| Submitted | Field | Original | Note / Status | |
|---|---|---|---|---|
No corrections yet. Use the flag at the end of a row to report an issue. | ||||
Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 4000 x 800 x 1100 mm | |
|---|---|---|
| Visitor-facing counter height | 1100 mm | |
| Staff seated work surface height | 750 mm | |
| Staff knee clearance height under work surface | 680 mm | |
| Work surface depth | 600 mm | |
| Faceted front facade relief depth | 120 mm | |
| Central dark accent panel width | 700 mm | |
| Kickboard recess height from floor | 100 mm | |
| Work surface panel thickness | 25 mm | |
| Edge band thickness | 2 mm | |
| Cable grommet diameter | 80 mm | |
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| Work surface static load capacity | 200 kg | |
|---|---|---|
| Drawer slide static load per drawer | 45 kg | |
| Drawer slide cycle rating | 50000 cycles | |
| Storage cabinet door hinge cycle rating | 80000 cycles | |
| Product net weight | 320 kg | |
| Recommended maximum concurrent staff users | 2 | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles | |
| Top Abrasion Reference | Acceptance target ≥4,000 abrasion cycles or finish-system test |
Core acceptance fields · Panels / hardware / frame / upholstery
| Main carcass substrate | 25mm thick E0 grade MDF panel | |
|---|---|---|
| White faceted front finish | High-gloss UV-cured baked paint | |
| Central accent panel | Matte dark grey laminate panel | |
| Work surface top | 25mm high-pressure laminate (HPL) | |
| Internal drawer boxes | 18mm thick plywood | |
| Kickboard trim | 1mm thick powder-coated steel | |
| Drawer slides | Cold-rolled steel ball-bearing slides | |
| Cable grommets | ABS plastic | |
| Internal cable management tray | 0.8mm thick galvanized steel | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel |
Adjustment / rotation / tilt / mobility / storage features
| Dual independent work zones | Two separated staff positions for concurrent front desk operation | |
|---|---|---|
| Lockable storage drawers | Integrated under-surface drawers with keyed locks for secure document storage | |
| Cable management system | Dual grommets and under-surface tray to route power/data cables out of sight | |
| Faceted visitor-facing facade | 3D geometric diamond relief panels for brand front presentation | |
| Central logo-ready accent panel | Flat matte dark panel for custom company logo mounting | |
| Recessed kickboard design | 100mm high base recess to accommodate visitor and staff foot placement | |
| Optional LED strip lighting compatibility | Recessed gap behind faceted panels for accent lighting installation | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
| Corporate office lobby reception | Front-of-house counter for employee and visitor greeting at company entry | |
|---|---|---|
| Hotel front desk | Dual-station check-in counter for boutique and business hotel lobbies | |
| Medical clinic waiting area | Check-in and registration counter for dental, medical or wellness clinics | |
| Salon and spa reception | Guest check-in and retail transaction counter for beauty service locations | |
| Commercial building leasing center | Information and registration counter for property sales and leasing offices | |
| Recommended companion furniture | Pair with standard ergonomic office task chairs and 3-seat visitor waiting lounge seating |
EU Market Access Requirements* EN Standards
| EN 15372:2008 | Furniture – Strength, durability and safety for non-domestic office storage units | |
|---|---|---|
| EN 13722:2004 | Furniture – Strength and durability of office work surfaces for commercial use | |
| EN 14073-2:2004 | Office furniture – Storage furniture safety requirements for commercial installations |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable for panel constructionAcceptance inspection | |
|---|---|---|
| GB 18580-2017 | Formaldehyde emission limits for wood-based panels, E0 grade required for indoor office use | |
| GB/T 4897.3-2003 | Particleboard specifications for furniture structural use, applicable for carcass substrates |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable for panel constructionAcceptance inspection; 2. GB 18580-2017: Formaldehyde emission limits for wood-based panels, E0 grade required for indoor office use; 3. GB/T 4897.3-2003: Particleboard specifications for furniture structural use, applicable for carcass substrates; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
