Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 2400 x 600 x 1050 mm | |
|---|---|---|
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| Unit net weight | 145 kg | |
|---|---|---|
| Work surface static load capacity | 150 kg | |
| Recommended staff capacity | 2 people | |
| Surface abrasion resistance | 2000 cycles | |
| Structure service life | 8 years | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles | |
| Top Abrasion Reference | Acceptance target ≥4,000 abrasion cycles or finish-system test | |
| Recommended Procurement Warranty | Structure 5 years; hardware 3 years; finish 2 years |
Core acceptance fields · Panels / hardware / frame / upholstery
| Main cabinet carcass | 25mm thick E1 grade melamine-faced particle board | |
|---|---|---|
| Raised countertop | 25mm thick white melamine board with polished edge | |
| Front decorative panel | Frosted semi-translucent acrylic base with orange painted geometric inlay | |
| Countertop support posts | Polished 304 stainless steel cylindrical columns | |
| Base plinth trim | Brushed stainless steel kick plate | |
| Cabinet doors | 18mm thick matching white melamine with soft-close hinges | |
| Interior shelves | 18mm thick white melamine adjustable shelves | |
| Cable grommet | ABS plastic round cable port | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel | |
| Primary Connector Specification | Reference M6-M8 with at least 2 fixing points per main support |
Adjustment / rotation / tilt / mobility / storage features
| Built-in storage layout | Left-side closed cabinet with adjustable shelves, under-counter central storage | |
|---|---|---|
| Integrated cable management | Centered desktop grommet with under-desk cable routing channels | |
| Dual-height work surface | Lower 750mm staff work area, raised 1050mm visitor transaction counter | |
| Soft-close door mechanism | Concealed 95-degree opening hinges with damping cushion | |
| Leveling base feet | Adjustable threaded feet under plinth | |
| Freestanding installation | Pre-assembled core structure requiring only countertop attachment | |
| Stain-resistant work surface | Melamine finish that resists common office liquid spills | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
| Corporate office lobbies | Serves as visitor check-in point for 50person small to medium offices | |
|---|---|---|
| Beauty salon and retail reception | Provides check-in and transaction counter for customer-facing service businesses | |
| Hotel front desk auxiliary station | Acts as secondary concierge or check-in support desk in hospitality settings | |
| Medical clinic reception | Supports patient check-in and document processing in outpatient facilities | |
| Open-plan co-working space entry | Functions as member check-in and visitor management point for shared offices |
EU Market Access Requirements* EN Standards
Standards applicable to China-market projects
This product must meet the following technical requirements: 1. Technical standards and test reports must be supplied during tender or purchase confirmation; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
