Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 2400 x 800 x 1100 mm | |
|---|---|---|
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| Total product weight (reference) | 185 kg | |
|---|---|---|
| Glass transaction shelf static load | 50 kg | |
| Work surface static load | 120 kg | |
| Recommended user capacity | 2 receptionists | |
| Structure service life | 8 years | |
| Worktop edge impact resistance | 10 N | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles | |
| Top Abrasion Reference | Acceptance target ≥4,000 abrasion cycles or finish-system test |
Core acceptance fields · Panels / hardware / frame / upholstery
| Front modesty panel | 25mm thick matte grey MDF panel with scratch-resistant laminate | |
|---|---|---|
| Transaction shelf | 10mm thick clear tempered glass with polished edges | |
| Horizontal accent trim | 15mm wide brushed stainless steel trim at base | |
| Internal frame | 40 x 40mm square steel tubing frame | |
| Work surface | 25mm thick high-pressure laminate over particleboard core | |
| Adjustable feet | 30mm diameter nylon leveling feet, 15mm adjustment range | |
| Cable grommets | 60mm diameter plastic desk grommets for cable routing | |
| Edge banding | 2mm thick PVC edge banding matching panel finish | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel | |
| Primary Connector Specification | Reference M6-M8 with at least 2 fixing points per main support |
Adjustment / rotation / tilt / mobility / storage features
| Transaction counter design | Elevated glass shelf separates visitor and staff zones for item exchange | |
|---|---|---|
| Cable management | Built-in rear cable routing channels for monitor and device wiring | |
| Leveling adjustment | Four adjustable base feet compensate for uneven floor surfaces | |
| Privacy modesty panel | Full-height front panel blocks view of lower work area and staff legs | |
| Dual workstation layout | Central work bay accommodates two seated reception staff side-by-side | |
| Flat work surface | Rear work zone provides level space for monitor, keyboard and office supplies | |
| Curved end design | Rounded front ends improve visitor flow and reduce sharp edge hazards | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
| Corporate office lobbies | Provides professional front-of-house welcome point for visitors | |
|---|---|---|
| Hotel reception areas | Curved profile creates an inviting, upscale check-in area | |
| Medical clinic front offices | Glass counter supports patient check-in and document exchange | |
| Salon or studio entrances | Sized to handle client greeting and appointment scheduling | |
| Co-working space entry zones | Dual workstation supports two staff managing member check-ins | |
| Showroom welcome areas | Matte finish and clean lines complement modern product displays |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Office work tables, safety and strength requirements | |
|---|---|---|
| EN 527-2:2016 | Office work tables, dimensional safety requirements | |
| EN 12521:2015 | Furniture strength, durability and safety requirements for non-domestic use |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Desk Products Standard | |
|---|---|---|
| ANSI/BIFMA e3-2019e | Furniture sustainability standard |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture | |
|---|---|---|
| GB/T 3327-2017 | Performance requirements for office desks | |
| GB 18584-2001 | Formaldehyde emission limits for wooden furniture |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture; 2. GB/T 3327-2017: Performance requirements for office desks; 3. GB 18584-2001: Formaldehyde emission limits for wooden furniture; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
