Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions (main segment + right return) | 2400 x 1800 x 1150 mm | |
|---|---|---|
| Main work surface height (staff side) | 750 mm | |
| Raised front visitor counter height | 1150 mm | |
| Main work surface depth | 600 mm | |
| Return segment depth | 800 mm | |
| Worktop panel thickness | 25 mm | |
| Edge banding thickness | 2 mm | |
| Front privacy panel height | 1000 mm | |
| Chrome support post diameter | 50 mm | |
| Drawer internal height per front drawer bank | 220 mm | |
| Knee clearance height (staff work zone) | 690 mm | |
| Plinth base height | 60 mm | |
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| Product net weight | 160 kg | |
|---|---|---|
| Main worktop static load capacity | 150 kg | |
| Single drawer dynamic load rating | 25 kg | |
| Recommended maximum reception staff capacity | 2 persons | |
| Drawer slide cycle rating | 50000 cycles | |
| Door/drawer hinge cycle rating | 80000 cycles | |
| Laminate surface abrasion resistance | 2000 cycles | |
| Maximum recommended staff occupancy | 2 persons | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
| Panel substrate | E1-grade particleboard/MDF composite | |
|---|---|---|
| Surface finish | Matte two-tone grey/white laminate | |
| Raised counter support posts | Chrome-plated polished steel tubing | |
| Edge banding | Impact-resistant PVC matching panel finish | |
| Drawer hardware | Cold-rolled steel ball-bearing slides | |
| Plinth base | Matching laminated manufactured wood | |
| Cable management grommets | ABS plastic 80mm diameter | |
| Leveling feet | Nylon-tipped adjustable steel feet | |
| Structural panel substrate | E1-grade particleboard and MDF composite | |
| Raised counter supports | Polished chrome-plated steel tubing | |
| Edge sealing | Color-matched impact-resistant PVC | |
| Drawer running hardware | Cold-rolled steel ball-bearing slides |
Adjustment / rotation / tilt / mobility / storage features
| Dual-tier counter design | Raised front counter blocks staff work area view while enabling visitor transactions | |
|---|---|---|
| Front drawer storage bank | Three horizontal lockable drawer compartments on customer-facing long segment | |
| Corner return workspace | Right-side return extends staff work area for secondary equipment/storage | |
| Integrated cable management | Punched cable grommets on work surface for monitor/register wiring | |
| Lockable storage | Central keyed lock secures all front drawers for valuables/documents | |
| Adjustable leveling | Concealed plinth feet adjust by 10mm to correct uneven floor surfaces | |
| Modular assembly | Three bolt-together sections for on-site corner configuration | |
| Scratch-resistant work surface | Laminate finish resists scuffs from keys, registers and office equipment | |
| Dual-tier transaction design | Raised 1150mm front counter obscures staff workspace while supporting visitor check-in | |
| Front storage bank | Three equal horizontal drawer compartments on main front segment for supplies | |
| Keyed storage security | Central cam lock secures all front drawers to protect documents and valuables | |
| Floor leveling adjustment | Concealed plinth feet adjust 10mm vertically to stabilize desk on uneven floors |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
| Office lobby reception | Primary use for greeting visitors, registering guests and workplace access control | |
|---|---|---|
| Retail cashier counter | Suitable for boutique, salon or clinic checkout with raised transaction surface | |
| Hotel front service desk | Appropriate for small hotel or service apartment guest check-in and concierge use | |
| Open-plan office front zone | Fits modern office layouts with L-shaped corner placement against walls | |
| Dual-staff workstation | Layout supports two reception staff working simultaneously without interference | |
| Shared service counter | Usable for administrative service points in public buildings or government offices | |
| Beauty salon reception | Suitable for salon front desk with space for scheduling terminals and retail displays | |
| Corporate office lobby reception | Primary use for guest greeting, visitor registration and access control |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Office work tables safety and strength requirements, applicable for work surface load | |
|---|---|---|
| EN 15372:2016 | Furniture durability and strength for non-domestic storage, applicable for drawer units | |
| EN 13722:2004 | Furniture test methods for cabinet storage strength, applicable for case integrity |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Desk products standard for safety and performance, applicable for commercial use | |
|---|---|---|
| ANSI/BIFMA X5.9-2019 | Storage units standard for drawer cycle and load performance | |
| ANSI/BIFMA M7.1-2020 | Test standard for furniture stability of freestanding desk and case units |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable for panel structural integrity | |
|---|---|---|
| GB 18580-2017 | Formaldehyde emission limits for wood-based panels, applicable for E1-grade substrate verification | |
| GB/T 4893.8-2013 | Surface abrasion resistance test for furniture finishes, applicable for laminate durability |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable for panel structural integrity; 2. GB 18580-2017: Formaldehyde emission limits for wood-based panels, applicable for E1-grade substrate verification; 3. GB/T 4893.8-2013: Surface abrasion resistance test for furniture finishes, applicable for laminate durability; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
