Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 2400 x 600 x 1000 mm | |
|---|---|---|
| Countertop thickness | 50 mm | |
| Front mirrored panel height | 750 mm | |
| Stainless steel plinth height | 100 mm | |
| Raised end overhang length | 400 mm | |
| Diamond inlay diagonal length | 350 mm | |
| Edge banding thickness | 2 mm | |
| Internal frame panel thickness | 18 mm | |
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| Countertop static load capacity | 150 kg | |
|---|---|---|
| Drawer slide load rating (if fitted) | 35 kg | |
| Drawer slide cycle rating | 50000 cycles | |
| Hinge cycle rating (if fitted) | 80000 cycles | |
| Recommended maximum user count | 2 reception staff | |
| Product net weight | 130 kg | |
| Surface abrasion resistance | 2000 cycles | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
| Internal core structure | 18mm thick medium-density fiberboard (MDF) | |
|---|---|---|
| Exterior body finish | High-gloss white baked polyurethane lacquer | |
| Countertop surface | Artificial marble-look solid surface | |
| Front decorative panel | Smoked silver mirrored glass with diamond beveled grid | |
| Base plinth trim | Brushed stainless steel sheet, 1.2mm thick | |
| Edge trim | 2mm thick matching white PVC edge banding | |
| Internal hardware | Cold-rolled steel hinges, screws and connecting fittings | |
| Countertop substrate | Plywood support layer under solid surface top | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel | |
| Primary Connector Specification | Reference M6-M8 with at least 2 fixing points per main support |
Adjustment / rotation / tilt / mobility / storage features
| Linear guest-facing service layout | Full-length front facade directs guest interaction to open counter side | |
|---|---|---|
| Raised terminal section | Right-end extended overhang supports check-in or cashier transaction positioning | |
| Cable management provision | 80mm diameter rear cable grommet for POS, computer and telecom wiring | |
| Optional internal storage | Lockable drawer and shelf compartment configuration for office supplies | |
| Freestanding installation | Floor-standing plinth base requires no wall fixing for standard placement | |
| Wear-resistant surface | Lacquered exterior resists daily cleaning and minor scuffs from lobby use | |
| Optional LED accent lighting | Recessed strip lighting fitment compatible behind front mirrored panel | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
| Office lobby reception | Suitable for company entry areas to greet visitors and process check-in | |
|---|---|---|
| Retail cashier counter | Supports checkout operations for beauty salons, boutiques and service stores | |
| Hotel front desk small format | Fits boutique hotel lobbies for guest registration and concierge service | |
| Clinic reception area | Appropriate for medical or dental clinic patient check-in stations | |
| Recommended placement | Position against finished lobby wall with 1200mm clear circulation space in front | |
| Pairing recommendation | Match with 2 adjustable-height reception stools for staff use |
EU Market Access Requirements* EN Standards
| EN 527-2:2002 | Office work tables safety and strength requirements for work surfaces | |
|---|---|---|
| EN 15372:2016 | Furniture strength, durability and safety for non-domestic storage units | |
| EN 13722:2004 | Furniture surface resistance to cold liquids for finished worktops |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Desk products safety and performance standard for commercial office use | |
|---|---|---|
| ANSI/BIFMA X5.9-2019 | Storage units performance standard for integral cabinet components |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to cabinet and desk construction | |
|---|---|---|
| GB 18584-2001 | Indoor decoration material limit of harmful substances for wooden furniture | |
| GB/T 4897.3-2003 | Particleboard for furniture use, applicable to core panel material acceptance |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to cabinet and desk construction; 2. GB 18584-2001: Indoor decoration material limit of harmful substances for wooden furniture; 3. GB/T 4897.3-2003: Particleboard for furniture use, applicable to core panel material acceptance; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
