Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 2400 x 600 x 1100 mm | |
|---|---|---|
| Staff work surface height | 750 mm | |
| Raised visitor counter height | 1100 mm | |
| Raised counter depth | 300 mm | |
| Staff work surface depth | 600 mm | |
| Plinth base height | 100 mm | |
| Stainless steel support post diameter | 50 mm | |
| Modesty panel height | 1000 mm | |
| Curved end radius | 300 mm | |
| Decorative recessed groove width | 5 mm | |
| Vase recess cutout diameter | 120 mm | |
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| Worktop static load capacity | 150 kg | |
|---|---|---|
| Drawer slide load rating (if fitted) | 25 kg | |
| Drawer slide cycle rating | 50000 cycles | |
| Door hinge cycle rating | 80000 cycles | |
| Recommended staff capacity | 2 | |
| Net weight range | 120 kg | |
| Surface scratch resistance rating | 2H | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
| Body and modesty panel | 25 mm thick E1-grade high-density MDF with matte grey baked lacquer finish | |
|---|---|---|
| Raised transaction countertop | 25 mm thick E1-grade MDF with high-gloss white baked lacquer finish | |
| Counter support posts | Mirror polished 304 stainless steel cylindrical tubes | |
| Work surface edge banding | 2 mm thick matching PVC edge banding | |
| Plinth base | 18 mm thick MDF with light grey matte lacquer finish | |
| Internal cabinet panels | 18 mm thick E1-grade particleboard with melamine laminate | |
| Hardware components | Zinc alloy drawer pulls and steel screws with chrome plating | |
| Cable management grommets | ABS plastic 60 mm diameter desk grommets with brush inserts | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel | |
| Primary Connector Specification | Reference M6-M8 with at least 2 fixing points per main support |
Adjustment / rotation / tilt / mobility / storage features
| Dual-level work surface | Lower 750mm surface for staff seated work, raised 1100mm counter for visitor transactions | |
|---|---|---|
| Full front modesty panel | Solid panel running full desk height to conceal staff legs, equipment and lower storage from visitor view | |
| Integrated cable management | Concealed internal cable channels and 60mm grommets route power/data cords from work surface to floor | |
| Storage provision | Internal compartments for hanging drawers, mobile pedestal and file storage under staff work surface | |
| Raised counter decorative recess | Built-in circular cutout on curved end to hold floral arrangements or branding displays | |
| Curved end safety design | Smooth rounded right end eliminates sharp corners in high-traffic lobby areas | |
| Adjustable floor glides | M8 threaded glides under plinth base compensate for uneven floor surfaces up to 15mm | |
| Customizable layout option | Curved end can be specified on left or right side to match lobby floor plans | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
| Corporate office lobby | Suitable for main entrance reception areas accommodating 2 staff with visitor transaction space | |
|---|---|---|
| Hotel front check-in | Raised counter supports guest check-in, key handover and document exchange at standing height | |
| Beauty salon and clinic reception | Smooth easy-clean lacquer surface and curved end support customer greeting and appointment check-in | |
| Small service center reception | 2.4m length fits compact entry spaces with integrated storage for office supplies | |
| Co-working space entry | Dual-staff layout supports member check-in, package handling and visitor management |
EU Market Access Requirements* EN Standards
| EN 527-2:2002+A1:2019 | Office work tables safety and strength requirements, applicable to staff work surface structural performance | |
|---|---|---|
| EN 14073-2:2004 | Office storage furniture safety requirements, applicable to integrated internal cabinet components | |
| EN 13722:2004 | Furniture test for surface resistance to dry heat, applicable to lacquered countertop performance verification |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to panel reception desk dimensional and structural tolerance testing | |
|---|---|---|
| GB 18580-2017 | Formaldehyde emission limit for wood-based panels, required E1 grade emission for indoor commercial furniture | |
| GB/T 4893.8-2013 | Surface abrasion resistance test for furniture finishes, applicable to lacquered worktop durability | |
| GB/T 10357.1-2013 | Furniture mechanical performance test for tables, applicable to worktop static and impact load verification |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to panel reception desk dimensional and structural tolerance testing; 2. GB 18580-2017: Formaldehyde emission limit for wood-based panels, required E1 grade emission for indoor commercial furniture; 3. GB/T 4893.8-2013: Surface abrasion resistance test for furniture finishes, applicable to lacquered worktop durability; 4. GB/T 10357.1-2013: Furniture mechanical performance test for tables, applicable to worktop static and impact load verification; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
