Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 3500 x 800 x 1100 mm | |
|---|---|---|
| Worktop thickness | 50 mm | |
| Front facade panel thickness | 25 mm | |
| Plinth base height | 100 mm | |
| Standing transaction counter height | 1100 mm | |
| Behind-desk seated work surface height | 750 mm | |
| Knee clearance depth behind desk | 650 mm | |
| LED accent channel width | 20 mm | |
| Corner radius on front LED trim | 150 mm | |
| Internal storage compartment depth | 600 mm | |
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| Worktop static load capacity | 50 kg | |
|---|---|---|
| Drawer slide load rating | 35 kg | |
| Drawer slide cycle life | 50000 cycles | |
| Cabinet hinge cycle life | 80000 cycles | |
| Formaldehyde emission level | 9 mg/100g | |
| Paint surface hardness | 3H | |
| LED strip operational lifespan | 50000 hours | |
| Recommended receptionist capacity | 3 people | |
| Net product weight | 300 kg | |
| Top Static Load Reference | 150 kg uniformly distributed |
Core acceptance fields · Panels / hardware / frame / upholstery
| Internal substrate | E1-grade MDF panel with anti-crack fiber mesh reinforcement | |
|---|---|---|
| Exterior finish | Two-tone matte white and beige environmental paint | |
| Accent trim | Recessed blue LED strip with frosted polycarbonate diffuser | |
| Worktop surface | High-pressure laminate anti-scratch overlay | |
| Internal framing | 18mm thick plywood support structure | |
| Edge banding | 2mm thick PVC edge banding matching panel color | |
| Storage hardware | Cold-rolled steel ball-bearing drawer slides and concealed hinges | |
| Plinth base | Powder-coated steel support frame under wood panel base | |
| Cable management | ABS plastic cable trays and 80mm diameter desk grommets | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel |
Adjustment / rotation / tilt / mobility / storage features
| LED accent lighting | Integrated 12V blue LED strips along front geometric contours, wall-switch controlled | |
|---|---|---|
| Concealed storage | Behind-facade double-door cabinets and pull-out drawers for office supplies | |
| Cable management system | Internal routing channels with desk grommets for power, data and security wiring | |
| Leveling adjustment | Adjustable feet on plinth base for uneven commercial carpeted floors | |
| Workstation layout | Three behind-desk seating positions for reception staff | |
| Custom branding option | Recessed logo panel position above front facade for company signage | |
| Easy-clean surface | Non-porous painted facade and laminate worktop for stain resistance | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
| Corporate office lobby | High-tech company entry reception area for visitor check-in and greeting | |
|---|---|---|
| Technology showroom entry | Front counter for tech exhibition space guest registration and direction | |
| Command center reception | Public-facing counter for monitoring facility lobby check-in | |
| Modern co-working space entry | Reception counter for shared office member check-in and guest services | |
| Dual-use transaction point | Standing guest interaction on front side, seated staff work on rear side |
EU Market Access Requirements* EN Standards
| EN 527-2:2002+A1:2019 | Office worktables safety and strength requirements, applicable to work surface load | |
|---|---|---|
| EN 13722:2004 | Furniture - Reception desks - Functional and safety requirements |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Desk products performance standard, applicable to static load and durability testing |
|---|
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to desk structural safety | |
|---|---|---|
| GB 18580-2017 | Formaldehyde emission limits for wood-based panels, applicable to substrate E1 compliance | |
| GB/T 4893.8-2013 | Surface paint film hardness test method, applicable to 3H finish verification |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to desk structural safety; 2. GB 18580-2017: Formaldehyde emission limits for wood-based panels, applicable to substrate E1 compliance; 3. GB/T 4893.8-2013: Surface paint film hardness test method, applicable to 3H finish verification; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
