Automatic mm / inch conversion · Core engineering specifications
| Overall footprint (outer arc) | 3000 x 1600 x 1050 mm | |
|---|---|---|
| Outer semi-circular arc diameter | 3000 mm | |
| Inner staff work surface height | 750 mm | |
| Work surface total depth (outer edge to inner panel) | 600 mm | |
| Central knee clearance width | 800 mm | |
| Knee clearance under work surface height | 680 mm | |
| Raised transaction counter height | 1050 mm | |
| Transaction counter depth | 350 mm | |
| Grey kickplate height at floor level | 100 mm | |
| Worktop thickness | 25 mm | |
| Front panel total thickness | 25 mm | |
| Edge banding thickness (all exposed edges) | 2 mm | |
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| Work surface static uniform load capacity | 200 kg | |
|---|---|---|
| Unit total net weight | 180 kg | |
| Recommended simultaneous users (staff side) | 2 | |
| Recommended guest transaction capacity (front side) | 3 | |
| Surface abrasion resistance (worktop) | 2000 cycles | |
| Lacquer finish scratch resistance | 2H pencil hardness | |
| Optional drawer slide static load rating (per drawer) | 30 kg | |
| Manufacturer warranty period | 5 years | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
| Structural substrate (all panels) | 25mm E1 grade high-density particle board | |
|---|---|---|
| Front facade finish | Matte white PU baked lacquer | |
| Decorative mid-front stripe | High-gloss dark cherry lacquer | |
| Worktop/transaction counter surface | 0.8mm dark cherry high-pressure laminate (HPL) | |
| All exposed panel edges | 2mm dark cherry PVC edge banding | |
| Kickplate base | Matte grey PVC laminated panel | |
| Cable management grommets | ABS plastic with brushed metal finish | |
| Internal support frame | 1.2mm thick powder-coated square steel tube | |
| Adjustable leveling feet | Nylon base with steel threaded stem | |
| Optional drawer hardware | Cold-rolled steel ball-bearing slides | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm |
Adjustment / rotation / tilt / mobility / storage features
| C-shaped concave work area | Full wrap-around inner workspace for seated reception staff | |
|---|---|---|
| Dual-height surface design | Raised 1050mm transaction counter for guests, lower 750mm work surface for staff | |
| Integrated cable management | Two 60mm diameter cable grommets at work surface positions for monitor/device wiring | |
| Central staff entry cutout | 800mm wide open gap in the inner arc for staff entry/exit to work area | |
| Kickspace recess | 100mm tall recessed base to accommodate seated staff foot placement | |
| Leveling adjustment | Four adjustable nylon feet with 15mm vertical adjustment for uneven floors | |
| Wipe-clean surface maintenance | Lacquer and HPL surfaces cleanable with damp cloth and mild detergent | |
| Customizable layout options | Custom arc diameter, color finish, and integrated storage available for commercial projects | |
| Optional integrated storage | Suspended 2-drawer pedestal under work surface for office supplies | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
| Corporate office lobbies | Designed as front greeting counter for office building main entrance visitor reception | |
|---|---|---|
| Hotel/hospital front desks | Suitable for public-facing check-in and inquiry positions in hospitality/healthcare settings | |
| Public service center counters | Works for government service hall, bank branch or administrative office information desks | |
| Commercial showroom reception | Appropriate for auto dealership, retail showroom or corporate experience center greeting points | |
| Dual-staff work position | Inner work area accommodates two receptionists working simultaneously during peak hours | |
| Accessible visitor interaction | Raised transaction counter provides appropriate standing-height surface for guest document exchange | |
| Matching furniture recommendation | Pairs with ergonomic mesh office chairs for staff and lobby lounge seating for waiting guests |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Office work tables safety and strength requirements, applicable to staff work surface load testing | |
|---|---|---|
| EN 13722:2004 | Furniture strength, durability and stability for reception/contract commercial furniture | |
| EN 13986:2004 | Wood-based panels formaldehyde emission class E1 requirement for indoor commercial spaces |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Desk products safety and performance standard for static load and stability testing | |
|---|---|---|
| ANSI/BIFMA X5.9-2019 | Storage units performance standard for optional integrated drawer pedestals |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden office furniture, applicable to panel substrate and finish quality checks | |
|---|---|---|
| GB 18580-2017 | Formaldehyde emission limit for wood-based panels, requires E1 grade ≤0.124mg/m³ for indoor use | |
| GB/T 4897.3-2015 | Performance requirements for particle board used in furniture structural applications | |
| GB/T 17657-2013 | Test methods for evaluating surface wear, scratch, and impact resistance of furniture panels |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden office furniture, applicable to panel substrate and finish quality checks; 2. GB 18580-2017: Formaldehyde emission limit for wood-based panels, requires E1 grade ≤0.124mg/m³ for indoor use; 3. GB/T 4897.3-2015: Performance requirements for particle board used in furniture structural applications; 4. GB/T 17657-2013: Test methods for evaluating surface wear, scratch, and impact resistance of furniture panels; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
