Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions (L x W x H) | 2400 x 800 x 1150 mm | |
|---|---|---|
| Visitor-facing lower counter height | 750 mm | |
| Staff-facing rear work surface height | 1050 mm | |
| Countertop slab thickness | 50 mm | |
| Body panel substrate thickness | 25 mm | |
| Edge banding thickness | 2 mm | |
| Base plinth recess height for LED strip | 100 mm | |
| Front barrier panel height above staff worktop | 100 mm | |
| Return side extension width | 800 mm | |
| Seam gap between joined panels | 1 mm | |
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| Countertop static uniform load capacity | 200 kg | |
|---|---|---|
| Integrated LED strip service life | 30000 hours | |
| Recommended number of concurrent reception staff | 2 | |
| Product net weight | 180 kg | |
| Surface abrasion resistance cycles | 2000 cycles | |
| Drawer slide load rating (if fitted) | 35 kg | |
| Hinge open/close cycle rating (if fitted) | 50000 cycles | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
| Main body substrate | E0-grade MDF engineered wood | |
|---|---|---|
| Visitor-facing front panel | Matte light grey baked lacquer finish | |
| Rear/side barrier panels | Black marble-veined engineered stone or laminate slab | |
| Edge trim | Matching color PVC edge banding | |
| Internal support frame | 1.2mm thick cold-rolled steel square tube | |
| Base plinth lighting | 24V warm white LED strip, aluminum channel housing | |
| Decorative trim strip | 0.8mm thick brushed stainless steel trim | |
| Cable management grommets | 60mm diameter ABS plastic cable ports | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel | |
| Primary Connector Specification | Reference M6-M8 with at least 2 fixing points per main support |
Adjustment / rotation / tilt / mobility / storage features
| Base ambient lighting | Warm white LED strip recessed in plinth, dimmable via wall switch | |
|---|---|---|
| Dual-height work zones | Separate 750mm visitor transaction counter and 1050mm staff standing work surface | |
| Cable management system | Built-in under-counter cable tray with rear access cutouts | |
| Custom logo compatibility | Flat raised rear barrier panel supports illuminated or adhesive company branding | |
| Storage configuration | Optional internal hanging drawer on heavy-duty slides, lockable for valuables | |
| Assembly seam alignment | Precision-cut panel joints with ≤1mm gap for seamless finished appearance | |
| Reversible orientation | Available in left-return or right-return L-shape configuration to fit lobby layouts | |
| Surface protection | Anti-fingerprint matte coating on light panels to reduce visible smudges | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
| Corporate office lobby | Primary use as company reception and guest check-in point for 2staff | |
|---|---|---|
| Hotel front desk | Suitable for boutique hotel check-in and guest service operations | |
| Retail showroom checkout | Adaptable for high-end retail service, transaction and customer greeting | |
| Medical clinic reception | Works for patient check-in and administrative staff workspace separation | |
| Beauty salon service counter | Fits salon greeting, checkout and appointment scheduling functions | |
| Co-working space entrance | Suitable for shared workspace front desk visitor management | |
| Recommended pairing | Combine with matching wall logo panel and waiting area seating for complete lobby |
EU Market Access Requirements* EN Standards
| EN 527-2:2002+A1:2016 | Office worktables safety and strength requirements for work surface performance | |
|---|---|---|
| EN 12521:2015 | Furniture strength, durability and safety for contract non-domestic use | |
| EN 60598-1:2015+A1:2018 | Luminaires general safety requirements for integrated LED components |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to panel substrate construction | |
|---|---|---|
| GB 18580-2017 | Indoor decoration material formaldehyde emission limit, E0 grade panel required | |
| GB 7000.201-2008 | Safety requirements for fixed general purpose luminaires, applicable to integrated LED strip | |
| GB/T 4893.8-2013 | Furniture surface abrasion resistance test method for finish durability verification |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to panel substrate construction; 2. GB 18580-2017: Indoor decoration material formaldehyde emission limit, E0 grade panel required; 3. GB 7000.201-2008: Safety requirements for fixed general purpose luminaires, applicable to integrated LED strip; 4. GB/T 4893.8-2013: Furniture surface abrasion resistance test method for finish durability verification; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
