PRODUCT MODULE 01 / 06

Physical Dimensions

Automatic mm / inch conversion · Core engineering specifications

Data source: Structured from factory data; final measured values prevail.

Overall dimensions (W × D × H)	800 × 600 × 1220 mm
Desktop height from floor	760 mm
Partition height above desktop	460 mm
Desktop usable depth	600 mm
Desktop usable width	800 mm
Knee well clearance height	650 mm
Knee well clearance width	700 mm
Pull-out tray internal height	80 mm
Partition panel thickness	18 mm
Desktop panel thickness	25 mm
Drawer slide extension length	450 mm
Front privacy panel width	700 mm
Side panel height	1220 mm
Primary Component Thickness	40 mm according to load-bearing role
Hardware / Moving-part Clearance	5 mm operating clearance

PRODUCT MODULE 02 / 06

Weight, Load & Performance

Net weight / load capacity / users / durability

Data source: Product performance data; verify exact test conditions before procurement.

Desktop static load capacity	100 kg
Net product weight	70 kg
Recommended user weight capacity	136 kg
Surface scratch resistance rating	2000 cycles
Surface stain resistance level	Grade 4
Structural warranty period	5 years
Available color finish count	2
Reference Static Load	150 kg depending on category
Moving-part Durability Reference	Acceptance target 50000 cycles
Recommended Procurement Warranty	Structure 5 years; hardware 3 years

PRODUCT MODULE 03 / 06

Materials & Structure

Core acceptance fields · Panels / hardware / frame / upholstery

Data source: Subject to the factory material list and inspection report.

Desktop substrate	25mm E1 grade particleboard
Partition panels	18mm melamine-faced particleboard
Edge banding	2mm thick PVC edging
Drawer construction	15mm melamine particleboard box
Drawer lock hardware	Zinc alloy keyed cam lock
Frame hardware connectors	Powder-coated steel cam fittings
Accent trim panels	High-gloss yellow acrylic laminate
Leveling glides	Nylon base adjustable feet
Cable management grommets	ABS plastic wire ports
Primary Connector Specification	Reference M6-M10 with at least 2 fixing points at major joints
Reference Finish / Color Count	Recommended 6finish options

PRODUCT MODULE 04 / 06

Functions & Adjustment

Adjustment / rotation / tilt / mobility / storage features

Data source: Functional configuration; the supplier specification prevails.

Privacy enclosure function	Wraparound 460mm tall partitions above desk
Lockable storage drawer	Key-locked full-extension drawer under right desk section
Pull-out open tray	Sliding open tray adjacent to lockable drawer
Cable routing capability	Rear desktop wire grommets
Modular configuration compatibility	Freestanding unit designed for row placement
Floor leveling adjustment	15mm height adjustment on base glides
Surface maintenance property	Stain and water resistant melamine finish
Locking operation	Single key lock secures the main storage drawer
Lockable drawer internal height	120 mm
Reference Adjustment / Operating Range	100 mm or 120° where applicable

PRODUCT MODULE 05 / 06

Packaging & Logistics

Verified carton / gross weight / assembly / loading data

Data source: Reference for export quotations and container planning.

Reference Package Count	1 set / 2 cartons
Reference Assembly Time	40 minutes per set
Reference Packaging Volume	0.8 m³/set
Reference Packaged Gross Weight	120 kg/set

PRODUCT MODULE 06 / 06

Applications & Usage

Recommended spaces / users / usage modes

Data source: Recommended applications based on product form and category.

Open plan office focused work zones	Enclosed design reduces distraction for individual task work
Educational exam and study areas	High partitions prevent visual cheating during testing
Call center and shared workspace environments	Modular layout creates semi-private individual work points
Library individual study carrel applications	Compact footprint fits in quiet study floor plans
Startup and co-working space dedicated stations	Provides assigned private desk space in flexible offices
Training room individual work positions	Integrated storage supports training material organization

STANDARD S1

EU Market Entry Requirements * EN Standards

EU Market Access Requirements* EN Standards

EN 527-1:2011	Office work tables safety and strength requirements, applicable for commercial desk design
EN 13722:2004	Office furniture storage units performance requirements, applicable for drawer durability
EN 71-3:2019	Migration of certain elements, applicable for surface finish safety if used in educational settings

STANDARD S2

North America Purchasing & Inspection Reference * ANSI/BIFMA Standards

US and Canada office-furniture standards

ANSI/BIFMA X5.5-2021	Desk products performance standard, recommended for commercial grade load testing
ANSI/BIFMA X5.9-2019	Storage units performance standard, recommended for drawer cycle testing
BIFMA e3-2019	Furniture sustainability standard, recommended for low-emission material verification

STANDARD S3

Standards Applicable to China-Market Projects * GB Standards

Standards applicable to China-market projects

GB/T 3324-2017	General technical requirements for wooden furniture, applicable for desk structural performance
GB 18580-2017	Formaldehyde emission limits for wood-based panels, required for E1 grade substrate verification
GB/T 4897-2015	Particleboard quality standard, applicable for desktop and panel substrateAcceptance inspection

Standardized tender description text

This product must meet the following technical requirements:
1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable for desk structural performance;
2. GB 18580-2017: Formaldehyde emission limits for wood-based panels, required for E1 grade substrate verification;
3. GB/T 4897-2015: Particleboard quality standard, applicable for desktop and panel substrateAcceptance inspection;
Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.

GENERATED EXPORTS

Ready-to-use export tools

Export data is generated from the current published product record.

Technical Report PDF

Directly download an English report in metric or imperial units.

PDF · CD-SGL-PRT-001

Complete Parameter Workbook

Download all product information and parameter modules in English.

XLSX · CD-SGL-PRT-001

International Listing Template

English title, specifications, materials, standards and purchasing fields.

XLSX · LISTING

Customs Declaration Data

Prepare customs description, material, usage, dimensions and declaration elements.

CUSTOMS · CD-SGL-PRT-001Open Export Tool

Quick Actions

Post an RFQ

Product Description

The CD-SGL-PRT-001 single-seat enclosed privacy partition cubicle workstation desk is a freestanding, modular public and commercial furniture solution delivered unbranded, designed to deliver dedicated, semi-private work points across high-traffic shared environments. Visually, the unit presents a compact, streamlined rectangular layout with wraparound partitions rising 460mm above the 800mm wide, 600mm deep work surface, accented with high-gloss yellow decorative trim panels that add subtle visual definition without overwhelming surrounding space. Two available color finish options support coordination with existing interior design schemes, while the unobtrusive footprint fits neatly into structured rowed layouts without creating visual clutter.
Construction centers on durable, commercial-grade materials selected for long-term high-use operation. The desktop uses 25mm E1 grade particleboard topped with scratch and stain-resistant melamine, finished with 2mm thick PVC edge banding to protect against impact and daily wear. Partition panels are built from 18mm melamine-faced particleboard, while the integrated storage drawer uses 15mm melamine particleboard for its box structure, secured with a zinc alloy keyed cam lock. Structural connectors are powder-coated steel, with nylon base adjustable feet offering 15mm of height adjustment to accommodate uneven floors, and ABS plastic wire grommets integrated at the desktop rear. The full unit supports a 100kg static load on the desktop, with a 136kg recommended user weight capacity, a Grade 4 stain resistance rating, 2000-cycle scratch resistance, and a 5-year structural warranty. The melamine surface is stain and water resistant for simple routine maintenance.
Core practical functions include the wraparound partition system that blocks surrounding visual distractions, a key-locked full-extension drawer positioned under the right desk section for secure personal or work item storage, and an adjacent sliding open pull-out tray for frequently accessed supplies. Rear cable grommets support tidy routing of power and data cords, and the freestanding modular design enables seamless row placement for scaled installations.
This workstation is well suited for open-plan office focused work zones, educational exam and study areas, call centers and shared workspaces, library individual study carrels, startup and co-working dedicated stations, and training room individual work positions. For procurement, note that each unit ships in two cartons with a total packaged gross weight of 120kg and packaging volume of 0.8 cubic meters, requires 40 minutes of assembly per set, and offers 15mm of floor leveling adjustment to suit varied site conditions.

Single-Seat Enclosed Privacy Partition Cubicle Workstation Desk with Lockable Drawer Specifications
