Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 3600 x 1400 x 750 mm | |
|---|---|---|
| Tabletop thickness | 36 mm | |
| Under-table knee clearance height | 680 mm | |
| Modesty panel height | 620 mm | |
| End leg panel width | 200 mm | |
| Central cable management strip length | 1800 mm | |
| Table corner radius | 50 mm | |
| Foot cap height | 30 mm | |
| End leg overhang from table edge | 100 mm | |
| Side overhang along table length | 150 mm | |
| Finished Top Thickness | 45 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| Seating capacity | 10 people | |
|---|---|---|
| Distributed tabletop static load | 200 kg | |
| Surface scratch resistance | 2H pencil hardness | |
| Net product weight | 90 kg | |
| Formaldehyde emission limit | 0.05 mg/m³ | |
| TVOC emission limit | 0.1 mg/m³ | |
| Adjustable foot pad leveling range | 10 mm | |
| Warranty period | 36 months | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
| Tabletop substrate | E1 grade particleboard | |
|---|---|---|
| Tabletop surface finish | Light oak wood grain melamine laminate | |
| Edge banding | 2mm thick PVC edge trim | |
| Modesty panel substrate | 18mm thick engineered wood panel | |
| End leg panels | 18mm thick engineered wood panel | |
| Foot accent caps | Solid wood matching tabletop finish | |
| Foot pads | Nylon anti-slip adjustable glides | |
| Cable channel cover | Matte aluminum alloy | |
| Connector hardware | Zinc-plated steel cam lock fittings | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel |
Adjustment / rotation / tilt / mobility / storage features
| Central cable management system | Recessed full-length channel with removable covers, routes power/data cables under table | |
|---|---|---|
| Full modesty panel | Solid vertical panel spans full central width between end legs, conceals under-table wiring and legs | |
| Leveling adjustment | Adjustable nylon foot pads at each leg base, compensates for up to 10mm floor unevenness | |
| Knock-down assembly | Flat-packed components with pre-drilled holes, all assembly hardware included | |
| Edge impact protection | Rounded radiused corners and thick PVC edge banding on all tabletop edges | |
| Cable access points | Multiple pre-cut openings along central strip for power outlets, HDMI, and network ports | |
| Stable support structure | Dual wide panel end legs connected via modesty panel, no central cross-bars blocking knee space | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 1100× 300 mm | |
| Reference Packaged Gross Weight | 90 kg/set in 2 cartons | |
| Reference Packaging Volume | 0.55 m³/set |
Recommended spaces / users / usage modes
| Medium corporate boardrooms | Accommodates 10 attendees for formal executive meetings and decision-making sessions | |
|---|---|---|
| Open-plan office meeting zones | Neutral two-tone finish complements modern light wood office interior schemes | |
| Training and conference facilities | Integrated cable management supports presentation equipment and device charging | |
| Government and institutional meeting spaces | Heavy-duty construction meets commercial durability requirements for high-use public areas | |
| Small video conferencing rooms | Central cable channel hides AV wiring for clean camera-facing presentation setups |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Office furniture work tables and desks, applies to height, strength, and stability requirements | |
|---|---|---|
| EN 13722:2004 | Furniture test methods for table static load and durability, suitable for performance validation | |
| EN 12521:2015 | Furniture strength, durability and safety requirements for non-domestic seating-adjacent tables |
US and Canada office-furniture standards
| North America procurement and testing reference | Recommended references: ANSI/BIFMA X5.5 |
|---|
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to dimensional and structural quality checks | |
|---|---|---|
| GB 18580-2017 | Formaldehyde emission limits for wood-based panels, required for indoor air quality compliance | |
| GB/T 4897.3-2003 | Performance requirements for particleboard used in furniture, applicable to tabletop substrate validation |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to dimensional and structural quality checks; 2. GB 18580-2017: Formaldehyde emission limits for wood-based panels, required for indoor air quality compliance; 3. GB/T 4897.3-2003: Performance requirements for particleboard used in furniture, applicable to tabletop substrate validation; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
