| Submitted | Field | Original | Note / Status | |
|---|---|---|---|---|
No corrections yet. Use the flag at the end of a row to report an issue. | ||||
Automatic mm / inch conversion · Core engineering specifications
| overall dimensions | 2400 x 900 x 1100 mm | |
|---|---|---|
| upper counter front panel height | 750 mm | |
| lower illuminated base tier height | 350 mm | |
| countertop thickness | 50 mm | |
| front panel material thickness | 18 mm | |
| base LED light strip recess depth | 20 mm | |
| end cap radius | 450 mm | |
| staff side knee clearance height | 700 mm | |
| staff work surface depth | 600 mm | |
| LED strip overhang from front facade | 30 mm | |
| edge band thickness | 2 mm | |
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| countertop static load capacity | 800 kg | |
|---|---|---|
| net product weight | 260 kg | |
| recommended number of concurrent reception staff | 2 | |
| surface scratch resistance rating | 2H pencil hardness | |
| LED strip rated lifespan | 50000 hours | |
| internal storage shelf static load | 50 kg | |
| surface stain resistance level | Grade 5 | |
| structural service life | 10 years | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
| upper counter and front facade | 18mm ENF-grade high-density MDF core with high-gloss baked white lacquer finish | |
|---|---|---|
| lower illuminated base tier | 18mm MDF core with matching high-gloss white lacquer finish | |
| internal structural frame | 1.2mm thick cold-rolled steel frame with 80μm anti-corrosion powder coating | |
| countertop working surface | 50mm thick lacquered MDF with seamless rounded edges | |
| base accent lighting | 24V IP20 warm white recessed LED strip with frosted diffuser | |
| internal storage components | 15mm thick plywood shelves with white melamine finish | |
| floor contact base pads | 5mm thick non-slip rubber pads to protect polished flooring | |
| seam treatment | UV-cured lacquer seam filling with ≤0.5mm gap tolerance | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel | |
| Primary Connector Specification | Reference M6-M8 with at least 2 fixing points per main support |
Adjustment / rotation / tilt / mobility / storage features
| integrated base LED lighting | Recessed warm white strip casts soft ambient glow onto floor, operates with wall-connected on/off switch | |
|---|---|---|
| handleless closed front facade | Continuous solid curved panel conceals internal structure and storage from visitor view | |
| hidden rear cable management | 60mm diameter cable grommets and under-top steel cable tray with 10kg load capacity route power and data cables | |
| internal rear storage access | Concealed hinged rear access doors provide storage for office supplies and visitor materials, 100000 hinge cycle rating | |
| floor level adjustment | Integrated adjustable feet with 15mm adjustment range compensate for uneven lobby flooring | |
| modular assembly design | Curved sections join with concealed bolt connections for on-site installation without visible exterior fasteners | |
| easy-clean surface | Non-porous high-gloss lacquer surface wipes clean with standard non-abrasive disinfectants for high-traffic use | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
| corporate office lobbies | Visitor-facing greeting counter for company reception areas, high-gloss finish matches modern office interior design | |
|---|---|---|
| hotel and hospitality entrances | Front desk for 5star hotel lobby check-in and guest greeting, curved form provides approachable visitor interface | |
| high-end retail and service spaces | Cash and greeting counter for premium salons, boutiques, medical clinics and bank branches | |
| exhibition and event venues | Registration and information counter for trade shows, event entrances and visitor centers | |
| recommended supporting configuration | Pair with matching minimalist white reception seating and gold-finish lobby decor to coordinate with high-gloss aesthetic | |
| floor compatibility | Suitable for polished marble, tile and hard lobby flooring, rubber base pads prevent floor scratching |
EU Market Access Requirements* EN Standards
| EN 15372:2008+A1:2016 | Safety, strength and durability requirements for non-domestic office furniture | |
|---|---|---|
| EN 12520:2015 | Furniture strength, durability and safety requirements for commercial seating and work surfaces | |
| EN 60598-1:2021 | General safety requirements for luminaires, applicable to integrated LED lighting systems | |
| EN 312:2010 | Performance requirements for wood-based particleboard panels used in furniture |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Performance standard for desk products, applicable for work surface load and durability testing | |
|---|---|---|
| ANSI/BIFMA e3-2019 | Furniture sustainability standard, applicable for material emissions and environmental compliance |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to lacquered wood-based board structural components | |
|---|---|---|
| GB/T 4897.3-2003 | Particleboard for furniture use, applicable for high-density wood-based core material verification | |
| GB 7000.1-2015 | General safety requirements for luminaires, applicable to integrated base LED lighting components | |
| GB 18580-2017 | Formaldehyde emission limits for wood-based panels, applicable for indoor air quality compliance |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to lacquered wood-based board structural components; 2. GB/T 4897.3-2003: Particleboard for furniture use, applicable for high-density wood-based core material verification; 3. GB 7000.1-2015: General safety requirements for luminaires, applicable to integrated base LED lighting components; 4. GB 18580-2017: Formaldehyde emission limits for wood-based panels, applicable for indoor air quality compliance; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
