Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 2200 x 600 x 1100 mm | |
|---|---|---|
| Staff work surface height | 750 mm | |
| Raised overhang shelf dimensions | 2200 x 200 x 30 mm | |
| Chrome support post diameter | 50 mm | |
| Grey plinth base height | 100 mm | |
| Drawer front face height | 300 mm per drawer, 3 total drawer tiers | |
| Work surface depth | 600 mm | |
| Overhang shelf vertical clearance above worktop | 320 mm | |
| Side panel thickness | 25 mm | |
| Worktop panel thickness | 38 mm | |
| Edge band thickness | 2 mm | |
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| Work surface static load capacity | 150 kg | |
|---|---|---|
| Finish abrasion resistance | 2000 cycles | |
| Recommended maximum concurrent users | 2 staff | |
| Drawer slide operational cycle life | 50000 cycles | |
| Net product weight | 107 kg | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles | |
| Top Abrasion Reference | Acceptance target ≥4,000 abrasion cycles or finish-system test | |
| Recommended Procurement Warranty | Structure 5 years; hardware 3 years; finish 2 years |
Core acceptance fields · Panels / hardware / frame / upholstery
| Main cabinet body | 18mm thick MDF core with high-gloss white UV-cured lacquer finish | |
|---|---|---|
| Work surface panel | 38mm thick particleboard core with high-gloss white laminate overlay | |
| Raised overhang shelf | 25mm thick MDF with matching high-gloss white finish | |
| Shelf support posts | Chrome-plated polished steel cylindrical posts, 3 paired sets | |
| Recessed plinth base | 18mm thick MDF with matte grey melamine finish | |
| Drawer horizontal trim strips | Polished chrome-finish aluminum accent strips | |
| Drawer slides | Cold-rolled steel ball-bearing full-extension slides | |
| Edge banding | 2mm thick impact-resistant PVC matching white panel finish | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel | |
| Primary Connector Specification | Reference M6-M8 with at least 2 fixing points per main support |
Adjustment / rotation / tilt / mobility / storage features
| Staff-side storage drawers | 3 full-width horizontal drawers aligned with front trim lines, accessible from staff side | |
|---|---|---|
| Raised transaction overhang | 320mm elevated rear shelf supported by 6 chrome posts for visitor interaction and document pass-through | |
| Cable management grommets | 2 x 60mm diameter plastic grommets positioned at work surface rear for power/data routing | |
| Recessed plinth toe kick | 100mm high recessed grey base allowing foot clearance for standing staff | |
| Glossy stain-resistant work surface | Non-porous high-gloss finish that resists water, coffee and ink stains for easy cleaning | |
| Lockable top transaction drawer | Keyed lock on upper drawer for secure storage of cash, keys or visitor documents | |
| Freestanding installation | No wall mounting required, level-adjustable feet concealed in plinth for uneven floor adjustment | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
| Office building lobby | Suitable for main visitor greeting and check-in for corporate offices of 100staff | |
|---|---|---|
| Retail store checkout | Works as a point-of-sale counter with secure transaction drawer and raised display shelf | |
| Hotel front desk | Appropriate for small boutique hotel check-in with document and key storage | |
| Medical clinic reception | Supports patient check-in, document handoff and administrative staff work | |
| Salon/small business front counter | Fits beauty salons, gyms or small service businesses for guest check-in and reception | |
| Recommended companion seating | Pair with 2 low-back guest chairs positioned at front for visitor waiting |
EU Market Access Requirements* EN Standards
| EN 15372:2008+A1:2016 | Applicable for safety, strength and durability of non-domestic office furniture | |
|---|---|---|
| EN 14073-2:2004 | Applicable for storage units used in office environments | |
| EN 13722:2004 | Applicable for surface finish resistance to wear, stains and heat |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Applicable for desk products strength, durability and structural integrity | |
|---|---|---|
| ANSI/BIFMA X5.9-2019 | Applicable for storage units integrated into office workstations |
Standards applicable to China-market projects
| GB/T 3324-2017 | Applicable for general technical requirements of wooden office furniture | |
|---|---|---|
| GB 18584-2001 | Applicable for formaldehyde emission limits for wooden interior furniture | |
| GB/T 4897.3-2003 | Applicable for particleboard used in furniture structural components |
This product must meet the following technical requirements: 1. GB/T 3324-2017: Applicable for general technical requirements of wooden office furniture; 2. GB 18584-2001: Applicable for formaldehyde emission limits for wooden interior furniture; 3. GB/T 4897.3-2003: Applicable for particleboard used in furniture structural components; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
