PRODUCT MODULE 01 / 06

Physical Dimensions

Automatic mm / inch conversion · Core engineering specifications

Data source: Structured from factory data; final measured values prevail.

Overall dimensions (W × D × H)	700 × 630 × 1060 mm
Finished Seat Cushion Thickness	90 mm
Backrest Padding Thickness	70 mm
Lumbar Support Zone Height	240 mm
Clear Width Between Armrests	540 mm

PRODUCT MODULE 02 / 06

Weight, Load & Performance

Net weight / load capacity / users / durability

Data source: Product performance data; verify exact test conditions before procurement.

Recommended static load	160 kg
Net weight	15 kg
Stacking quantity	0 chairs
Seating capacity	1 person
Daily-use rating	8 hours
Backrest static proof-load target	100 kg
Arm downward load target	45 kg per arm
Front-foot stability load	70 kg
Seat Foam Density / Rebound Reference	45 kg/m³ / 65%
Back Foam Density Reference	38 kg/m³

PRODUCT MODULE 03 / 06

Materials & Structure

Core acceptance fields · Panels / hardware / frame / upholstery

Data source: Subject to the factory material list and inspection report.

Seat and back upholstery	Beige padded leather-look surface over foam cushioning
Rear back panel	Black vertical accent panel with matching padded border
Arm pads	Black rectangular padded arm caps with 29 mm visible thickness
Arm supports	Black rigid support housing connected to a polished chrome upright
Cantilever frame	Polished chrome-plated bent steel tube forming a continuous sled base
Floor protection	Black non-slip pads at the four floor contact ends

PRODUCT MODULE 04 / 06

Functions & Adjustment

Adjustment / rotation / tilt / mobility / storage features

Data source: Functional configuration; the supplier specification prevails.

Seating adjustment	Fixed 440 mm seat height with no gas lift, tilt, swivel or height mechanism
Back support	Continuous high-back cushion with lumbar transition and upper-back support
Arm support	Fixed padded armrests provide forearm support and side-impact protection
Movement and storage	Cantilever sled base allows short repositioning on smooth floors but does not stack

PRODUCT MODULE 05 / 06

Packaging & Logistics

Verified carton / gross weight / assembly / loading data

Data source: Reference for export quotations and container planning.

Reference Package Count	1 set / 2 cartons
Reference Assembly Time	40 minutes per set
Reference Carton Dimensions	850× 420× 720 mm
Reference Packaged Gross Weight	23 kg/set
Reference Carton Volume	0.26 m³/set
Indicative 20GP Loading	135 sets at 85% space utilization

PRODUCT MODULE 06 / 06

Applications & Usage

Recommended spaces / users / usage modes

Data source: Recommended applications based on product form and category.

Meeting and visitor areas	Suitable for conference rooms, reception lounges and executive visitor seating due to fixed high-back support and 440 mm seat height.
Formal office settings	Pairs with desks or meeting tables in executive and consultation spaces where a non-swiveling, polished chrome guest chair is required.

STANDARD S1

EU Market Entry Requirements * EN Standards

EU Market Access Requirements* EN Standards

No standards data is available for this market.

STANDARD S3

Standards Applicable to China-Market Projects * GB Standards

Standards applicable to China-market projects

No standards data is available for this market.

Standardized tender description text

This product must meet the following technical requirements:
1. Technical standards and test reports must be supplied during tender or purchase confirmation;
Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.

GENERATED EXPORTS

Ready-to-use export tools

Export data is generated from the current published product record.

Technical Report PDF

Directly download an English report in metric or imperial units.

PDF · VC-HB-700630-CB

Complete Parameter Workbook

Download all product information and parameter modules in English.

XLSX · VC-HB-700630-CB

International Listing Template

English title, specifications, materials, standards and purchasing fields.

XLSX · LISTING

Customs Declaration Data

Prepare customs description, material, usage, dimensions and declaration elements.

CUSTOMS · VC-HB-700630-CBOpen Export Tool

Quick Actions

Post an RFQ

Product Description

The Padded High-Back Visitor Chair with Chrome Cantilever Base, model VC-HB-700630-CB, presents a formal guest-seating solution with a tailored, high-back silhouette and a polished metal base. Its beige leather-look upholstery gives the seat and back a refined appearance, while the black rear accent panel, black arm pads, and chrome frame create a structured two-tone profile suited to professional interiors. The continuous backrest rises to support the lumbar transition and upper back, and fixed armrests frame the seating area with rectangular padded caps. The clear width between armrests is 540 mm, and overall dimensions are 700 x 630 x 1060 mm. Comfort is built through layered cushioning rather than moving mechanisms. The finished seat cushion is 90 mm thick, the backrest padding is 70 mm thick, and the lumbar support zone is 240 mm high. A beige padded leather-look surface covers foam cushioning on the seat and back. The rear back combines a black vertical accent panel with a matching padded border. Each armrest uses a black padded cap with 29 mm visible thickness, supported by a black rigid housing connected to a polished chrome upright. The chair is supported by a polished chrome-plated bent steel tube formed into a continuous cantilever sled base. This fixed layout has no gas lift, tilt, swivel, or height adjustment, and the seat height remains fixed at 440 mm. The cantilever form allows short repositioning on smooth floors, while black non-slip pads at all four floor-contact ends help protect flooring. The chair is designed for one person, rated for eight hours of daily use, with a recommended static load of 160 kg. It does not stack, allowing storage plans to be based around individual chair placement rather than nesting. This visitor chair is appropriate for conference rooms, reception lounges, executive visitor seating, consultation spaces, and formal office settings where a non-swiveling guest chair can pair with desks or meeting tables. Its high-back shape and restrained beige, black, and chrome finish support both traditional and polished contemporary schemes. Procurement planning should note that the chair is unbranded and supplied as one set across two cartons, with a packaged gross weight of 23 kg and reference assembly time of 40 minutes per set. Reference carton dimensions are 850 x 420 x 720 mm, with carton volume of 0.26 cubic meters per set and indicative loading of 135 sets in a 20GP container at 85 percent space utilization. Buyers should also account for the fixed seat height, non-stacking design, leather-look upholstery, and matching room décor when specifying this model.

Padded High-Back Visitor Chair with Chrome Cantilever Base Specifications
