| Submitted | Field | Original | Note / Status | |
|---|---|---|---|---|
No corrections yet. Use the flag at the end of a row to report an issue. | ||||
Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 2000 x 700 x 1100 mm | |
|---|---|---|
| Work surface height above floor | 1050 mm | |
| Work surface thickness | 25 mm | |
| Front modesty panel height | 850 mm | |
| Horizontal decorative metal strip width | 2000 mm | |
| Metal accent strip thickness | 0.8 mm | |
| Base plinth height | 50 mm | |
| Internal knee clearance height | 700 mm | |
| Internal knee clearance depth | 600 mm | |
| Edge banding thickness | 2 mm | |
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| Work surface static load capacity | 150 kg | |
|---|---|---|
| Integrated drawer slide load rating | 35 kg | |
| Drawer slide cycle durability | 50000 cycles | |
| Door hinge cycle durability | 80000 cycles | |
| Surface stain resistance rating | Grade 5 | |
| Product net weight | 120 kg | |
| Recommended maximum concurrent users | 2 staff | |
| Surface abrasion resistance cycles | 2000 cycles | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
| Main cabinet substrate | E0-grade medium density fiberboard | |
|---|---|---|
| Exterior finish | High-gloss white bake paint | |
| Decorative front accent | Brushed stainless steel strip | |
| Internal support frame | 1.2mm thick cold-rolled steel tube | |
| Work surface top layer | High-pressure laminate overlay | |
| Edge treatment | 2mm thick PVC edge banding | |
| Base plinth | Powder-coated steel leveling base | |
| Hardware components | Zinc-plated steel screws and connectors | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel | |
| Primary Connector Specification | Reference M6-M8 with at least 2 fixing points per main support |
Adjustment / rotation / tilt / mobility / storage features
| Internal storage configuration | 2 lockable drawers and 1 open storage compartment | |
|---|---|---|
| Cable management system | 80mm diameter cable grommets plus under-desk cable tray | |
| Adjustable leveling glides | 15mm height adjustment range on base feet | |
| Work surface equipment capacity | Supports all-in-one computers, printers and reception signage | |
| Front visitor interaction design | Full-height solid modesty panel for staff privacy | |
| Modular assembly design | Knockdown three-section cabinet construction | |
| Optional custom add-on compatibility | Supports integrated USB charging ports and recessed logo panel | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Total shipping gross weight | 145 kg | |
|---|---|---|
| Reference Package Count | 1 set / 2 cartons | |
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
| Commercial office lobby | Suitable for main entrance reception in small to mid-size corporate offices | |
|---|---|---|
| Hotel front check-in area | Appropriate for boutique hotel or service apartment front counters | |
| Beauty salon or studio reception | Fits customer greeting areas in salons, dance studios or creative agencies | |
| Medical clinic check-in station | Suitable for clinic and dental office patient registration areas | |
| Co-working space entry | Designed for shared workspace front desks serving member check-in | |
| Two-staff reception configuration | Optimized for two receptionists working concurrently during peak hours |
EU Market Access Requirements* EN Standards
| EN 527-2:2002+A1:2019 | Office worktables safety and strength requirements | |
|---|---|---|
| EN 12521:2015 | Furniture strength, durability and safety for commercial use | |
| EN 13722:2004 | Furniture surface finish performance test methods |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Desk products performance standard |
|---|
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture | |
|---|---|---|
| GB 18580-2017 | Formaldehyde emission limits for wood-based panels | |
| GB/T 4897.3-2015 | Particleboard specifications for furniture use |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture; 2. GB 18580-2017: Formaldehyde emission limits for wood-based panels; 3. GB/T 4897.3-2015: Particleboard specifications for furniture use; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
Export data is generated from the current published product record.
Directly download an English report in metric or imperial units.
Download all product information and parameter modules in English.
English title, specifications, materials, standards and purchasing fields.
Prepare customs description, material, usage, dimensions and declaration elements.
Open Export Tool
