Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 2400 x 800 x 1050 mm | |
|---|---|---|
| Work surface height | 750 mm | |
| Front facade height | 1050 mm | |
| Work surface depth | 600 mm | |
| Knee clearance height under worktop | 680 mm | |
| Rounded corner radius | 100 mm | |
| Worktop panel thickness | 25 mm | |
| Front panel thickness | 18 mm | |
| Edge band thickness | 2 mm | |
| Cable grommet diameter | 60 mm | |
| Internal storage compartment height | 400 mm | |
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| Work surface static load capacity | 150 kg | |
|---|---|---|
| Recommended maximum occupancy | 2 staff | |
| Product net weight | 180 kg | |
| Surface scratch resistance rating | 2H pencil hardness | |
| Drawer slide load rating (if fitted) | 25 kg | |
| Drawer slide cycle rating | 50000 open/close cycles | |
| Hinge cycle rating (if fitted) | 80000 open/close cycles | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
| Worktop substrate | 18mm thick MDF core board | |
|---|---|---|
| Front facade panel | 18mm thick MDF with embossed wave texture | |
| Surface finish | High-gloss white UV-cured baked paint | |
| Internal support frame | 1.2mm thick rectangular steel tubing | |
| Edge treatment | 2mm thick matching white PVC edge banding | |
| Leveling feet | Nylon base adjustable steel feet | |
| Internal storage panels | 15mm thick particleboard | |
| Cable management hardware | ABS plastic grommets and cable tray | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel | |
| Primary Connector Specification | Reference M6-M8 with at least 2 fixing points per main support |
Adjustment / rotation / tilt / mobility / storage features
| Cable management system | Dual 60mm grommets with under-desk cable tray | |
|---|---|---|
| Under-worktop storage | Optional suspended drawer and open shelf | |
| Floor leveling adjustment | 15mm vertical adjustment range on feet | |
| Work surface layout | Dual parallel seated work zones | |
| Front privacy screen | Full-height 1050mm front facade | |
| Cleaning compatibility | Non-porous glossy surface | |
| Assembly structure | Knock-down flat-packed panel construction | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
| Office lobby reception area | Primary use for corporate office entry guest greeting and visitor check-in | |
|---|---|---|
| Commercial retail concierge | Suitable for boutique retail, salon or gym front desk checkout and consultation | |
| Medical clinic check-in station | Works for small clinic, dental office or medical spa patient registration | |
| Dual-staff work configuration | Designed for 2reception staff during standard business hours | |
| Modern minimalist interior schemes | Matches contemporary, high-gloss, neutral-toned commercial interior designs | |
| Waiting area adjacent placement | Positioned facing entry, with seating zone 1800 mm in front for guest queueing |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Office work tables safety and strength requirements, applies to worktop load and stability | |
|---|---|---|
| EN 13722:2004 | Furniture test for storage unit strength and durability, applies to internal cabinet components |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Desk products performance standard, covers static load, stability and durability testing |
|---|
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applies to structural safety and finish quality | |
|---|---|---|
| GB 18580-2017 | Formaldehyde emission limit for wood-based panels, sets E1 ≤0.124mg/m³ emission requirement | |
| GB/T 4893.4-2013 | Surface paint film adhesion test standard, validates finish bonding to wood substrate | |
| GB/T 4893.8-2013 | Surface wear resistance test for furniture finishes, sets minimum commercial abrasion threshold |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applies to structural safety and finish quality; 2. GB 18580-2017: Formaldehyde emission limit for wood-based panels, sets E1 ≤0.124mg/m³ emission requirement; 3. GB/T 4893.4-2013: Surface paint film adhesion test standard, validates finish bonding to wood substrate; 4. GB/T 4893.8-2013: Surface wear resistance test for furniture finishes, sets minimum commercial abrasion threshold; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
