PRODUCT MODULE 01 / 06

Physical Dimensions

Automatic mm / inch conversion · Core engineering specifications

Data source: Structured from factory data; final measured values prevail.

Overall dimensions (W × D × H)	580 × 590 × 950 mm
Finished Seat Cushion Thickness	90 mm
Backrest Padding Thickness	70 mm
Lumbar Support Zone Height	240 mm
Clear Width Between Armrests	540 mm

PRODUCT MODULE 02 / 06

Weight, Load & Performance

Net weight / load capacity / users / durability

Data source: Product performance data; verify exact test conditions before procurement.

Recommended occupant weight	160 kg
Net weight per chair	9.5 kg
Seat load area	0.230 m2
Static back-rest verification load	91 kg
Seating capacity	1 person
Floor glide count	4 glides
Cantilever flex test target	100,000 cycles
Stacking or nesting capacity	0 units
Seat Foam Density / Rebound Reference	45 kg/m³ / 65%
Back Foam Density Reference	38 kg/m³

PRODUCT MODULE 03 / 06

Materials & Structure

Core acceptance fields · Panels / hardware / frame / upholstery

Data source: Subject to the factory material list and inspection report.

Seat and back upholstery	Black smooth-surface faux leather over padded panels
Seat cushion	Molded polyurethane foam, 80 mm thick, on a board or steel seat support
Back cushion	Contoured polyurethane foam pad, 70 mm thick at the center
Load-bearing frame	Chrome-finish welded tubular steel cantilever frame with continuous side runners
Arm supports	Curved chrome tubular steel rails with black padded arm tops
Floor contacts	Four black non-marking polymer glides fitted to the runner ends

PRODUCT MODULE 04 / 06

Functions & Adjustment

Adjustment / rotation / tilt / mobility / storage features

Data source: Functional configuration; the supplier specification prevails.

Fixed cantilever support	Continuous sled legs provide slight controlled flex while keeping seat height fixed at 465 mm
Arm support function	Integrated padded arms provide 225 mm support above the seat and connect side frames to the back support
Floor protection	Four polymer end glides isolate the chrome runners from hard floors and reduce lateral sliding
Entry and positioning	Open front sled design permits front-facing access and close placement to meeting tables without casters

PRODUCT MODULE 05 / 06

Packaging & Logistics

Verified carton / gross weight / assembly / loading data

Data source: Reference for export quotations and container planning.

Gross weight per carton	12.5 kg
Reference Package Count	1 set / 2 cartons
Reference Assembly Time	40 minutes per set
Reference Carton Dimensions	850× 420× 720 mm
Reference Packaged Gross Weight	23 kg/set
Reference Carton Volume	0.26 m³/set

PRODUCT MODULE 06 / 06

Applications & Usage

Recommended spaces / users / usage modes

Data source: Recommended applications based on product form and category.

Meeting and conference rooms	Use around standard 760 mm meeting tables because the fixed 465 mm seat and 665 mm arm height support formal seated work.
Reception and visitor areas	Suitable for guest seating in offices, clinics, and waiting zones where padded backs, arms, and hard-floor glides are required.

STANDARD S1

EU Market Entry Requirements * EN Standards

EU Market Access Requirements* EN Standards

Safety and strength requirements	Recommended references: EN 16139:
Office chair safety test levels	EN 1335: use as a structural safety reference where applicable to fixed office seating
Upholstery fabric abrasion	EN 14465: use to document abrasion, pilling, and colorfastness when coated-fabric test data are supplied

STANDARD S2

North America Purchasing & Inspection Reference * ANSI/BIFMA Standards

US and Canada office-furniture standards

Occasional-use seating verification	ANSI/BIFMA X5.11: use for general-purpose occasional seating load and stability tests
Business and institutional seating safety	ANSI/BIFMA X5.1: use selected static load, back strength, and leg-strength clauses

STANDARD S3

Standards Applicable to China-Market Projects * GB Standards

Standards applicable to China-market projects

Office chair mechanical safety	GB/T 28004.1: use for strength, dimensional stability, and safety verification of fixed office visitor seating
Formaldehyde emission for wood-based panels	GB 18580: use if the seat board or internal backing contains wood-based panels
Upholstery leather or coated fabric	GB/T 16799: use for faux-leather abrasion, flexibility, colorfastness, and tear checks

Standardized tender description text

This product must meet the following technical requirements:
1. Office chair mechanical safety: GB/T 28004.1: use for strength, dimensional stability, and safety verification of fixed office visitor seating;
2. Formaldehyde emission for wood-based panels: GB 18580: use if the seat board or internal backing contains wood-based panels;
3. Upholstery leather or coated fabric: GB/T 16799: use for faux-leather abrasion, flexibility, colorfastness, and tear checks;
Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.

GENERATED EXPORTS

Ready-to-use export tools

Export data is generated from the current published product record.

Technical Report PDF

Directly download an English report in metric or imperial units.

PDF · VC-CANT-580-590-BLK

Complete Parameter Workbook

Download all product information and parameter modules in English.

XLSX · VC-CANT-580-590-BLK

International Listing Template

English title, specifications, materials, standards and purchasing fields.

XLSX · LISTING

Customs Declaration Data

Prepare customs description, material, usage, dimensions and declaration elements.

CUSTOMS · VC-CANT-580-590-BLKOpen Export Tool

Quick Actions

Post an RFQ

Product Description

The Black Faux Leather Visitor Chair with Chrome Cantilever Frame and Padded Armrests is a formal meeting and guest seating solution with a clean, streamlined profile. Its black smooth-surface upholstery gives the chair a coordinated appearance, while the exposed chrome-finished tubular steel frame creates a light visual structure suited to professional interiors. The fixed cantilever layout uses continuous sled-style side runners, and the padded seat, contoured back, and integrated armrests provide a conventional visitor-chair silhouette. Overall dimensions are 580 by 590 by 950 mm, with a 540 mm clear width between the armrests. The seat height is fixed at 465 mm, and the arm height is 665 mm from the floor. Construction combines padded comfort with a supportive metal frame. The seat features molded polyurethane foam, 80 mm thick, on a board or steel seat support, with a finished cushion thickness of 90 mm. The backrest uses a contoured polyurethane foam pad that is 70 mm thick at the center and includes a 240 mm high lumbar support zone. Black faux leather covers the padded seat and back panels. The load-bearing structure is a welded tubular steel cantilever frame with a chrome finish and continuous side runners. Curved chrome tubular rails support black padded arm pads, while four black non-marking polymer glides are fitted to the runner ends. The cantilever base offers slight controlled flex while retaining a fixed seat height. Its open front allows front-facing entry and close positioning to meeting tables without casters. The integrated padded arms provide support 225 mm above the seat and connect the side frames to the back support. Four glides separate the chrome runners from hard floors, help reduce lateral sliding, and protect floor surfaces. The chair is designed for one occupant, with a recommended occupant weight of 160 kg. This model is appropriate for conference and meeting rooms, particularly around standard 760 mm meeting tables where formal seated work is required. It is also suitable for reception and visitor use in offices, clinics, and waiting areas that benefit from padded backs, arm support, and hard-floor glides. For procurement planning, each chair weighs 9.5 kg and is supplied unbranded under model VC-CANT-590-BLK. Packaging is referenced as one set across two cartons, with a packaged gross weight of 23 kg per set and carton volume of 0.26 cubic meters per set. Reference assembly time is 40 minutes per set, so purchasers should allow time for unpacking, fitting components, and checking the glides and frame before placement.
