Automatic mm / inch conversion · Core engineering specifications
| overall dimensions | 2400 x 1200 x 750 mm | |
|---|---|---|
| Finished Top Thickness | 45 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| table net weight | 115 kg | |
|---|---|---|
| uniform static worktop load capacity | 300 kg | |
| seating capacity | 6 persons | |
| single leg static load rating | 100 kg | |
| surface abrasion resistance | 2000 cycles | |
| edge impact resistance | 30 N | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles | |
| Top Abrasion Reference | Acceptance target ≥4,000 abrasion cycles or finish-system test |
Core acceptance fields · Panels / hardware / frame / upholstery
| worktop core | 25 mm high-density particleboard | |
|---|---|---|
| worktop surface finish | 0.6 mm wood-grain high-pressure laminate | |
| worktop edge banding | 2 mm matching PVC edge trim | |
| support legs | Polished die-cast aluminum alloy | |
| cable grommet trim | Brushed ABS plastic with rubber brush insert | |
| leg floor glides | Nylon adjustable leveling glides | |
| leg mounting brackets | 2 mm cold-rolled steel plates | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel | |
| Primary Connector Specification | Reference M6-M8 with at least 2 fixing points per main support | |
| Reference Finish / Color Count | Recommended 6top finishes and 3frame colors |
Adjustment / rotation / tilt / mobility / storage features
| central cable management grommet | Rectangular brush-sealed port routes power and data cables below worktop | |
|---|---|---|
| leveling adjustment | 10 mm vertical adjustment via bottom nylon glides to compensate for uneven flooring | |
| seating accommodation | Supports 6 cantilever conference chairs with full knee clearance on all sides | |
| worktop surface function | Matte scratch-resistant finish supports laptops, meeting materials and tabletop accessories | |
| structural stability | Four outward-angled legs distribute weight to prevent tipping during normal meeting use | |
| floor protection | Non-marking nylon glides prevent scuffing on hard commercial flooring materials | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 1100× 300 mm | |
| Reference Packaged Gross Weight | 90 kg/set in 2 cartons | |
| Reference Packaging Volume | 0.55 m³/set |
Recommended spaces / users / usage modes
| corporate boardrooms | 6-person seating for formal executive meetings and leadership discussions | |
|---|---|---|
| open-plan office meeting zones | Dedicated collaborative work area for team project reviews and client presentations | |
| executive private offices | Large work and meeting surface for senior staff meetings with small visitor groups | |
| training room applications | Stable work surface for small group training sessions and workshop activities | |
| hotel business centers | Guest meeting space for small corporate events and client consultations |
EU Market Access Requirements* EN Standards
| office table strength and durability | EN 527:2002 Office work tables - Safety and strength requirements | |
|---|---|---|
| surface wear resistance | EN 14322:2017 Laminate furniture surface performance | |
| furniture formaldehyde emission | EN 13986:2004 E1 class |
US and Canada office-furniture standards
| table load and stability | ANSI/BIFMA X2021Desk Products - Tests for safety and performance | |
|---|---|---|
| leg static load testing | ANSI/BIFMA X2021Section 7 vertical leg load test |
Standards applicable to China-market projects
| worktop formaldehyde emission | GB/T 17657E1 grade | |
|---|---|---|
| table structural stability | GB/T 3324General technical requirements for wooden furniture | |
| metal surface coating adhesion | GB/T 1993Paint film impact resistance test |
This product must meet the following technical requirements: 1. worktop formaldehyde emission: GB/T 17657E1 grade; 2. table structural stability: GB/T 3324General technical requirements for wooden furniture; 3. metal surface coating adhesion: GB/T 1993Paint film impact resistance test; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
