Automatic mm / inch conversion · Core engineering specifications
| overall dimensions | 1830 x 810 x 1170 mm | |
|---|---|---|
| work surface height from floor | 750 mm | |
| work surface depth | 600 mm | |
| privacy back panel height above work surface | 420 mm | |
| knee well clear width between supports | 1530 mm | |
| knee well clear height under work surface | 700 mm | |
| work surface panel thickness | 38 mm | |
| cable grommet diameter | 60 mm | |
| lower modesty panel height | 700 mm | |
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| work surface distributed static load capacity | 100 kg | |
|---|---|---|
| product net weight | 95 kg | |
| cable grommet cable pass-through capacity | 5 cables | |
| surface scratch resistance rating | 2000 cycles | |
| recommended maximum user weight capacity | 136 kg | |
| laminate surface stain resistance rating | Level 4 | |
| adjustable footpad load rating per pad | 50 kg | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
| work surface substrate | 18mm thick high-density MDF core | |
|---|---|---|
| surface finish | High-gloss white thermofused melamine laminate | |
| end support blocks | Hollow-core MDF construction with matching white laminate cladding | |
| back privacy panel | 18mm thick MDF with matching white laminate | |
| lower modesty panel | 15mm thick MDF with white laminate finish | |
| cable grommet | White ABS plastic with removable cover cap | |
| edge banding | 2mm thick matching white PVC edge banding | |
| base foot pads | Injection-molded nylon adjustable leveling pads | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel | |
| Primary Connector Specification | Reference M6-M8 with at least 2 fixing points per main support |
Adjustment / rotation / tilt / mobility / storage features
| cable management | Single centered 60mm ABS grommet routes power/data cables from desk surface to floor | |
|---|---|---|
| leveling adjustment | Four adjustable nylon foot pads correct uneven floor surfaces up to 10mm height difference | |
| privacy screening | Full-width raised back panel and solid lower modesty panel block staff leg/desk clutter from visitor view | |
| transaction surface | Raised privacy panel top edge forms a flat ledge for document exchange between staff and visitors | |
| assembly design | Flat-pack knock-down construction with cam-lock fasteners for on-site assembly | |
| surface cleaning | Non-porous laminate surface allows wipe-down cleaning with standard office disinfectants | |
| seating orientation | Single open front side allows only one staff member to sit facing incoming visitors | |
| end support block thickness | 150 mm | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
| small office lobby | Compact single-staff footprint fits entryways of small businesses, startups and professional offices | |
|---|---|---|
| medical/dental clinic reception | Easy-clean non-porous surface supports high-traffic patient check-in and sanitization protocols | |
| salon/spa front desk | Minimalist white aesthetic matches modern beauty and wellness space design schemes | |
| retail checkout counter | Stable work surface supports POS terminal, transaction materials and customer greeting | |
| coworking space entry | Clear staff screening and cable management support front-desk member check-in operations | |
| school administration office | Durable laminate surface withstands daily high-volume visitor and student traffic |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Office worktables safety and strength requirements, applicable to desk load and stability testing | |
|---|---|---|
| EN 14073-2:2004 | Office storage furniture safety requirements, applicable to fixed panel structural durability | |
| EN 12521:2015 | Furniture for non-domestic seating/work surfaces, applicable to commercial lobby use durability |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Desk products safety and performance standard, applicable to top load and cycle testing | |
|---|---|---|
| ANSI/BIFMA M7.1-2020 | Furniture emissions standard, applicable to VOC and formaldehyde emission limits for indoor office use |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to desk structural stability and finish quality | |
|---|---|---|
| GB/T 4897.3-2003 | Particleboard/MDF for furniture use, applicable to substrate formaldehyde emission and physical performance | |
| GB 18584-2001 | Indoor decorating and refurbishing materials limit of harmful substances, applicable to formaldehyde content limits |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to desk structural stability and finish quality; 2. GB/T 4897.3-2003: Particleboard/MDF for furniture use, applicable to substrate formaldehyde emission and physical performance; 3. GB 18584-2001: Indoor decorating and refurbishing materials limit of harmful substances, applicable to formaldehyde content limits; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
