| Submitted | Field | Original | Note / Status | |
|---|---|---|---|---|
No corrections yet. Use the flag at the end of a row to report an issue. | ||||
Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 3600 x 1200 x 1100 mm | |
|---|---|---|
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| Product net weight | 210 kg | |
|---|---|---|
| Work surface distributed load capacity | 150 kg | |
| Supported concurrent users | 3 | |
| Seating capacity for visitor side | 0 | |
| Recommended service life | 8 years | |
| Surface abrasion resistance rating | 2000 cycles | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles | |
| Top Abrasion Reference | Acceptance target ≥4,000 abrasion cycles or finish-system test |
Core acceptance fields · Panels / hardware / frame / upholstery
| Worktop substrate | 18mm E1 grade particleboard | |
|---|---|---|
| Worktop finish | White matte melamine laminate | |
| Edge banding | 2mm thick PVC edge trim | |
| Modesty panels | 25mm melamine-faced particleboard | |
| Structural support dividers | 25mm thick panel uprights | |
| End support columns | 30mm thick boxed panel construction | |
| Wire grommets | ABS plastic 60mm diameter | |
| Structural hardware | Zinc-plated steel cam lock connectors | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel | |
| Primary Connector Specification | Reference M6-M8 with at least 2 fixing points per main support |
Adjustment / rotation / tilt / mobility / storage features
| Cable management ports | Three 60mm grommet openings aligned to each workstation | |
|---|---|---|
| Independent knee bays | Three separate open leg spaces separated by vertical dividers | |
| Front privacy barrier | 350mm high modesty panel running full length of public side | |
| Corner L configuration | 90-degree right-angle layout for corner placement | |
| Knockdown assembly | Flat-pack construction with cam-lock fasteners | |
| Leveling adjustment | Glide feet at base of all support panels | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
| Corporate office reception areas | Front-facing counter for greeting visitors and processing guest check-in | |
|---|---|---|
| Three-staff shared service counters | Equipped with separate work zones for receptionists, admin staff or customer service teams | |
| Medical clinic or service center lobbies | Durable easy-clean surface suitable for high-traffic public-facing service points | |
| Open-plan office corner installations | 90-degree L shape fits flush against intersecting walls to save floor space | |
| Government or public service halls | Long continuous counter supports simultaneous visitor service at multiple positions | |
| Co-working space welcome desks | Neutral white finish complements modern minimalist office interiors |
EU Market Access Requirements* EN Standards
| Office furniture safety requirement | EN 527:2002 | |
|---|---|---|
| Furniture formaldehyde emission class | EN 312:2010 | |
| Office work surface ergonomics | EN 1335:2020 |
Standards applicable to China-market projects
| Office desk dimensional standard | GB/T 3326 | |
|---|---|---|
| Panel furniture formaldehyde limit | GB 18580 | |
| Furniture surface durability standard | GB/T 4893.8 |
This product must meet the following technical requirements: 1. Office desk dimensional standard: GB/T 3326; 2. Panel furniture formaldehyde limit: GB 18580; 3. Furniture surface durability standard: GB/T 4893.8; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
