Physical Dimensions
Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall dimensions (W × D × H) | 700 × 720 × 1180 mm | |
|---|---|---|
| Finished Seat Cushion Thickness | 90 mm | |
| Backrest Padding Thickness | 70 mm | |
| Lumbar Support Zone Height | 240 mm | |
| Clear Width Between Armrests | 540 mm |
Weight, Load & Performance
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Recommended maximum user weight | 150 kg | |
|---|---|---|
| Product net weight | 28 kg | |
| Static seat load rating | 136 kg | |
| Backrest recline angle range | 95 to 135 degrees | |
| Gas lift height adjustment stroke | 100 mm | |
| Caster rolling durability | 40000 cycles | |
| Seat foam density | 45 kg/m³ | |
| Backrest foam density | 38 kg/m³ | |
| Upholstery abrasion resistance | 50000 cycles | |
| Seat Foam Density / Rebound Reference | 45 kg/m³ / 65% |
Materials & Structure
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Seat and back upholstery | Grey tufted leather upholstery | |
|---|---|---|
| Cushion core padding | High-density polyurethane foam | |
| Armrest construction | Padded upholstered fixed armrests with steel internal frame | |
| Five-star base | Polished die-cast aluminum alloy | |
| Height adjustment mechanism | Class 3 nitrogen gas lift | |
| Tilt control mechanism | 3 mm thick steel chassis with tilt tension adjustment | |
| Footrest surface | Matching grey upholstered padded surface | |
| Caster material | Black polyurethane dual-wheel casters with metal stems | |
| Internal back frame | 12 mm thick plywood support frame | |
| Seat support platform | 15 mm thick plywood with sinuous spring support | |
| Recline control knob | Chrome-finished plastic adjustment dial | |
| Seat Internal Support Board Thickness | 14 mm bent plywood or equivalent support board |
Functions & Adjustment
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| 360-degree swivel rotation | Full rotating seat and backrest supported by central gas lift | |
|---|---|---|
| Pneumatic height adjustment | Lever-controlled height adjustment for seat to match user desk height | |
| Reclining backrest with lock | Adjustable back tilt with position lock controlled via armrest dial | |
| Tilt tension adjustment | User-adjustable resistance for back recline to match user weight | |
| Retractable built-in footrest | Pull-out padded leg support that stores flush under seat when not in use | |
| Smooth rolling mobility | Dual-wheel casters suitable for hard floors and low-pile carpet | |
| Lumbar support | Integrated tufted padding provides mid-back lumbar contact | |
| Padded head support | Integrated thick head pillow supports neck during upright and reclined positions | |
| Recline Angle / Lock Reference | 125° with 3suggested lock positions | |
| Tilt Tension User-weight Range | Reference adjustment coverage 120 kg | |
| Rotation / Mobility Configuration | 360° swivel with 5-caster multidirectional movement |
Packaging & Logistics
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Carton Dimensions | 850× 420× 720 mm | |
| Reference Packaged Gross Weight | 23 kg/set | |
| Reference Carton Volume | 0.26 m³/set | |
| Indicative 20GP Loading | 135 sets at 85% space utilization | |
| Indicative 40HQ Loading | 320 sets at 85% space utilization |
Applications & Usage
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Executive private offices | High-back reclining design supports long work hours and impromptu rest for management staff | |
|---|---|---|
| Home office workspaces | Neutral grey finish and comfort features suit premium residential work setups | |
| Manager meeting rooms | Professional aesthetic and padded comfort fit formal office meeting spaces | |
| Reclining work positions | Footrest and recline function support short rest breaks during extended work shifts | |
| Commercial office fit-outs | Durable standard components support regular daily use in professional work environments | |
| Recommended Matching Desk Size | 2.4 m executive desk | |
| Reference Daily Use Duration | 8 hours/day; confirm by ergonomic testing |
EU Market Entry Requirements * EN Standards
EU Market Access Requirements* EN Standards
North America Purchasing & Inspection Reference * ANSI/BIFMA Standards
US and Canada office-furniture standards
| North America procurement and testing reference | Recommended references: ANSI/BIFMA X5.1 |
|---|
Standards Applicable to China-Market Projects * GB Standards
Standards applicable to China-market projects
This product must meet the following technical requirements: 1. Technical standards and test reports must be supplied during tender or purchase confirmation; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
