Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions (1800mm variant) | 1800 x 600 x 1050 mm | |
|---|---|---|
| Staff worksurface height | 750 mm | |
| Front visitor counter height | 1050 mm | |
| Knee clearance height under worksurface | 680 mm | |
| Knee clearance width | 900 mm | |
| Worksurface top thickness | 25 mm | |
| Front privacy panel thickness | 18 mm | |
| Edge banding thickness | 2 mm | |
| Curved corner radius | 150 mm | |
| Drawer internal dimensions | 400 x 350 x 120 mm | |
| Cable grommet diameter | 60 mm | |
| Base toe kick height | 80 mm | |
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| Top surface static load capacity | 150 kg | |
|---|---|---|
| Drawer slide cycle rating | 50000 cycles | |
| Recommended maximum user count | 1 person | |
| Finish scratch resistance | 2H pencil hardness | |
| Unit net weight (1800mm variant) | 95 kg | |
| Storage drawer count | 2 units | |
| Warranty period | 3 years | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
| Core substrate | 18mm/25mm medium-density fiberboard (MDF) | |
|---|---|---|
| Exterior finish | High-gloss white polyurethane baked paint | |
| Decorative accents | Grey horizontal PVC accent stripes | |
| Drawer slides | Cold-rolled steel 3-section ball-bearing slides | |
| Drawer locks | Zinc alloy keyed cam locks | |
| Internal support frame | Solid pine wood bracing | |
| Edge banding | 2mm thick PVC edge trim | |
| Base molding | Matching painted MDF stepped trim | |
| Cable grommets | ABS plastic desk grommets | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel |
Adjustment / rotation / tilt / mobility / storage features
| Reversible installation orientation | Curved corner can be assembled for left or right approach | |
|---|---|---|
| Dual-height work surface | Raised front transaction ledge for visitor interaction, lower rear surface for staff seating | |
| Lockable drawer storage | Two integrated lockable drawers for storing reception supplies and documents | |
| Concealed cable management | Grommet pass-throughs to route monitor and device cables out of sight | |
| Front privacy screening | Full-height front panel blocks view of staff leg and work area from visitors | |
| Signage placement area | Flat raised front top surface designed for company logo or nameplate | |
| Smooth rounded corner design | Curved guest-facing edge eliminates sharp corners for high-traffic lobby safety | |
| Scratch-resistant easy-clean surface | Baked paint finish allows wipe-down cleaning for daily lobby maintenance | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
| Small office lobbies | Single-staff reception counter for entryways with limited floor space, three length options available | |
|---|---|---|
| Beauty salons and clinics | Curved approach design supports guest check-in and transaction with privacy for staff | |
| Retail store front desks | Smooth easy-clean finish suits high-traffic customer service areas | |
| Hotel front counters (small properties) | Compact size supports check-in, key storage and guest interaction | |
| Reversible layout fitting | Curved corner can be oriented to match left or right entry flow without custom modification | |
| Brand display placement | Raised front ledge accommodates logo signage and decorative items for visitor-facing presentation |
EU Market Access Requirements* EN Standards
| EN 527-2:2002 | Office worktables safety and strength requirements, applicable for staff worksurface load testing | |
|---|---|---|
| EN 13722:2004 | Furniture storage units strength and durability requirements, applicable for drawer performance | |
| EN 71-3:2019 | Migration of certain elements for surface materials, applicable for public area furniture safety |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Desk products performance standard, applicable for worksurface load and stability testing | |
|---|---|---|
| ANSI/BIFMA X5.9-2019 | Storage units performance standard, applicable for drawer slide and lock durability |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable for panel reception desk structural quality | |
|---|---|---|
| GB/T 4893.1-2021 | Surface wear resistance test method for furniture coatings, applicable for finish durability acceptance | |
| GB 18584-2001 | Limit of harmful substances in wooden furniture, applicable for formaldehyde emission verification |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable for panel reception desk structural quality; 2. GB/T 4893.1-2021: Surface wear resistance test method for furniture coatings, applicable for finish durability acceptance; 3. GB 18584-2001: Limit of harmful substances in wooden furniture, applicable for formaldehyde emission verification; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
