Physical Dimensions
Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall dimensions (W × D × H) | 2400 × 1000 × 760 mm | |
|---|---|---|
| Desktop thickness | 20 mm | |
| Modesty panel height | 620 mm | |
| Knee clearance height | 730 mm | |
| Knee clearance width | 1200 mm | |
| Side return height above desktop | 80 mm | |
| Rounded plinth base height | 50 mm | |
| Front work surface edge radius | 800 mm | |
| PVC edge banding thickness | 2 mm | |
| Integrated light strip width | 20 mm | |
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Weight, Load & Performance
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Product net weight | 120 kg | |
|---|---|---|
| Desktop static load capacity | 150 kg | |
| Scratch resistance rating | 3 H | |
| Stain resistance performance | Grade 5 | |
| Maximum recommended user count | 1 | |
| Surface wear cycle rating | 10000 cycles | |
| Integrated light strip service life | 50000 hours | |
| Manufacturer warranty period | 5 years | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles |
Materials & Structure
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Desktop | 20mm glossy white acrylic solid surface (Corian-style) | |
|---|---|---|
| Front modesty panel | 18mm matching white solid surface panel | |
| Plinth base | 15mm reinforced composite frame with matte white finish | |
| Base lighting strip | 24V dimmable LED strip with frosted diffuser | |
| Edge treatment | Seamless thermoformed solid surface edge | |
| Internal support frame | 1.5mm thick powder-coated steel tube framework | |
| Foot pads | Adjustable 20mm diameter nylon leveling glides | |
| Surface finish | High-gloss UV-cured clear top coat | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel | |
| Primary Connector Specification | Reference M6-M8 with at least 2 fixing points per main support |
Functions & Adjustment
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Knee clearance design | Full-height central unobstructed open bay | |
|---|---|---|
| Ambient base lighting | Integrated recessed LED strip along plinth perimeter | |
| Leveling adjustment | Four adjustable floor glides at base corners | |
| Cable management | 80mm diameter hidden cable grommet at desktop rear central position | |
| Surface maintenance | Non-porous seamless solid surface | |
| Freestanding installation | Self-supporting structure with no wall fixing required | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Packaging & Logistics
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Applications & Usage
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Private executive office | Premium statement desk for senior management and leadership workspaces | |
|---|---|---|
| High-end home office | Designer work surface for luxury residential workspaces | |
| Boutique creative studio | Curated workspace for design, consulting or client meeting studios | |
| Executive boardroom ancillary space | Secondary work surface for boardroom preparation or private meeting areas | |
| Matching configuration recommendation | Pair with mid-back white leather executive chair and low-profile floor cable management |
EU Market Entry Requirements * EN Standards
EU Market Access Requirements* EN Standards
| Office furniture structural stability | EN 527:2002 | |
|---|---|---|
| Office work surface dimensions | EN 527:2011 |
North America Purchasing & Inspection Reference * ANSI/BIFMA Standards
US and Canada office-furniture standards
| Office desk performance standard | ANSI/BIFMA X2021 |
|---|
Standards Applicable to China-Market Projects * GB Standards
Standards applicable to China-market projects
| Desktop panel emission standard | GB/T 39600 | |
|---|---|---|
| Desk structural strength standard | GB/T 3324 | |
| Office furniture surface durability | GB/T 4893.4 |
This product must meet the following technical requirements: 1. Desktop panel emission standard: GB/T 39600; 2. Desk structural strength standard: GB/T 3324; 3. Office furniture surface durability: GB/T 4893.4; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
