Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 2400 x 800 x 1100 mm | |
|---|---|---|
| Work surface height | 1050 mm | |
| Work surface thickness | 30 mm | |
| Front faceted panel thickness | 18 mm | |
| Recessed LED plinth height | 100 mm | |
| Cable grommet diameter | 80 mm | |
| Grommet spacing (center to center) | 1200 mm | |
| Work surface depth (front to back) | 650 mm | |
| Base plinth setback from front edge | 50 mm | |
| Knee clearance height (staff side) | 700 mm | |
| Edge band thickness | 2 mm | |
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| Work surface static load capacity | 150 kg | |
|---|---|---|
| Unit net weight | 180 kg | |
| Recommended user capacity | 2 reception staff | |
| Drawer slide load rating (if fitted) | 25 kg per drawer | |
| Drawer slide cycle rating | 50000 open/close cycles | |
| Hinge cycle rating (if storage doors fitted) | 80000 open/close cycles | |
| Surface abrasion resistance | 400 cycles | |
| LED strip operational lifespan | 50000 hours | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
| Work surface top | White seamless solid surface, 30mm thick, high-gloss polished finish | |
|---|---|---|
| Front faceted facade panels | High-gloss white solid surface, diamond-angle geometric construction, seamless joints | |
| Internal structural carcass | 18mm thick moisture-resistant MDF/plywood, reinforced internal bracing | |
| Base plinth frame | Powder-coated steel rectangular section, 1.5mm wall thickness, matte white finish | |
| Integrated LED lighting | 24V DC cool white LED strip, recessed into base plinth, diffused frosted cover | |
| Cable grommets | ABS plastic, soft brush insert, white finish matching work surface | |
| Cable management tray | 0.8mm thick galvanized steel, mounted under work surface between grommets | |
| Leveling feet | Nylon base, 12mm steel threaded stem, 20mm adjustment range | |
| Hardware components | Zinc-plated steel screws, confirmat connectors, corrosion-resistant finish | |
| Back panel (staff side) | 18mm thick white melamine laminated particleboard, smooth matte finish | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm |
Adjustment / rotation / tilt / mobility / storage features
| Integrated base LED illumination | Continuous cool white linear light along full base perimeter, hardwired for fixed installation | |
|---|---|---|
| Dual cable management grommets | Two pass-through ports with brush seals to route power/data cables from work surface to under-desk tray | |
| Modular custom configuration | Available in custom lengths, finishes, LED color temperatures and add-on storage per commercial project requirements | |
| Floor leveling adjustment | Adjustable feet at each corner to correct uneven floor surfaces up to 20mm height difference | |
| Seated staff work position | Ergonomic staff-side clearance supports standard office chairs for extended reception shifts | |
| Standing transaction interface | 1050mm work surface height supports visitor standing check-in, document handoff and guest interaction | |
| Seamless facade appearance | Faceted panels are joined with color-matched adhesive to create a continuous monolithic geometric front | |
| Optional locking storage | Lockable drawer and cabinet compartments can be added on staff side for paperwork and office supplies storage | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
| Corporate office main lobby | Serves as primary visitor greeting point for medium to large company entrances | |
|---|---|---|
| Hotel welcome entrance area | Functions as check-in and concierge counter for upscale boutique or business hotels | |
| Medical/dental clinic front desk | Provides patient check-in and administrative workspace for clinical reception areas | |
| High-end retail/salon reception | Acts as transaction and greeting counter for premium retail, beauty or wellness spaces | |
| 2-person reception staffing | Supports two full-time reception staff with dual cable access for workstations | |
| Modern minimalist interior schemes | Coordinates with white, monochrome or contemporary styled spaces with linear accent lighting | |
| Polished hard-floor installations | Works with marble, tile or polished concrete lobby floors via adjustable leveling feet |
EU Market Access Requirements* EN Standards
| EN 527-2:2002+A1:2019 | Office worktables safety and strength requirements, applicable to work surface structural performance | |
|---|---|---|
| EN 60598-1:2021 | Luminaires general safety requirements, applicable to integrated LED lighting components | |
| EN 13722:2004 | Furniture storage units strength and durability requirements, applicable if fitted storage is selected |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Desk products performance standard, applicable to work surface load and durability testing | |
|---|---|---|
| ANSI/BIFMA X5.9-2019 | Storage units performance standard, applicable to drawer and cabinet components if fitted | |
| ANSI/BIFMA e3-2019 | Furniture sustainability standard, applicable to material emissions and environmental claims |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to structural safety and finish quality | |
|---|---|---|
| GB/T 4897.3-2015 | Particleboard for furniture use, applicable to internal carcass panel performance | |
| GB 7000.1-2015 | Luminaires general safety requirements, applicable to integrated LED base lighting | |
| GB/T 17657-2013 | Test methods for wood-based furniture panels, applicable to surface durability and mechanical strength | |
| GB 18584-2001 | Limit of harmful substances in wooden furniture, applicable to formaldehyde emission limits |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to structural safety and finish quality; 2. GB/T 4897.3-2015: Particleboard for furniture use, applicable to internal carcass panel performance; 3. GB 7000.1-2015: Luminaires general safety requirements, applicable to integrated LED base lighting; 4. GB/T 17657-2013: Test methods for wood-based furniture panels, applicable to surface durability and mechanical strength; 5. GB 18584-2001: Limit of harmful substances in wooden furniture, applicable to formaldehyde emission limits; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
