Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 2400 x 760 x 1100 mm | |
|---|---|---|
| Low front reception edge height | 750 mm | |
| Raised rear work counter height | 1100 mm | |
| Work counter depth | 320 mm | |
| Front facade panel thickness | 12 mm | |
| Wood veneer front panel thickness | 3 mm | |
| Edge band radius (rounded corners) | 50 mm | |
| Internal knee clearance height | 700 mm | |
| Knee clearance depth from front facade | 600 mm | |
| Stainless steel kick plate height | 100 mm | |
| LED light strip recess width | 20 mm | |
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| Top surface static load capacity | 150 kg | |
|---|---|---|
| Internal drawer slide load rating | 35 kg per drawer | |
| Drawer slide cycle rating | 50000 open/close cycles | |
| Door hinge cycle rating | 80000 open/close cycles | |
| LED ambient light operational lifespan | 30000 hours | |
| Product net weight reference | 180 kg | |
| Surface abrasion resistance | 2000 cycles | |
| Recommended reception staff capacity | 2 people | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
| Exterior white cladding | 12mm thick solid surface (artificial stone) | |
|---|---|---|
| Central front panel | 3mm thick light oak wood veneer on MDF substrate | |
| Internal support frame | 1.5mm thick welded square steel tubing | |
| Internal substrate panels | 12mm thick flame-retardant plywood | |
| Floor kick plate | 1.2mm thick 304 stainless steel with brushed finish | |
| Ambient light component | 24V low-voltage linear LED strip recessed in upper trim | |
| Surface edge treatment | Seamless polished rounded edge trim | |
| Internal cable channel | PVC cable management tray mounted below work surface | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel | |
| Primary Connector Specification | Reference M6-M8 with at least 2 fixing points per main support |
Adjustment / rotation / tilt / mobility / storage features
| Ambient LED lighting | Recessed upper front linear light with integrated driver | |
|---|---|---|
| Cable management system | Hidden internal channels with 60mm diameter grommets | |
| Storage configuration | Internal lockable drawer and open shelf compartments | |
| Staff work surface | Stepped raised rear counter with matte non-glare finish | |
| Visitor transaction surface | Low front curved ledge | |
| Installation method | Floor-standing freestanding unit with adjustable leveler feet | |
| Customization support | Modular construction allows length, color, and accessory customization | |
| Logo mounting provision | Flat raised upper panel reserved for custom company logo placement | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
| Corporate office lobby | Asymmetrical modern design creates professional first impression for visiting clients | |
|---|---|---|
| Retail store reception | Curved low-profile front supports checkout and customer greeting operations | |
| Beauty salon/medical clinic | Smooth non-porous surface allows easy sanitization between visitor interactions | |
| Hotel lobby check-in | Dual-staff sizing supports peak guest check-in and concierge service | |
| Co-working space entrance | Integrated lighting and branding provision fits flexible shared office reception needs |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Office work tables safety and strength requirements | |
|---|---|---|
| EN 12521:2015 | Commercial furniture durability requirements for high-traffic use | |
| EN 60598-1:2015 | Luminaire general safety requirements |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Desk products performance and safety standard | |
|---|---|---|
| ANSI/BIFMA e3-2019 | Furniture sustainability standard for material emissions |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture | |
|---|---|---|
| GB 18584-2001 | Indoor decoration material formaldehyde emission limit | |
| GB 7000.1-2015 | General safety requirements for luminaires | |
| GB/T 10357.1-2013 | Furniture mechanical performance test for tables |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture; 2. GB 18584-2001: Indoor decoration material formaldehyde emission limit; 3. GB 7000.1-2015: General safety requirements for luminaires; 4. GB/T 10357.1-2013: Furniture mechanical performance test for tables; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
