Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 2400 x 600 x 1050 mm | |
|---|---|---|
| Work surface height | 750 mm | |
| Front facade total height | 1050 mm | |
| Knee clearance height under worktop | 680 mm | |
| Knee clearance depth under worktop | 450 mm | |
| Work surface thickness | 25 mm | |
| Front facade panel thickness | 18 mm | |
| Edge banding thickness | 2 mm | |
| LED light strip width | 20 mm | |
| Curved front arc angle | 30 degrees | |
| Adjustable foot height adjustment range | 15 mm | |
| Cable grommet diameter | 80 mm | |
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| Work surface static load capacity | 150 kg | |
|---|---|---|
| Total unit net weight | 120 kg | |
| Recommended user capacity | 2 reception staff | |
| LED strip operational lifespan | 50000 hours | |
| High-gloss paint surface hardness | 3H | |
| Surface abrasion resistance rating | 2000 cycles | |
| Product warranty period | 3 years | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
| Structural core panels | 18mm thick E1-grade high-density MDF | |
|---|---|---|
| Work surface top panel | 25mm thick E1-grade MDF substrate | |
| Exterior finish | High-gloss baked white water-based paint | |
| Integrated lighting | 24V recessed LED strip with frosted diffuser | |
| Leveling feet | 10mm diameter chrome-plated steel adjustable feet | |
| Internal support frame | 1.2mm thick powder-coated square steel tubing | |
| Edge banding | 2mm thick matching white PVC edging | |
| Cable management components | ABS plastic grommets and galvanized steel cable tray | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel | |
| Primary Connector Specification | Reference M6-M8 with at least 2 fixing points per main support |
Adjustment / rotation / tilt / mobility / storage features
| Integrated mid-facade LED lighting | Stepped white light strip with hardwired power connection, 4000K neutral white color temperature | |
|---|---|---|
| Cable management system | Two rear work surface grommets with under-desk cable tray to route power and data cables | |
| Floor leveling adjustment | Four corner adjustable feet to compensate for 15mm of uneven floor height | |
| Workstation layout | Dual-position work area designed to support two monitors and two staff workstations | |
| Visitor-facing privacy design | 1050mm total front height to block view of under-desk clutter from lobby | |
| Branding surface compatibility | Flat upper front facade panel supports custom adhesive or illuminated corporate logo placement | |
| Storage compartment access | Rear-facing under-desk cabinet space for office supplies and equipment | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
| Office lobby reception zones | Ideal for corporate entry areas to greet visitors and process visitor check-in | |
|---|---|---|
| Medical and aesthetic clinic front desks | Suitable for clinic reception areas requiring clean, modern, easy-to-clean surfaces | |
| Retail boutique checkout counters | Adaptable for high-end retail stores as a checkout and customer service counter | |
| 100-300 sqm small to mid-sized office spaces | Scaled appropriately for small company entry areas without overwhelming lobby space | |
| Hotel and service apartment front counters | Usable as small boutique hotel check-in desk for low-to-mid volume guest traffic | |
| Co-working space entry points | Suitable for co-working facility reception to manage member check-in and guest services |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Office work tables safety and strength requirements, applicable for work surface load performance | |
|---|---|---|
| EN 15372:2016 | Furniture durability and stability for non-domestic seating and tables, applicable for commercial lobby use |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable for panel structural integrity and finish quality | |
|---|---|---|
| GB 18580-2017 | Formaldehyde emission limits for wood-based panels, applicable for MDF substrate E1 grade compliance | |
| GB/T 4893.4-2013 | Surface abrasion resistance test for furniture finishes, applicable for high-gloss paint durability |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable for panel structural integrity and finish quality; 2. GB 18580-2017: Formaldehyde emission limits for wood-based panels, applicable for MDF substrate E1 grade compliance; 3. GB/T 4893.4-2013: Surface abrasion resistance test for furniture finishes, applicable for high-gloss paint durability; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
