PRODUCT MODULE 01 / 06

Physical Dimensions

Automatic mm / inch conversion · Core engineering specifications

Data source: Structured from factory data; final measured values prevail.

Overall dimensions (W × D × H)	3600 × 1200 × 1100 mm
Finished Top Thickness	50 mm
Effective Knee Clearance	680 mm high and 900 mm wide per main seat
Leg / Support Section	80 mm main section with 2 mm metal wall
Cable Opening Size	80 mm diameter; cable tray depth 120 mm

PRODUCT MODULE 02 / 06

Weight, Load & Performance

Net weight / load capacity / users / durability

Data source: Product performance data; verify exact test conditions before procurement.

Product net weight	210 kg
Work surface distributed load capacity	150 kg
Supported concurrent users	3
Seating capacity for visitor side	0
Recommended service life	8 years
Surface abrasion resistance rating	2000 cycles
Top Static Load Reference	150 kg uniformly distributed
Drawer Slide Load / Life	45 kg/pair; 50000 cycles
Hinge Opening Life	Acceptance target 80000 cycles
Top Abrasion Reference	Acceptance target ≥4,000 abrasion cycles or finish-system test

PRODUCT MODULE 03 / 06

Materials & Structure

Core acceptance fields · Panels / hardware / frame / upholstery

Data source: Subject to the factory material list and inspection report.

Worktop substrate	18mm E1 grade particleboard
Worktop finish	White matte melamine laminate
Edge banding	2mm thick PVC edge trim
Modesty panels	25mm melamine-faced particleboard
Structural support dividers	25mm thick panel uprights
End support columns	30mm thick boxed panel construction
Wire grommets	ABS plastic 60mm diameter
Structural hardware	Zinc-plated steel cam lock connectors
Primary Panel Thickness	25 mm; load-bearing top may use 40 mm composite build-up
Edge Band Thickness	2 mm
Metal Frame Wall Thickness	2 mm cold-rolled steel
Primary Connector Specification	Reference M6-M8 with at least 2 fixing points per main support

PRODUCT MODULE 04 / 06

Functions & Adjustment

Adjustment / rotation / tilt / mobility / storage features

Data source: Functional configuration; the supplier specification prevails.

Cable management ports	Three 60mm grommet openings aligned to each workstation
Independent knee bays	Three separate open leg spaces separated by vertical dividers
Front privacy barrier	350mm high modesty panel running full length of public side
Corner L configuration	90-degree right-angle layout for corner placement
Knockdown assembly	Flat-pack construction with cam-lock fasteners
Leveling adjustment	Glide feet at base of all support panels
Cable Management Capacity	Reference capacity 10power/data cables; tray load 10 kg
Reference Reassembly Count	Main joints should support 5controlled assembly cycles

PRODUCT MODULE 05 / 06

Packaging & Logistics

Verified carton / gross weight / assembly / loading data

Data source: Reference for export quotations and container planning.

Reference Package Count	1 set / 2 cartons
Reference Assembly Time	40 minutes per set
Reference Package Dimensions	Main top 2500× 1050× 350 mm; return/pedestal packed separately
Reference Packaged Gross Weight	180 kg/set in 4 cartons
Reference Packaging Volume	1 m³/set

PRODUCT MODULE 06 / 06

Applications & Usage

Recommended spaces / users / usage modes

Data source: Recommended applications based on product form and category.

Corporate office reception areas	Front-facing counter for greeting visitors and processing guest check-in
Three-staff shared service counters	Equipped with separate work zones for receptionists, admin staff or customer service teams
Medical clinic or service center lobbies	Durable easy-clean surface suitable for high-traffic public-facing service points
Open-plan office corner installations	90-degree L shape fits flush against intersecting walls to save floor space
Government or public service halls	Long continuous counter supports simultaneous visitor service at multiple positions
Co-working space welcome desks	Neutral white finish complements modern minimalist office interiors

STANDARD S1

EU Market Entry Requirements * EN Standards

EU Market Access Requirements* EN Standards

Office furniture safety requirement	EN 527:2002
Furniture formaldehyde emission class	EN 312:2010
Office work surface ergonomics	EN 1335:2020

STANDARD S3

Standards Applicable to China-Market Projects * GB Standards

Standards applicable to China-market projects

Office desk dimensional standard	GB/T 3326
Panel furniture formaldehyde limit	GB 18580
Furniture surface durability standard	GB/T 4893.8

Standardized tender description text

This product must meet the following technical requirements:
1. Office desk dimensional standard: GB/T 3326;
2. Panel furniture formaldehyde limit: GB 18580;
3. Furniture surface durability standard: GB/T 4893.8;
Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.

GENERATED EXPORTS

Ready-to-use export tools

Export data is generated from the current published product record.

Technical Report PDF

Directly download an English report in metric or imperial units.

PDF · REC-L3-3600W

Complete Parameter Workbook

Download all product information and parameter modules in English.

XLSX · REC-L3-3600W

International Listing Template

English title, specifications, materials, standards and purchasing fields.

XLSX · LISTING

Customs Declaration Data

Prepare customs description, material, usage, dimensions and declaration elements.

CUSTOMS · REC-L3-3600WOpen Export Tool

Quick Actions

Post an RFQ

Product Description

The Triple-Seat L-Shaped Reception Desk with Wire Management, model REC-L3600W, is a purpose-built public-facing service counter designed for high-traffic front-of-house settings. It features a clean 90-degree right-angle L-shaped layout finished in matte white, with a streamlined form that sits flush against intersecting walls to optimize floor space in corner installations. The public-facing side is fitted with a full-length modesty panel to maintain staff privacy, while three separate open knee bays separated by vertical dividers create dedicated independent work zones for concurrent use by three staff members, with no dedicated visitor seating integrated into the unit. Constructed for durable daily use, the desk’s worktop uses E1 grade particleboard substrate topped with white matte melamine laminate, finished with thick PVC edge trim to resist wear from regular contact. Structural components include melamine-faced particleboard modesty panels, thick panel upright dividers, and boxed panel end support columns, joined with zinc-plated steel cam lock connectors for stable assembly. The metal leg support sections provide robust load bearing, while adjustable glide feet at the base of all support panels allow for stable positioning on uneven flooring. All work surfaces have a smooth, easy-to-clean finish suited for frequent public use, with tested abrasion resistance to withstand regular contact from office equipment and daily handling. Integrated cable management is built into each workstation, with aligned ABS plastic grommet openings that route power and data cords to under-desk cable trays, keeping work surfaces free of tangled wiring. The desk supports a uniformly distributed work surface load, making it suitable for holding reception equipment, visitor sign-in tools, and office supplies. It ships in flat-pack packaging for efficient transport, with cam-lock fasteners enabling straightforward on-site assembly. This reception desk is well suited for a range of commercial and public spaces, including corporate office reception areas for visitor greeting and check-in, three-station shared service counters for admin or customer service teams, high-traffic medical clinic and service center lobbies, open-plan office corner installations, government and public service halls, and co-working space welcome desks, where its neutral white finish complements modern minimalist interior schemes. For procurement planning, note that the unit is delivered unbranded in multiple cartons, with a documented reference assembly time per set. Specified knee clearance dimensions accommodate standard office task seating, and the rated 8-year recommended service life supports long-term facility investment planning. Buyers should account for total packaged weight and volume when coordinating delivery and on-site handling, and confirm that the L-shaped footprint aligns with available corner space prior to installation.
