Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 2400 x 760 x 1070 mm | |
|---|---|---|
| Lower staff work surface height | 860 mm | |
| Raised visitor transaction counter height | 1070 mm | |
| Work surface thickness | 50 mm | |
| Front decorative panel thickness | 18 mm | |
| Stainless steel base kickplate height | 100 mm | |
| Raised counter support standoff diameter | 50 mm | |
| Staff work surface depth | 600 mm | |
| Raised counter overhang depth | 300 mm | |
| Left integrated storage cabinet width | 600 mm | |
| Edge banding thickness | 2 mm | |
| Cable grommet diameter | 80 mm | |
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| Total unit net weight | 185 kg | |
|---|---|---|
| Main work surface static load capacity | 150 kg | |
| Storage drawer slide static load rating | 45 kg | |
| Recommended simultaneous staff capacity | 2 | |
| Surface wear resistance rating | 2000 abrasion cycles | |
| Drawer slide cycle life | 50000 open/close cycles | |
| Door hinge cycle life | 80000 open/close cycles | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
| Main body structure | 18mm E0-grade high-density particleboard | |
|---|---|---|
| Work surfaces | High-gloss white thermally fused laminate | |
| Front decorative panel | Frosted white backing with dark geometric metal overlay | |
| Base kickplate | 0.8mm thick brushed stainless steel | |
| Raised counter supports | Polished chrome-plated steel cylinders | |
| Storage cabinet interiors | 15mm melamine-faced engineered board | |
| Hardware components | Cold-rolled steel hinges and slides | |
| Edge trim | 2mm thick matching white PVC edge banding | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel | |
| Primary Connector Specification | Reference M6-M8 with at least 2 fixing points per main support |
Adjustment / rotation / tilt / mobility / storage features
| Dual-height work zone design | Lower rear staff surface paired with raised front transaction counter | |
|---|---|---|
| Integrated cable management | 80mm diameter desk grommets with under-desk cable tray | |
| Left-side enclosed storage | Concealed cabinet with adjustable interior shelf | |
| Stainless steel kickplate protection | Full perimeter base trim prevents scuffs from foot traffic and cleaning equipment | |
| Rear staff access | Full open rear side for staff entry and equipment placement | |
| Custom logo mounting provision | Flat raised counter front edge supports adhesive or mounted brand lettering | |
| Leveling base adjustment | Adjustable feet under stainless kickplate compensate for uneven floors | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
| Corporate office lobbies | Linear dual-height design creates professional front-of-house first impression | |
|---|---|---|
| Hotel check-in areas | Durable laminate surfaces accommodate high-volume guest interaction | |
| Medical and clinic reception | Easy-clean non-porous surfaces support sanitary regular disinfection | |
| Modern co-working space entrances | Geometric decorative front matches contemporary workspace aesthetics | |
| Recommended complementary furniture | Pair with ergonomic office task chairs, waiting area seating and lobby signage |
EU Market Access Requirements* EN Standards
| EN 15372:2008+A1:2016 | Durability and stability requirements for non-domestic furniture | |
|---|---|---|
| EN 12521:2015 | Safety and strength requirements for commercial work surfaces |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture | |
|---|---|---|
| GB/T 4897.3-2015 | Particleboard for furniture use | |
| GB 18580-2017 | Formaldehyde emission limits for wood-based panels |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture; 2. GB/T 4897.3-2015: Particleboard for furniture use; 3. GB 18580-2017: Formaldehyde emission limits for wood-based panels; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
