Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 2800 x 1400 x 750 mm | |
|---|---|---|
| Tabletop thickness | 25 mm | |
| Knee clearance height under table | 700 mm | |
| Central modesty panel dimensions | 1200 x 400 x 650 mm | |
| Leg outer diameter | 60 mm | |
| Cable grommet opening width | 80 mm | |
| Long-side seating knee space width per position | 700 mm | |
| End-side seating knee space width per position | 700 mm | |
| Leveling foot adjustment range | 15 mm | |
| Modesty panel bottom cable cutout width | 300 mm | |
| Primary Component Thickness | 40 mm according to load-bearing role | |
| Hardware / Moving-part Clearance | 5 mm operating clearance |
Net weight / load capacity / users / durability
| Maximum seated user capacity | 8 people | |
|---|---|---|
| Distributed tabletop static load capacity | 120 kg | |
| Table unit net weight | 140 kg | |
| Surface scratch resistance rating | 2000 cycles | |
| Surface heat resistance temperature | 120 °C | |
| Leveling foot load rating per foot | 80 kg | |
| Recommended commercial warranty period | 5 years | |
| Reference Static Load | 150 kg depending on category | |
| Moving-part Durability Reference | Acceptance target 50000 cycles | |
| Recommended Procurement Warranty | Structure 5 years; hardware 3 years |
Core acceptance fields · Panels / hardware / frame / upholstery
| Dark end tabletop sections | 25mm MDF substrate with matte dark grey melamine laminate | |
|---|---|---|
| Central tabletop section | 25mm MDF substrate with light wood grain melamine laminate | |
| Table edge banding | 2mm thick matching color PVC edge banding | |
| Cylindrical support legs | 1.5mm thick steel tube with matte dark grey powder coating | |
| Leg accent rings | Polished chrome plated metal trim rings at leg top and foot | |
| Central modesty panel | 18mm thick MDF panel with matching matte dark grey laminate finish | |
| Leveling feet | Nylon base with steel threaded stem, non-slip rubber pad | |
| Cable grommets | ABS plastic flip-top grommet with soft cable brush seal | |
| Primary Connector Specification | Reference M6-M10 with at least 2 fixing points at major joints | |
| Reference Finish / Color Count | Recommended 6finish options |
Adjustment / rotation / tilt / mobility / storage features
| Dual tabletop cable access | Two 80mm flip-top grommets route power/data cables from work surface to floor | |
|---|---|---|
| Central modesty panel cable pass-through | Lower cutout routes cables across table width without floor obstruction | |
| 6-point level adjustment | All 6 support feet rotate to adjust height and compensate for uneven floors | |
| Splice-constructed tabletop | Three-panel bolted assembly creates continuous flat work surface | |
| Concealed frame connection | Steel brackets attach legs and modesty panel to tabletop for rigid wobble-free use | |
| Wipe-clean surface maintenance | Non-porous laminate surface allows disinfection with standard office cleaners | |
| Modesty panel privacy screen | Central panel blocks knee and lap visibility across the table width | |
| Reference Adjustment / Operating Range | 100 mm or 120° where applicable |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Packaging Volume | 0.8 m³/set | |
| Reference Packaged Gross Weight | 120 kg/set |
Recommended spaces / users / usage modes
| Corporate boardrooms | Seats 8 for formal leadership meetings and presentations, with integrated cable access for AV | |
|---|---|---|
| Open office meeting areas | Provides collaborative workspace for team discussions and project reviews | |
| Training and conference facilities | Accommodates multi-person training sessions with device power access | |
| Small executive meeting rooms | Fits 30sqm rooms for client meetings and internal strategy sessions | |
| Hybrid work spaces | Supports video conferencing equipment setup via routed cable management | |
| Government and institutional offices | Durable commercial construction suitable for high-traffic public meeting areas |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Office work tables and desks, safety and strength requirements for commercial use | |
|---|---|---|
| EN 1335-1:2020 | Office furniture reference for clearances and ergonomic seated work dimensions |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Desk and table products standard, applicable to static load and durability testing | |
|---|---|---|
| ANSI/BIFMA e3-2019 | Furniture sustainability standard, applicable for material emissions and lifecycle criteria |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to tabletop and panel components | |
|---|---|---|
| GB/T 3327-2018 | Technical requirements for office tables, applicable to structural performance and dimensions | |
| GB 18584-2001 | Indoor decoration material limit of harmful substances for wood furniture, required for formaldehyde emission |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to tabletop and panel components; 2. GB/T 3327-2018: Technical requirements for office tables, applicable to structural performance and dimensions; 3. GB 18584-2001: Indoor decoration material limit of harmful substances for wood furniture, required for formaldehyde emission; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
