| Submitted | Field | Original | Note / Status | |
|---|---|---|---|---|
No corrections yet. Use the flag at the end of a row to report an issue. | ||||
Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 3000 x 800 x 1100 mm | |
|---|---|---|
| Seated work surface height | 750 mm | |
| Raised rear monitor surface height | 1100 mm | |
| Single workstation clear width | 1500 mm | |
| Knee clearance height under work surface | 680 mm | |
| Work surface panel thickness | 25 mm | |
| Front privacy panel thickness | 18 mm | |
| Kickplate/plinth height | 100 mm | |
| Edge banding thickness | 2 mm | |
| Cable grommet diameter | 80 mm | |
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| Work surface static load capacity | 150 kg | |
|---|---|---|
| Drawer slide load rating per drawer | 45 kg | |
| Drawer slide cycle rating | 50000 cycles | |
| Hinge cycle rating for cabinet doors | 80000 cycles | |
| Seating capacity | 2 reception staff | |
| Surface scratch resistance rating | 2000 revolutions | |
| Unit net weight | 250 kg | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
| Main structural panels | 25mm melamine-faced particle board | |
|---|---|---|
| Front accent panel | 18mm dark grey matte melamine engineered wood | |
| Base plinth trim | Black PVC or powder-coated steel strip | |
| Horizontal accent trim | 2mm black PVC edge band | |
| Work surface finish | Matte white thermofused melamine | |
| Structural support frame | 1.2mm thick powder-coated steel internal frame | |
| Edge sealing | 2mm thick PVC impact-resistant edge banding | |
| Storage hardware | Cold-rolled steel drawer slides and hinges | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel | |
| Primary Connector Specification | Reference M6-M8 with at least 2 fixing points per main support |
Adjustment / rotation / tilt / mobility / storage features
| Dual independent work zones | Two equal 1500mm wide stations, each with dedicated cable access | |
|---|---|---|
| Cable management system | 80mm desk grommets connect to under-desk cable trays | |
| Solid front privacy panel | Full-height closed facade obscures under-desk area from visitors | |
| Under-desk storage provision | Integrated mobile pedestals fit under each work zone | |
| Modular assembly design | Knock-down panelized construction for on-site installation | |
| Customizable size option | Length/finish configurable to match lobby dimensions | |
| Surface moisture resistance | Melamine finish resists liquid spills from reception visitor interactions | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
| Corporate office lobby | Suitable for company front entrance, greets visitors and hides staff work area | |
|---|---|---|
| Two-person reception team | Provides dedicated equal workspace for two front-desk staff | |
| High-traffic commercial spaces | Durable melamine surface resists daily wear from visitor and staff use | |
| Modern minimalist office interiors | Two-tone white/dark grey finish matches contemporary office design schemes | |
| Service counters for public facilities | Suitable for hotel front desks, clinic check-in, or government service lobbies | |
| Free-standing against lobby walls | Flat back design requires no wall mounting, flexible for lobby layout |
EU Market Access Requirements* EN Standards
| EN 527-2:2002+A1:2016 | Office worktables: safety, strength and durability requirements | |
|---|---|---|
| EN 13722:2004 | Office furniture: reception desks, functional and safety requirements |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Desk products: safety and durability performance requirements | |
|---|---|---|
| ANSI/BIFMA X7.1-2021 | Formaldehyde and TVOC emission limits for office furniture |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden office furniture | |
|---|---|---|
| GB/T 4897-2015 | Particle board for furniture use | |
| GB 18580-2017 | Formaldehyde emission limits for wood-based panels |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden office furniture; 2. GB/T 4897-2015: Particle board for furniture use; 3. GB 18580-2017: Formaldehyde emission limits for wood-based panels; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
