Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 3600 x 800 x 1100 mm | |
|---|---|---|
| Raised upper guest counter height | 1100 mm | |
| Lower staff work surface height | 750 mm | |
| Staff work surface depth | 600 mm | |
| Front privacy panel height | 900 mm | |
| Side return cabinet dimensions | 800 x 600 x 750 mm | |
| Countertop thickness | 25 mm | |
| Vertical support post diameter | 80 mm | |
| Base foot height | 20 mm | |
| Knee clearance height under staff surface | 680 mm | |
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| Countertop static load capacity | 150 kg | |
|---|---|---|
| Drawer slide load rating | 25 kg per drawer | |
| Drawer slide cycle rating | 50000 cycles | |
| Door hinge cycle rating | 80000 cycles | |
| Recommended staff capacity | 3 users | |
| Adjustable foot load rating | 100 kg per foot | |
| Net weight range reference | 220 kg | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
| Countertop substrate | 25mm MDF/particleboard core | |
|---|---|---|
| Front panel finish | Matte mint green baked lacquer | |
| End column finish | Matte white baked lacquer | |
| Side return panel | Black matte engineered wood laminate | |
| Tier support posts | Powder-coated black steel | |
| Edge banding | 2mm PVC hot-melt edge banding | |
| Base feet | Black nylon adjustable glides | |
| Hardware components | Cold-rolled steel hinges/slides | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel | |
| Primary Connector Specification | Reference M6-M8 with at least 2 fixing points per main support |
Adjustment / rotation / tilt / mobility / storage features
| Cable management grommets | 2x 80mm diameter desk grommets | |
|---|---|---|
| Side return storage | 1 locking file drawer + 1 storage drawer | |
| Dual-tier counter layout | Raised guest counter conceals staff work zone | |
| Adjustable leveling feet | 15mm vertical adjustment range | |
| Keyboard tray compatibility | Under-desk slide-out keyboard tray mount | |
| Surface stain resistance | Wipe-clean lacquer surface | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
| Corporate office lobby | Multi-staff guest check-in and welcome for 100person companies | |
|---|---|---|
| Medical clinic reception | Patient check-in with concealed staff work area | |
| Co-working space entrance | Member and visitor registration with document storage | |
| Retail flagship front desk | Customer service and transaction counter with brand-compatible finish | |
| Hotel administrative lobby | Guest services counter suitable for standing and seated interaction |
EU Market Access Requirements* EN Standards
| EN 527-2:2002+A1:2016 | Office worktables – safety and strength requirements | |
|---|---|---|
| EN 14073-2:2004 | Office storage furniture – safety requirements | |
| EN 13722:2004 | Furniture – test methods for surface finish durability |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Desk Products – performance and safety standard | |
|---|---|---|
| ANSI/BIFMA X5.9-2019 | Storage Units – performance and safety standard |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden office furniture | |
|---|---|---|
| GB/T 4897-2015 | Particleboard for furniture use | |
| GB 18580-2017 | Formaldehyde emission limits for wood-based panels |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden office furniture; 2. GB/T 4897-2015: Particleboard for furniture use; 3. GB 18580-2017: Formaldehyde emission limits for wood-based panels; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
