Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 2000 x 430 x 590 mm | |
|---|---|---|
| Top surface thickness | 15 mm | |
| Floor clearance under unit | 150 mm | |
| Central raised back panel dimensions | 1200 x 300 x 250 mm | |
| Side storage cabinet internal dimensions (per unit) | 750 x 380 x 350 mm | |
| Adjustable interior shelf thickness | 15 mm | |
| Cable management opening diameter | 60 mm | |
| Ventilation slot width per storage compartment | 10 mm | |
| Door panel thickness | 18 mm | |
| Carcass Panel Thickness | 25 mm | |
| Back Panel Thickness | 9 mm | |
| Door / Drawer Front Thickness | 22 mm | |
| Shelf Thickness | 25 mm |
Net weight / load capacity / users / durability
| Top surface static load capacity | 100 kg | |
|---|---|---|
| Maximum supported TV size | 85 inches | |
| Unit net weight | 55 kg | |
| Soft-close hinge cycle rating | 80000 cycles | |
| Drawer slide cycle rating (if equipped) | 50000 cycles | |
| LED strip operational lifespan | 30000 hours | |
| Shelf Distributed Load | 30 kg/shelf | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Angle / Life | 165°; 80000 cycles | |
| Anti-tip Fixing Reference | Products above 1200 mm should use at least 2 wall fixing points |
Core acceptance fields · Panels / hardware / frame / upholstery
| Lower cabinet carcass | E1 grade MDF with matte gray scratch-resistant laminate finish | |
|---|---|---|
| Top surface and central back panel | Engineered wood substrate with dark wood grain veneer/lamiante | |
| Block support feet | Engineered wood with matching dark wood grain finish | |
| Cabinet door hinges | Cold-rolled steel with soft-close hydraulic damping | |
| Integrated LED lighting strips | Low-voltage SMD LED strips with warm white output | |
| Interior adjustable shelves | 15mm thick engineered wood with matching laminate finish | |
| Back panel (non-display) | 3mm thick hardboard with moisture-resistant coating | |
| Cable management grommets | ABS plastic with brushed finish | |
| Edge Band Thickness | 2 mm | |
| Primary Connector Specification | Reference M6-M8 cam/bolt fittings with at least 2 fixing points at major joints | |
| Reference Finish / Color Count | Recommended 6finish options |
Adjustment / rotation / tilt / mobility / storage features
| Enclosed side storage cabinets | Four soft-closing door compartments for concealed media accessory storage | |
|---|---|---|
| Integrated LED accent lighting | Warm white strips along base and central panel edge for ambient glow | |
| Cable management system | Dual rear grommets route power and AV cords without tangling | |
| Adjustable interior shelves | 3-position height adjustment to accommodate different AV component sizes | |
| Raised central back panel | Acts as media backstop and center channel speaker mounting surface | |
| Passive ventilation slots | Rear cutouts allow heat dissipation for enclosed AV electronics | |
| Rounded edge design | Soft rounded corners on all cabinet volumes to reduce impact injury risk | |
| Block foot dimensions (each) | 120 x 80 x 40 mm | |
| Cable / Vent Opening Reference | 80 mm diameter; recommend 4rear cable/vent openings |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 700× 350 mm/carton according to carcass split | |
| Reference Packaged Gross Weight | 100 kg/set in 3 cartons | |
| Reference Packaging Volume | 0.65 m³/set |
Recommended spaces / users / usage modes
| Living room placement | Position under wall-mounted TVs up to 85 inches for media storage and display | |
|---|---|---|
| Home theater setup | Accommodates AV receivers, game consoles, and center channel speakers on adjustable shelves | |
| Modern minimalist interiors | Matches contemporary, wabi-sabi, and light luxury decor styles with two-tone finish | |
| Bedroom media use | Fits against bedroom walls as a low-profile TV stand with concealed clutter storage | |
| Open-plan living spaces | Ambient underglow provides soft secondary lighting without harsh overhead glare |
EU Market Access Requirements* EN Standards
| EN 312:2010 | Particleboard performance requirements for structural furniture applications | |
|---|---|---|
| EN 14749:2016 | Safety and strength requirements for domestic storage furniture including media units | |
| EN 62471:2008 | Photobiological safety for integrated LED lighting components |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to engineered wood cabinet construction | |
|---|---|---|
| GB 18580-2017 | Formaldehyde emission limits for wood-based panels, required for E1 grade panel verification | |
| GB/T 4897.3-2003 | Particleboard specification for furniture use, applicable to structural panel components |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to engineered wood cabinet construction; 2. GB 18580-2017: Formaldehyde emission limits for wood-based panels, required for E1 grade panel verification; 3. GB/T 4897.3-2003: Particleboard specification for furniture use, applicable to structural panel components; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
