Automatic mm / inch conversion · Core engineering specifications
| overall dimensions | 2800 x 700 x 1100 mm | |
|---|---|---|
| top thickness | 50 mm | |
| front panel thickness | 12 mm | |
| base footprint width | 800 mm | |
| facet ridge depth | 120 mm | |
| counter transaction height | 1100 mm | |
| internal staff knee recess depth | 450 mm | |
| edge band thickness | 3 mm | |
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| top static distributed load | 100 kg | |
|---|---|---|
| net product weight | 320 kg | |
| surface Mohs hardness | 7 | |
| surface water absorption | 0.03% | |
| finish gloss level | 2000 GU | |
| recommended user count | 3 staff | |
| structural warranty | 10 years | |
| surface abrasion resistance | 4000 cycles | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
| top surface | 12mm glossy white acrylic solid surface (Corian equivalent) | |
|---|---|---|
| front facade panels | Thermoformed 12mm solid surface with faceted origami geometry | |
| internal substrate frame | 18mm birch plywood structural support | |
| base plinth | Sealed MDF core with solid surface cladding | |
| joint adhesive | Color-matched solid surface seam adhesive | |
| internal reinforcement | 20x40mm steel square tube bracing | |
| surface finish | High-gloss UV-stabilized polished coating | |
| optional LED channel | Recessed aluminum LED strip channel (custom option) | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel | |
| Primary Connector Specification | Reference M6-M8 with at least 2 fixing points per main support |
Adjustment / rotation / tilt / mobility / storage features
| floor-mounted fixed installation | Secured directly to finished floor with hidden anchor brackets | |
|---|---|---|
| seamless faceted facade | Thermoformed solid surface panels joined to create continuous angular diamond pattern | |
| rear cable management | 80mm diameter cable grommets positioned at each staff station | |
| customizable length option | Fabricated to custom lengths from 1800mm to 6000mm per project requirements | |
| surface repairability | Scratches and minor damage can be sanded and rebuffed to original finish | |
| non-porous surface performance | Resists stains, bacteria, and liquid absorption for high-traffic lobby use | |
| optional internal storage | Add-on lockable drawers and shelves installed on rear staff side | |
| optional logo engraving | Custom CNC engraved or inlaid logo available on front facade | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
| corporate office lobby | Sculptural modern design fits premium corporate entryways for guest check-in | |
|---|---|---|
| hotel lobby reception | High-gloss finish complements luxury stone and marble lobby finishes | |
| high-end retail concierge | Wide counter space supports product display and guest transaction services | |
| medical clinic check-in | Non-porous seamless surface enables easy sanitization for healthcare environments | |
| exhibition hall information counter | Long linear form provides multiple staff stations for high visitor traffic | |
| 2-3 person reception team | 2800mm length accommodates 3concurrent staff workstations | |
| contemporary minimalist interior | Monolithic white geometric form aligns with modern minimalist design schemes |
EU Market Access Requirements* EN Standards
| EN 438-2:2019 | Test methods for high-pressure decorative laminates, reference for surface wear resistance | |
|---|---|---|
| EN 13892-1:2002 | Surface flatness tolerance requirements for finished furniture surfaces | |
| EN 16121:2013 | Storage furniture safety, strength and durability requirements for optional internal units |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to internal plywood/MDF substrate | |
|---|---|---|
| GB 18580-2017 | Formaldehyde emission limits for wood-based panels, applicable to internal substrate materials | |
| GB/T 35607-2017 | Performance requirements for acrylic solid surface decorative sheets |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to internal plywood/MDF substrate; 2. GB 18580-2017: Formaldehyde emission limits for wood-based panels, applicable to internal substrate materials; 3. GB/T 35607-2017: Performance requirements for acrylic solid surface decorative sheets; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
