PRODUCT MODULE 01 / 06

Physical Dimensions

Automatic mm / inch conversion · Core engineering specifications

Data source: Structured from factory data; final measured values prevail.

Overall dimensions (W × D × H)	1830 × 900 × 610 mm
Internal soaking basin length	1730 mm
Internal soaking basin width	830 mm
Basin soaking water depth	460 mm
Rim width (flat mounting edge)	100 mm
Center drain outlet diameter	50 mm
Floor clearance under tub base	20 mm
Faucet fixture height above rim	180 mm
Base contact footprint length	1200 mm
Primary Component Thickness	40 mm according to load-bearing role
Hardware / Moving-part Clearance	5 mm operating clearance

PRODUCT MODULE 02 / 06

Weight, Load & Performance

Net weight / load capacity / users / durability

Data source: Product performance data; verify exact test conditions before procurement.

Net product weight	168 kg
Maximum fill water capacity	360 L
Recommended maximum user weight	150 kg
Surface wear resistance rating	4000 abrasion cycles
Thermal heat retention duration	60 minutes
Product structural warranty period	25 years
Available finish color count	3
Reference Static Load	150 kg depending on category
Moving-part Durability Reference	Acceptance target 50000 cycles
Recommended Procurement Warranty	Structure 5 years; hardware 3 years

PRODUCT MODULE 03 / 06

Materials & Structure

Core acceptance fields · Panels / hardware / frame / upholstery

Data source: Subject to the factory material list and inspection report.

Tub body construction	80% natural mineral powder + 20% PMMA resin solid surface
Surface finish coating	High-gloss UV-cured gel coat, 0.8mm thickness
Rim-mounted faucet body	Brass core with matte white powder coating
Drain waste assembly	Chrome-plated brass click-clack pop-up drain
Internal reinforcement layer	Fiberglass-reinforced resin backing, 8mm thickness
Base contact padding	Non-slip EPDM rubber foot pads, 5mm thickness
Water supply connection lines	304 stainless steel braided flexible hoses
Primary Connector Specification	Reference M6-M10 with at least 2 fixing points at major joints
Reference Finish / Color Count	Recommended 6finish options

PRODUCT MODULE 04 / 06

Functions & Adjustment

Adjustment / rotation / tilt / mobility / storage features

Data source: Functional configuration; the supplier specification prevails.

Installation method	Freestanding above-floor installation, no wall anchoring required
Drain operation	Click-clack pop-up drain activated by foot press
Faucet function	Single-lever rim-mounted mixer for hot/cold water flow control
Overflow protection	Concealed internal overflow to prevent overfill
Surface maintenance	Non-porous seamless surface allows stain removal and scratch repair
Load bearing design	Reinforced curved base supports static fill load plus two adult users
Plumbing compatibility	Compatible with standard above-floor rough-in drain connections
Reference Adjustment / Operating Range	100 mm or 120° where applicable

PRODUCT MODULE 05 / 06

Packaging & Logistics

Verified carton / gross weight / assembly / loading data

Data source: Reference for export quotations and container planning.

Reference Package Count	1 set / 2 cartons
Reference Assembly Time	40 minutes per set
Reference Packaging Volume	0.8 m³/set
Reference Packaged Gross Weight	120 kg/set

PRODUCT MODULE 06 / 06

Applications & Usage

Recommended spaces / users / usage modes

Data source: Recommended applications based on product form and category.

Luxury residential master bathroom	Freestanding design serves as focal point for high-end residential bath spaces
Upscale hotel guest suite bathroom	Durable solid surface material withstands high-frequency commercial guest use
Boutique resort villa soaking space	Deep soaking basin supports immersive relaxation for resort guest experiences
High-end residential show home installation	Sculptural silhouette enhances premium interior design presentation for property marketing
Freestanding open-plan bathroom layout	Symmetrical tapered form works for central room placement without wall adjacency

STANDARD S1

EU Market Entry Requirements * EN Standards

EU Market Access Requirements* EN Standards

EN 14516:2018	Baths for domestic use – Functional requirements and test methods
EN 274:2002	Waste fittings for sanitary appliances – Test methods and requirements
EN 198:2008	Sanitary tapware – General technical specification for single valves

STANDARD S3

Standards Applicable to China-Market Projects * GB Standards

Standards applicable to China-market projects

GB 6952-2015	Sanitary ware performance and safety requirements for bathtubs
GB/T 38150-2019	Specification for solid-surface sanitary ware products
GB 25501-2010	Water efficiency rating and test methods for sanitary fixtures

Standardized tender description text

This product must meet the following technical requirements:
1. GB 6952-2015: Sanitary ware performance and safety requirements for bathtubs;
2. GB/T 38150-2019: Specification for solid-surface sanitary ware products;
3. GB 25501-2010: Water efficiency rating and test methods for sanitary fixtures;
Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.

GENERATED EXPORTS

Ready-to-use export tools

Export data is generated from the current published product record.

Technical Report PDF

Directly download an English report in metric or imperial units.

PDF · FB-BOAT-1830-WHT

Complete Parameter Workbook

Download all product information and parameter modules in English.

XLSX · FB-BOAT-1830-WHT

International Listing Template

English title, specifications, materials, standards and purchasing fields.

XLSX · LISTING

Customs Declaration Data

Prepare customs description, material, usage, dimensions and declaration elements.

CUSTOMS · FB-BOAT-1830-WHTOpen Export Tool

Quick Actions

Post an RFQ

Product Description

The Boat-Shaped White Freestanding Soaking Bathtub with Rim-Mounted Faucet (model FB-BOAT-1830-WHT) is a refined unbranded freestanding soaking unit designed to balance sculptural visual appeal and reliable functional performance. Its silhouette follows a smooth, symmetrical tapered boat-like form, finished in a seamless high-gloss white that creates a polished focal point in open bathroom layouts. The unit features a 100mm flat wide rim that holds its integrated faucet fixture, positioned to sit 180mm above the tub rim, and includes 20mm of floor clearance beneath its curved reinforced base. Four non-slip EPDM rubber foot pads line the base contact points to protect flooring and hold the tub stable once positioned. The tub body is constructed from a solid surface composite of 80% natural mineral powder and 20% PMMA resin, backed by an 8mm fiberglass-reinforced resin layer for structural rigidity. Its surface is coated in a 0.8mm high-gloss UV-cured gel coat, delivering a non-porous seamless finish that supports simple stain removal and targeted scratch repair. The rim-mounted faucet uses a single-lever mixer for seamless hot and cold water flow control, built with a brass core finished in matte white powder coating, paired with chrome-plated brass click-clack pop-up drain and 304 stainless steel braided flexible water supply hoses. The drain operates via foot press activation, and a concealed internal overflow prevents accidental overfill during use. The tub supports a maximum fill capacity of 360L, with a soaking water depth of 460mm, and its reinforced curved base is engineered to support static fill load plus two adult users, with a recommended maximum user weight of 150kg. The surface carries a wear resistance rating of 4000 abrasion cycles, and delivers 60 minutes of thermal heat retention for comfortable soaking. This model is suited for a range of premium spaces, including luxury residential master bathrooms, upscale hotel guest suites, boutique resort villa soaking areas, high-end residential show homes, and open-plan freestanding bathroom layouts where central placement without wall adjacency is desired. The freestanding above-floor installation requires no wall anchoring, and is compatible with standard above-floor rough-in drain connections. For procurement planning, note the unit ships as one set across two cartons, with a reference assembly time of 40 minutes per set. The product carries a 25-year structural warranty. While listed in white, the line offers 3 available finish colors, with 6 total recommended finish options for project specification flexibility. Fixing points follow M6-M10 connector standards with at least 2 anchor points at major joints, and the integrated 50mm center drain aligns with common residential and commercial rough-in configurations.

Boat-Shaped White Freestanding Soaking Bathtub with Rim-Mounted Faucet Specifications
