Automatic mm / inch conversion · Core engineering specifications
| Overall assembled dimensions | 2400 x 800 x 1100 mm | |
|---|---|---|
| Staff work surface height | 750 mm | |
| Front visitor-facing modesty panel height | 1100 mm | |
| Countertop thickness | 25 mm | |
| Edge band thickness | 2 mm | |
| Knee clearance height under work surface | 680 mm | |
| Knee clearance depth under work surface | 450 mm | |
| Frosted translucent accent panel thickness | 10 mm | |
| Rounded front corner radius | 80 mm | |
| Cable grommet diameter | 80 mm | |
| LED strip mounting channel width | 12 mm | |
| Adjustable foot height adjustment range | 15 mm | |
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| Countertop uniform static load capacity | 150 kg | |
|---|---|---|
| Total unit net weight | 180 kg | |
| Recommended maximum reception staff capacity | 2 | |
| Drawer slide load rating (if fitted) | 45 kg | |
| Drawer slide cycle rating | 50000 cycles | |
| Door hinge cycle rating | 100000 cycles | |
| Surface abrasion resistance | 2000 cycles | |
| Standard product warranty | 5 years | |
| Available color finish options | 3 | |
| Top Static Load Reference | 150 kg uniformly distributed |
Core acceptance fields · Panels / hardware / frame / upholstery
| Countertop | 12mm thick acrylic solid surface with seamless thermoformed edges | |
|---|---|---|
| Front modesty panel | 18mm thick MDF core with matte white polyurethane paint finish | |
| Side accent panel | 10mm thick frosted translucent tempered resin panel | |
| Internal support frame | 18mm thick moisture-resistant plywood substrate | |
| Accent lighting | 24V low-voltage cool blue LED strip with aluminum mounting channel | |
| Leveling feet | 30mm diameter nylon-padded adjustable steel feet | |
| Hardware fittings | Zinc-plated steel screws, brackets and connector hardware | |
| Surface protection film | PET protective film applied to all finished surfaces pre-shipment | |
| Optional storage cabinet carcass | 15mm thick MDF with matching white laminate finish | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel |
Adjustment / rotation / tilt / mobility / storage features
| LED accent lighting | Recessed cool blue LED strip along frosted panel base with manual on/off switch | |
|---|---|---|
| Cable management | Dual 80mm desk grommets with under-desk cable tray to route power and data cables | |
| Leveling adjustment | Rotating adjustable feet at all base corners to compensate for uneven lobby flooring | |
| Modesty privacy | Full-height continuous front panel blocks all view of staff legs and under-desk items from visitor approach | |
| Storage compatibility | Pre-drilled mounting points for optional under-desk drawers and keyboard trays | |
| Customization capability | Length, LED color and storage configuration can be modified per lobby layout | |
| Work surface access | Continuous rear staff-side edge allows seated access along full length of counter | |
| Seating compatibility | Designed for use with standard 520 mm seat height office task chairs | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
| Corporate office entry lobbies | Provides branded visitor greeting point with concealed staff work area | |
|---|---|---|
| 2-person reception teams | Long continuous work surface supports two adjacent computer workstations | |
| Modern minimalist commercial interiors | Matte white finish and soft rounded corners suit contemporary office design | |
| High-traffic visitor environments | Durable solid surface top resists scratches and stains from daily guest interaction | |
| Professional services firm offices | Polished illuminated front panel presents premium brand image to clients | |
| Reception areas with hard flooring | Integrated adjustable feet allow stable placement on concrete or polished stone floors |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Office work tables safety and strength requirements, applicable to staff work surface | |
|---|---|---|
| EN 14749:2016 | Domestic and non-domestic storage units safety requirements, applicable to optional under-desk storage | |
| EN 62471:2008 | Photobiological safety for LED lighting, applicable to integrated accent light strips |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Desk products performance standard, applicable for static load and durability testing | |
|---|---|---|
| ANSI/BIFMA X5.9-2019 | Storage units performance standard, applicable to optional drawer and cabinet components | |
| ANSI/BIFMA e3-2020 | Furniture sustainability standard, applicable for material emissions and corporate social responsibility requirements |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to panel structural components | |
|---|---|---|
| GB/T 35607-2017 | Green product assessment standard for furniture, applicable for low-VOC finish requirements | |
| GB 7000.201-2008 | Safety requirements for fixed general-purpose luminaires, applicable to integrated LED lighting | |
| GB/T 19995.2-2005 | Tempered glass safety requirements, applicable if frosted glass panels are specified |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to panel structural components; 2. GB/T 35607-2017: Green product assessment standard for furniture, applicable for low-VOC finish requirements; 3. GB 7000.201-2008: Safety requirements for fixed general-purpose luminaires, applicable to integrated LED lighting; 4. GB/T 19995.2-2005: Tempered glass safety requirements, applicable if frosted glass panels are specified; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
