Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions (standard options) | 3600 x 800 x 1050 mm | |
|---|---|---|
| Work surface thickness | 50 mm | |
| Work surface standing height | 1050 mm | |
| Work surface usable depth | 800 mm | |
| Knee clearance height under work surface | 700 mm | |
| Knee clearance depth under work surface | 600 mm | |
| Curved front fascia thickness | 30 mm | |
| LED light strip width at base | 60 mm | |
| Angled side support panel height | 1050 mm | |
| Rear storage compartment internal height | 350 mm | |
| Cable grommet diameter | 80 mm | |
| Edge banding thickness | 2 mm | |
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| Work surface static load capacity | 200 kg | |
|---|---|---|
| Rear storage shelf static load per level | 20 kg | |
| Recommended maximum reception staff capacity | 2 persons | |
| Net weight (3600mm variant) | 250 kg | |
| Integrated LED strip operational lifespan | 50000 hours | |
| Surface wear resistance (taber test) | 4000 cycles | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles | |
| Top Abrasion Reference | Acceptance target ≥4,000 abrasion cycles or finish-system test |
Core acceptance fields · Panels / hardware / frame / upholstery
| Front and side fascia panels | 18mm MDF substrate with high-gloss white PU lacquer finish | |
|---|---|---|
| Work surface | 25mm plywood core with matching high-gloss white lacquer | |
| Internal structural frame | 40mm x 40mm square steel tube with powder coated finish | |
| Base LED light strip | 24V SMD warm white LED with diffused polycarbonate cover | |
| Rear storage shelves | 18mm particle board with white melamine finish | |
| Adjustable leveling feet | 10mm diameter nylon with steel threaded stem | |
| Edge treatment | 2mm thick matching PVC edge banding | |
| Cable management grommets | ABS plastic with brushed silver finish | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel | |
| Primary Connector Specification | Reference M6-M8 with at least 2 fixing points per main support |
Adjustment / rotation / tilt / mobility / storage features
| Integrated base ambient lighting | Continuous warm white LED strip along front base, hardwired to wall power | |
|---|---|---|
| Rear open storage compartments | Dual divided shelf bays under rear work surface for office supplies | |
| Concealed cable routing | Internal channeling from work surface grommets to floor outlet access | |
| Adjustable floor leveling | Threaded feet at all support points to correct uneven lobby floors | |
| Custom size support | Available in 2800mm and 3600mm standard widths, custom dimensions on request | |
| Seamless curved profile | CNC-machined panels to form continuous asymmetrical sloped front face | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
| Commercial office lobby | Standing-height design for visitor greeting and check-in at corporate entry points | |
|---|---|---|
| Hotel front reception area | Sculptural high-gloss aesthetic creates premium first impression for guest arrivals | |
| Medical clinic or beauty salon checkout | Smooth non-porous surface allows easy cleaning for high-traffic public service areas | |
| Two-staff reception configuration | 3600mm width provides sufficient personal space for two simultaneous receptionists | |
| Modern minimalist interior schemes | Monochrome white finish and sculptural form complements contemporary office design palettes |
EU Market Access Requirements* EN Standards
| EN 527-3:2003 | Test methods for office work surfaces, applicable for work surface load and durability | |
|---|---|---|
| EN 62471:2008 | Photobiological safety of lamps, applicable for integrated LED lighting safety | |
| EN 13722:2004 | Performance requirements for office storage furniture, applicable for rear shelf durability |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable for panel construction and finish quality | |
|---|---|---|
| GB/T 4897.3-2003 | Particle board for furniture use, applicable for internal substrate material performance | |
| GB 7000.201-2008 | Safety requirements for fixed general purpose lighting, applicable for integrated LED strip | |
| GB 18584-2001 | Limit of harmful substances in wooden furniture, applicable for indoor air quality compliance |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable for panel construction and finish quality; 2. GB/T 4897.3-2003: Particle board for furniture use, applicable for internal substrate material performance; 3. GB 7000.201-2008: Safety requirements for fixed general purpose lighting, applicable for integrated LED strip; 4. GB 18584-2001: Limit of harmful substances in wooden furniture, applicable for indoor air quality compliance; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
