Automatic mm / inch conversion · Core engineering specifications
| overall dimensions | 2400 x 800 x 1100 mm | |
|---|---|---|
| work surface height | 750 mm | |
| work surface depth | 650 mm | |
| raised privacy panel height | 350 mm | |
| knee clearance opening width | 1200 mm | |
| knee clearance height | 690 mm | |
| end panel width | 300 mm | |
| cable grommet diameter | 60 mm | |
| top panel thickness | 25 mm | |
| side panel thickness | 18 mm | |
| edge trim thickness | 2 mm | |
| curve radius | 1800 mm | |
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| product net weight | 150 kg | |
|---|---|---|
| work surface static load capacity | 200 kg | |
| accommodated staff count | 2 | |
| surface hardness rating | H grade | |
| water absorption rate | 0.003% | |
| finish scratch resistance | 4000 cycles | |
| structural warranty | 10 years | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
| work surface | 12mm matte white acrylic solid surface over MDF substrate | |
|---|---|---|
| back privacy panel | 18mm MDF with matte white baked paint finish | |
| end support panels | 18mm painted MDF with flared curved profile | |
| central knee divider | 18mm painted MDF with rounded edge detail | |
| cable grommets | White ABS plastic | |
| base edge trim | PVC rounded protective trim | |
| internal support frame | 1.2mm thick powder-coated steel tube | |
| surface finish | Low-sheen matte white coating | |
| edge banding | 2mm PVC edge trim applied to all exposed panel edges | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel |
Adjustment / rotation / tilt / mobility / storage features
| cable management | Two integrated 60mm grommets route power/data cables from work surface to floor | |
|---|---|---|
| attendant access | Central open knee well allows seated access for two reception staff | |
| visitor privacy screen | Full-length raised curved back panel blocks view of under-desk areas from lobby | |
| freestanding installation | Pre-assembled panels require no wall mounting for placement | |
| seated transaction design | 750mm work surface height accommodates standard office chair seat heights | |
| curved front profile | Smooth arc shape guides visitor flow around the reception point | |
| surface cleanability | Non-porous seamless surface allows wipe-down cleaning with standard disinfectants | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
| corporate office lobby | 2-station reception point for greeting visitors and check-in | |
|---|---|---|
| hotel front desk | Curved check-in counter for boutique and mid-scale hotel lobbies | |
| medical clinic reception | Easy-clean non-porous surface suitable for healthcare waiting areas | |
| beauty salon checkout | Curved cashier and consultation desk for retail service spaces | |
| bank information counter | Sturdy public-facing counter for customer guidance and form processing | |
| school administration lobby | Reception point for student and visitor check-in at institutional entrances |
EU Market Access Requirements* EN Standards
| EN 527-2:2002+A1:2019 | Office worktables safety and strength requirements, applicable to work surface load | |
|---|---|---|
| EN 1335-2:2009 | Office furniture stability and structural integrity for commercial use | |
| EN 71-3:2019+A1:2021 | Migration of certain elements, applicable for public area surface safety |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Desk products standard for strength, durability and structural stability | |
|---|---|---|
| ANSI/BIFMA e3-2019 | Furniture sustainability standard for material emissions and corporate responsibility |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to panel structural components | |
|---|---|---|
| GB/T 35607-2017 | Green product evaluation standard for furniture, applicable to formaldehyde emission limits | |
| GB 28007-2011 | Safety requirements for children's furniture, applicable to edge and corner safety for public spaces |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to panel structural components; 2. GB/T 35607-2017: Green product evaluation standard for furniture, applicable to formaldehyde emission limits; 3. GB 28007-2011: Safety requirements for children's furniture, applicable to edge and corner safety for public spaces; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
