Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 2400 x 800 x 1150 mm | |
|---|---|---|
| Front transaction counter height | 1100 mm | |
| Rear staff work surface height | 750 mm | |
| Knee clearance height under work surface | 650 mm | |
| Work surface depth | 600 mm | |
| Decorative dark accent band width | 80 mm | |
| Metal kickplate height | 100 mm | |
| Panel substrate thickness | 25 mm | |
| Edge band thickness | 2 mm | |
| Metal kickplate material thickness | 1.2 mm | |
| Cable grommet diameter | 80 mm | |
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| Total static desk load capacity | 800 kg | |
|---|---|---|
| Work surface uniform static load | 200 kg | |
| Drawer slide static load per drawer | 45 kg | |
| Drawer slide cycle rating | 50000 cycles | |
| Door hinge cycle rating | 80000 cycles | |
| Surface abrasion resistance | 2000 cycles | |
| Recommended user capacity | 2 staff | |
| Net weight reference | 180 kg | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
| Main structural substrate | 18 mm density fiberboard (MDF) | |
|---|---|---|
| Work surface substrate | 25 mm MDF with high-gloss white baked PU paint | |
| Horizontal accent trim | Dark brown wood-grain melamine veneer | |
| Base kickplate | Brushed dark gray cold-rolled steel sheet | |
| Edge treatment | 2 mm thick PVC edge banding matched to panel color | |
| Internal storage components | 18 mm particleboard cabinet frames with soft-close hardware | |
| Cable management components | ABS plastic cable grommets with removable brush inserts | |
| Leveling feet | Nylon base adjustable steel leveling glides | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel | |
| Primary Connector Specification | Reference M6-M8 with at least 2 fixing points per main support |
Adjustment / rotation / tilt / mobility / storage features
| Dual workstation layout | Split work zones for two staff with dedicated monitor and keyboard space | |
|---|---|---|
| Integrated cable management | Dual 80 mm grommets route power and data cables from work surface to floor | |
| Optional lockable drawer storage | Two lockable hanging drawers under staff work surface for office supplies | |
| Adjustable base leveling | Four leveling glides adjust up to 15 mm to compensate for uneven flooring | |
| Visitor-facing transaction surface | Elevated front counter screens staff work area while supporting visitor sign-in | |
| Stain-resistant easy-clean finish | High-gloss coating resists smudges and wipes clean with standard office cleaners | |
| Custom logo mounting surface | Flat upper front panel supports dimensional branded lettering | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
| Corporate office entry lobby | Two-person greeting capacity creates professional first impression for visiting clients and guests | |
|---|---|---|
| Commercial service reception area | Suitable for salon, hotel, clinic, or co-working space front desk check-in operations | |
| Modern open-plan office | Curved high-gloss profile complements contemporary commercial interior design schemes | |
| Small to medium business front office | 2400 mm width fits entry spaces without overwhelming compact reception zones | |
| High-traffic visitor areas | Durable easy-clean finish and kickplate resist wear from daily foot traffic and visitor contact |
EU Market Access Requirements* EN Standards
| EN 527-2:2002+A1:2016 | Office work tables – safety, strength and durability requirements, applies to staff work surface performance | |
|---|---|---|
| EN 14073-2:2004 | Office furniture – storage furniture – safety requirements, applies to integrated drawer and cabinet components | |
| EN 14074:2004 | Office furniture – tables and storage furniture – test methods for strength and durability |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden office furniture, applies to panel construction and finish durability | |
|---|---|---|
| GB 18584-2001 | Indoor decorating and refurbishing materials – limit of harmful substances for wooden furniture, applies to formaldehyde emission limits | |
| GB/T 4897.3-2003 | Particleboard for furniture use, applies to structural substrate performance requirements | |
| GB/T 11718-2009 | Medium density fiberboard for general use, applies to MDF substrate physical property requirements |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden office furniture, applies to panel construction and finish durability; 2. GB 18584-2001: Indoor decorating and refurbishing materials – limit of harmful substances for wooden furniture, applies to formaldehyde emission limits; 3. GB/T 4897.3-2003: Particleboard for furniture use, applies to structural substrate performance requirements; 4. GB/T 11718-2009: Medium density fiberboard for general use, applies to MDF substrate physical property requirements; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
