| Submitted | Field | Original | Note / Status | |
|---|---|---|---|---|
No corrections yet. Use the flag at the end of a row to report an issue. | ||||
Automatic mm / inch conversion · Core engineering specifications
| Overall assembled dimensions | 2200 x 1000 x 1100 mm | |
|---|---|---|
| Countertop working height | 1100 mm | |
| Raised end return length per side | 300 mm | |
| Raised end return height above main counter | 100 mm | |
| Dark gray accent band thickness | 150 mm | |
| Accent band angled notch width | 400 mm | |
| Main front panel height from floor | 850 mm | |
| Countertop thickness | 25 mm | |
| Side panel thickness | 18 mm | |
| Edge band thickness | 2 mm | |
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| Assembled product weight | 68 kg | |
|---|---|---|
| Main countertop static load capacity | 100 kg | |
| Recommended maximum daily user capacity | 2 staff | |
| Laminate surface abrasion resistance | 2000 cycles | |
| Surface stain resistance rating | Grade 4 | |
| Recommended commercial warranty period | 3 years | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles | |
| Top Abrasion Reference | Acceptance target ≥4,000 abrasion cycles or finish-system test |
Core acceptance fields · Panels / hardware / frame / upholstery
| Core substrate panels | 18mm high-density MDF composite | |
|---|---|---|
| Exterior finished surface | Matte white melamine laminate, scratch-resistant and easy-clean | |
| Accent band finish | Dark charcoal gray matte laminate with angled center notch | |
| Countertop surface | 25mm matte white melamine with 2mm PVC edge banding | |
| Raised end returns | Matching matte white laminate MDF with finished edges | |
| Internal support framing | Solid engineered wood blocking at all joint locations | |
| Leveling feet | 6 adjustable black nylon glides, 12mm diameter | |
| Cable grommets (optional) | 60mm diameter plastic desk grommets with brush seal | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel | |
| Primary Connector Specification | Reference M6-M8 with at least 2 fixing points per main support |
Adjustment / rotation / tilt / mobility / storage features
| Standing greeting counter design | 1100mm counter height optimized for standing visitor interaction | |
|---|---|---|
| Dual raised end returns | Short raised wings at both ends contain documents and small counter items | |
| Leveling adjustment system | 6 adjustable nylon glides compensate for uneven flooring with 15mm total adjustment travel | |
| Cable management provision | Optional dual 60mm grommets route power and data cables below counter surface | |
| Internal storage compatibility | Optional fixed internal shelf supports office supplies and visitor materials | |
| Easy-clean surface maintenance | Non-porous matte laminate resists stains and wipes clean with standard commercial cleaners | |
| Freestanding installation | No wall anchoring required for stable operation on flat commercial flooring | |
| Edge protection design | 2mm PVC edge banding protects all exposed panel edges from impact damage | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
| Small office main lobby | Compact footprint fits entry areas of 200person offices for visitor greeting | |
|---|---|---|
| Retail boutique checkout counter | Counter height supports transaction processing and product display in small retail spaces | |
| Salon or clinic front desk | Solid front panel hides work clutter while supporting check-in and payment processing | |
| Co-working space entry counter | Accommodates 2reception staff for member check-in and guest greeting | |
| Small business reception area | Low-profile minimalist design suits professional environments without overwhelming entry spaces | |
| School or training center front counter | Durable laminate surface resists scuffs and spills from high-traffic public areas |
EU Market Access Requirements* EN Standards
| EN 12521:2015 | Furniture - Strength, durability and safety for non-domestic tables, applicable to commercial reception loads | |
|---|---|---|
| EN 13722:2004 | Furniture - Test methods for surface resistance to cold liquids, applicable to easy-clean laminate performance | |
| EN 312:2010 | Particleboards and MDF - Specifications, applicable to engineered wood substrate structural requirements |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Desk Products - Safety and performance standard for commercial office tables, applicable to load testing |
|---|
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to panel construction and finish quality | |
|---|---|---|
| GB/T 4893.4-2013 | Surface abrasion resistance test for furniture surfaces, applicable to laminate worktop durability | |
| GB 18584-2001 | Indoor decoration material formaldehyde emission limit, applicable to engineered wood substrate safety |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to panel construction and finish quality; 2. GB/T 4893.4-2013: Surface abrasion resistance test for furniture surfaces, applicable to laminate worktop durability; 3. GB 18584-2001: Indoor decoration material formaldehyde emission limit, applicable to engineered wood substrate safety; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
