| Submitted | Field | Original | Note / Status | |
|---|---|---|---|---|
No corrections yet. Use the flag at the end of a row to report an issue. | ||||
Automatic mm / inch conversion · Core engineering specifications
| Overall footprint | 2400 x 810 x 1090 mm | |
|---|---|---|
| Lower staff work surface height | 760 mm | |
| Upper transaction shelf height | 1090 mm | |
| Vertical gap between shelves | 300 mm | |
| Left return wing depth | 600 mm | |
| Front privacy panel height | 740 mm | |
| Recessed plinth base height | 100 mm | |
| Work surface panel thickness | 25 mm | |
| Upper shelf thickness | 25 mm | |
| Edge band thickness | 2 mm | |
| Chrome support post diameter | 50 mm | |
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| Assembled net weight | 113 kg | |
|---|---|---|
| Main work surface static load capacity | 100 kg | |
| Recommended maximum daily user count | 50 visitors | |
| Laminate surface abrasion resistance | 2000 cycles | |
| Surface stain resistance rating | Class B | |
| Structural service life | 10 years | |
| Drawer slide load rating | 25 kg | |
| Drawer slide cycle rating | 50000 cycles | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
| Main work surface | High-pressure matte dark grey laminate over 25mm MDF core | |
|---|---|---|
| Upper transaction shelf | High-pressure light grey/white matching laminate over engineered wood core | |
| Upper shelf supports | Polished chrome-plated steel posts, 50mm diameter | |
| Front privacy panel | Matte dark grey laminate panel with three horizontal decorative recess lines | |
| Plinth kick base | Light silver-grey matte laminate recessed toe kick panel | |
| Internal support frame | Powder-coated steel internal bracing for structural rigidity | |
| Edge treatment | 2mm thick matching PVC edge banding on all exposed panel edges | |
| Left return side panel | Solid dark grey laminate panel enclosing staff side workspace | |
| Adjustable leveling feet | Nylon base adjustable feet for uneven floor compensation | |
| Left return end cap | Matching dark grey laminate panel finishing the side return edge | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm |
Adjustment / rotation / tilt / mobility / storage features
| Dual-tier transaction design | Raised upper shelf for standing visitor interaction, lower surface for staff seated work | |
|---|---|---|
| Front privacy screening | Full-height solid front panel obscures staff work area, legs and stored items from visitor view | |
| Cable management grommets | Two 60mm diameter cable ports for power and data wiring on work surface | |
| Under-desk storage compatibility | Accommodates standard 400mm wide mobile filing pedestal under work surface | |
| Leveling adjustment | 15mm vertical adjustment range via base feet to correct uneven floor surfaces | |
| Modular layout compatibility | Left return wing creates L-shape configuration for single staff workstation layout | |
| Surface cleaning tolerance | Laminate finish withstands regular disinfection with commercial cleaning chemicals | |
| Cable management system | Two 60mm diameter grommets routed to under-desk cable tray for power and data wiring | |
| Surface disinfection tolerance | Laminate finish withstands regular cleaning with commercial-grade disinfectants | |
| Under-desk storage fit | Clearance accommodates 400mm wide mobile filing pedestal under main work surface | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Shipping carton dimensions | 2450 x 850 x 200 mm | |
|---|---|---|
| Gross shipping weight | 125 kg | |
| Reference Package Count | 1 set / 2 cartons | |
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
| Corporate office lobbies | Provides professional front-of-house greeting and transaction surface for staff and visitors | |
|---|---|---|
| Salon and spa reception areas | Dual-tier design supports check-in, product display and appointment scheduling | |
| Medical and dental clinic entries | Privacy front panel conceals patient records and staff administrative work | |
| Hotel and hospitality front desks | Stain-resistant surface supports high-traffic guest check-in interactions | |
| Retail boutique cash wraps | Integrated transaction height supports point-of-sale equipment and customer purchases | |
| Small business entry areas | Compact L-shape fits narrow entry spaces while providing dedicated staff workspace |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Office work tables safety and strength requirements, applicable to staff work surface | |
|---|---|---|
| EN 14749:2016 | Domestic and kitchen storage units worktops safety requirements, applicable to storage panels | |
| EN 12521:2015 | Furniture strength, durability and safety for contract non-domestic seating and tables |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Desk products standard for safety, durability and structural performance | |
|---|---|---|
| ANSI/BIFMA G1-2013 | Ergonomic guidelines for office furniture work surface height dimensions | |
| ANSI/BIFMA X7.1-2011 | Furniture emissions standard for low-VOC indoor air quality compliance |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to laminate casegood construction | |
|---|---|---|
| GB/T 4893.4-2013 | Surface wear resistance test for furniture finishes, applicable to laminate work surfaces | |
| GB 18584-2001 | Formaldehyde emission limit for interior wood furniture, required for indoor commercial use | |
| GB/T 10357.1-1989 | Table static load test method, applicable to work surface load verification |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to laminate casegood construction; 2. GB/T 4893.4-2013: Surface wear resistance test for furniture finishes, applicable to laminate work surfaces; 3. GB 18584-2001: Formaldehyde emission limit for interior wood furniture, required for indoor commercial use; 4. GB/T 10357.1-1989: Table static load test method, applicable to work surface load verification; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
