Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 2400 x 1200 x 750 mm | |
|---|---|---|
| Tabletop thickness | 38 mm | |
| Cable trough length | 1800 mm | |
| Cable trough width | 120 mm | |
| Leg cross-section | 50 x 50 mm square steel tube | |
| Leg wall thickness | 2 mm | |
| Under-table knee clearance height | 680 mm | |
| Under-table knee clearance depth | 450 mm | |
| Corner radius | 50 mm | |
| End leg setback from table edge | 300 mm | |
| Finished Top Thickness | 45 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| Tabletop distributed static load | 300 kg | |
|---|---|---|
| Seating capacity | 8 persons | |
| Surface abrasion resistance | 2000 cycles | |
| Finish stain resistance | Grade 1 | |
| Frame lateral stability load | 150 kg | |
| Product net weight | 85 kg | |
| Adjustable foot pad height adjustment | 15 mm | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
| Tabletop core | High-density particleboard core | |
|---|---|---|
| Tabletop surface | Light wood grain melamine laminate | |
| Tabletop edge | 3mm ABS impact-resistant edge banding | |
| Support legs | Off-white powder-coated steel square tube | |
| Internal support beam | Rectangular steel crossbeam under tabletop | |
| Leveling feet | Reinforced nylon adjustable foot pads | |
| Cable trough cover | Matched light wood finish removable panel | |
| Connector hardware | Zinc-plated steel bolts and cam locks | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel | |
| Primary Connector Specification | Reference M6-M8 with at least 2 fixing points per main support |
Adjustment / rotation / tilt / mobility / storage features
| Central cable management trough | Continuous longitudinal channel routes power, HDMI, and network cords across table length | |
|---|---|---|
| Removable trough cover | Flush-fit panel hides cords when not in use, lifts out for cable access or module installation | |
| Bilateral open access | No modesty panel or under-table storage blocking leg room on both long sides | |
| Adjustable floor leveling | Threaded foot pads twist to adjust leg height for uneven carpet or hard flooring | |
| Impact-safe rounded corners | Soft radiused edges reduce injury risk from contact during active meetings | |
| Easy-clean surface | Non-porous melamine finish wipes clean with standard office disinfectants without staining | |
| Modular power compatibility | Trough sized to accept aftermarket flip-up power, USB, and data port modules | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 1100× 300 mm | |
| Reference Packaged Gross Weight | 90 kg/set in 2 cartons | |
| Reference Packaging Volume | 0.55 m³/set |
Recommended spaces / users / usage modes
| Small to medium meeting rooms | Fits standard 8-person meeting spaces for team discussions and client presentations | |
|---|---|---|
| Open office collaboration zones | Open bilateral access supports ad-hoc group work and quick stand-up meetings | |
| Boardroom ancillary spaces | Light finish complements executive boardrooms for breakout or small committee meetings | |
| Training and workshop spaces | Cable management supports laptop and presentation device use for multi-participant training sessions | |
| Co-working common areas | Sturdy build and easy-clean surface support high-traffic shared workspace use |
EU Market Access Requirements* EN Standards
| EN 527-3:2003 | Office tables test methods for stability and mechanical strength, applicable to structural durability validation | |
|---|---|---|
| EN 14372:2004 | Office furniture structural safety requirements for edges and corners, applicable to rounded edge impact safety |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Desk products standard covering load, stability, and durability for commercial office tables |
|---|
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to tabletop dimensional and structural stability | |
|---|---|---|
| GB/T 4897.3-2003 | Requirements for particleboard used in furniture, applicable to tabletop core material performance | |
| GB 18584-2001 | Limit of formaldehyde emission for wooden furniture, required for indoor office air quality compliance |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to tabletop dimensional and structural stability; 2. GB/T 4897.3-2003: Requirements for particleboard used in furniture, applicable to tabletop core material performance; 3. GB 18584-2001: Limit of formaldehyde emission for wooden furniture, required for indoor office air quality compliance; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
