Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 3600 x 800 x 1050 mm | |
|---|---|---|
| Work surface height | 750 mm | |
| Central divider width | 400 mm | |
| Individual work zone width | 1600 mm | |
| Work surface depth | 600 mm | |
| Front facade base kick height | 100 mm | |
| Top front band height | 80 mm | |
| Grey accent strip thickness | 30 mm | |
| Staff knee clearance height | 650 mm | |
| Knee clearance depth per station | 450 mm | |
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| Worktop static uniform load | 200 kg | |
|---|---|---|
| Single drawer slide rated load | 35 kg | |
| Drawer slide cycle rating | 50000 cycles | |
| Hinge open/close cycle rating | 80000 cycles | |
| Recommended user capacity | 2 reception staff | |
| Net weight per assembled unit | 220 kg | |
| Surface scratch resistance rating | 2000 revolutions | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
| Primary structural panels | 25mm thick melamine-faced MDF/particleboard composite | |
|---|---|---|
| Top and base edge trim | 2mm thick PVC edge banding, navy finish | |
| Horizontal accent strips | 1mm thick PVC laminate, grey and navy finish | |
| Cabinet internal shelving | 16mm thick melamine-faced composite panel | |
| Drawer slide hardware | Cold-rolled steel with zinc plating, silent soft-close mechanism | |
| Cabinet hinges | Stainless steel hydraulic soft-close hinges | |
| Cable grommets | 60mm diameter ABS plastic, matching finish | |
| Base leveler feet | 12mm diameter threaded steel with nylon base | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel | |
| Primary Connector Specification | Reference M6-M8 with at least 2 fixing points per main support |
Adjustment / rotation / tilt / mobility / storage features
| Dual independent work zones | Two equal separated work areas split by central navy divider, supporting two staff | |
|---|---|---|
| Lockable under-counter storage | Two lockable drawer units and one cabinet per station for secure document storage | |
| Integrated cable management | Two 60mm cable grommets per work surface leading to under-desk cable tray | |
| Adjustable base leveling | 15mm vertical adjustment range on each foot to compensate for uneven carpeted floors | |
| Visitor-facing solid facade | Full-height closed front panel conceals staff legroom and storage from lobby visitors | |
| Cable tray load capacity | 10 kg | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
| Commercial office lobbies | Suitable for company entry reception areas with high visitor traffic, providing staff greeting workspace | |
|---|---|---|
| Corporate administrative entries | Supports two reception staff handling visitor check-in, delivery coordination and inquiry response | |
| Hotel and service center front counters | Adaptable for front desk use in boutique hotels, medical clinics or service centers, matching modern interior finishes | |
| Co-working space entry points | Works as shared reception counter for multi-tenant office buildings, with separate storage for each staff position | |
| Recommended floor placement | Installed on level carpeted or hard commercial flooring against a feature wall |
EU Market Access Requirements* EN Standards
| EN 527-2:2002+A1:2016 | Office worktables safety and strength requirements, applicable to reception work surfaces | |
|---|---|---|
| EN 14073-2:2004 | Office storage furniture safety requirements for under-counter drawers and cabinets | |
| EN 120:1992 | Wood-based panels formaldehyde content determination, reference for indoor air quality compliance |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Desk products standard, applicable to work surface load and durability testing | |
|---|---|---|
| ANSI/BIFMA X5.9-2019 | Storage units standard, applicable to drawer and cabinet performance requirements |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden office furniture, applicable to panel reception desk structural performance | |
|---|---|---|
| GB 18580-2017 | Formaldehyde emission limits for wood-based panels, required for indoor commercial furniture use | |
| GB/T 4897.3-2015 | Particleboard specification for furniture-grade structural panel components |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden office furniture, applicable to panel reception desk structural performance; 2. GB 18580-2017: Formaldehyde emission limits for wood-based panels, required for indoor commercial furniture use; 3. GB/T 4897.3-2015: Particleboard specification for furniture-grade structural panel components; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
