Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 720 x 750 x 1200 mm | |
|---|---|---|
| Finished Seat Cushion Thickness | 90 mm | |
| Backrest Padding Thickness | 70 mm | |
| Lumbar Support Zone Height | 240 mm | |
| Clear Width Between Armrests | 540 mm |
Net weight / load capacity / users / durability
| Net chair weight | 28 kg | |
|---|---|---|
| Maximum user weight capacity | 180 kg | |
| Seat foam density | 45 kg/m³ | |
| Back foam density | 38 kg/m³ | |
| Gas lift stroke length | 100 mm | |
| Tilt mechanism static load rating | 250 kg | |
| Caster rolling durability cycle count | 120000 cycles | |
| Seating surface upholstery abrasion resistance | 50000 rub cycles | |
| Seat Foam Density / Rebound Reference | 45 kg/m³ / 65% | |
| Back Foam Density Reference | 38 kg/m³ |
Core acceptance fields · Panels / hardware / frame / upholstery
| Seat, back and headrest upholstery | 0.9 mm thick faux leather with matching light blue finish | |
|---|---|---|
| Armrest outer side panels | Tan textured faux leather accent panel with chrome-trimmed release button | |
| Armrest support frames | Polished chrome-plated curved steel arm brackets | |
| Internal seat frame | 1.8 mm thick welded steel tube internal frame | |
| Headrest, seat and back padding | Multi-layer high-density polyurethane foam with soft top layer | |
| Five-star base | Polished chrome-plated aluminum alloy five-star swivel base | |
| Gas lift cylinder | Class 4 chrome-plated steel gas lift with black protective collar | |
| Casters | 60 mm diameter dual-wheel black PU casters with chrome accent rings | |
| Reclining mechanism chassis | 2.5 mm thick stamped steel tilt-lock chassis under seat | |
| Retractable footrest | Padded faux leather covered footrest on chrome-plated steel slide rails | |
| Release control button | Chrome-finished metal recline/footrest release button on arm panel | |
| Seat Internal Support Board Thickness | 14 mm bent plywood or equivalent support board |
Adjustment / rotation / tilt / mobility / storage features
| 360-degree swivel rotation | Full rotating seat and back assembly supported by central swivel gas lift | |
|---|---|---|
| Pneumatic seat height adjustment | 100 mm vertical height adjustment via right-side under-seat lever | |
| Backrest recline with lock | Up to 160 degree backward tilt with multi-position locking via arm-side release button | |
| Retractable padded footrest | Slide-out padded footrest that extends 350 mm from seat front for leg support | |
| Fixed ergonomic armrests | Curved padded arm surfaces positioned at 210 mm above seat for forearm support | |
| Integrated head and neck support | Thick contoured attached headrest positioned to support cervical spine during recline | |
| Multi-zone lumbar and back support | Segmented padded back panels with built-in lumbar contour for lower back support | |
| Smooth dual-wheel rolling | PU casters designed for low-noise rolling on hard floors and low-pile carpet | |
| Recline Angle / Lock Reference | 125° with 3suggested lock positions | |
| Tilt Tension User-weight Range | Reference adjustment coverage 120 kg | |
| Rotation / Mobility Configuration | 360° swivel with 5-caster multidirectional movement |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Carton Dimensions | 850× 420× 720 mm | |
| Reference Packaged Gross Weight | 23 kg/set | |
| Reference Carton Volume | 0.26 m³/set | |
| Indicative 20GP Loading | 135 sets at 85% space utilization | |
| Indicative 40HQ Loading | 320 sets at 85% space utilization |
Recommended spaces / users / usage modes
| Executive private office use | Suitable for senior manager and executive offices, providing recline and nap support for long workdays | |
|---|---|---|
| Home office setup | Ideal for premium home offices where users require ergonomic support and casual rest functionality | |
| Managerial meeting rooms | Applicable for high-end meeting rooms where seating comfort for extended sessions is required | |
| Telecommuting workspaces | Suitable for remote work setups requiring adjustable support for seated and reclined positions | |
| Commercial reception executive areas | Appropriate for upscale reception and VIP waiting areas with professional aesthetic | |
| Recommended Matching Desk Size | 2.4 m executive desk | |
| Reference Daily Use Duration | 8 hours/day; confirm by ergonomic testing |
EU Market Access Requirements* EN Standards
| Office chair safety requirement | EN 1335:2020 | |
|---|---|---|
| Office chair structural strength | EN 1335:2018 | |
| Office chair surface flammability | EN 1021:2014 |
US and Canada office-furniture standards
| Office chair general purpose standard | ANSI/BIFMA X2017 | |
|---|---|---|
| Office chair caster durability | ANSI/BIFMA X2017Clause 17 | |
| Office chair gas lift performance | ANSI/BIFMA X2017Clause 8 |
Standards applicable to China-market projects
| Office chair stability requirement | GB/T 10357.2 | |
|---|---|---|
| Office chair strength and durability | GB/T 10357.3 | |
| Upholstered furniture formaldehyde limit | GB 18584 |
This product must meet the following technical requirements: 1. Office chair stability requirement: GB/T 10357.2; 2. Office chair strength and durability: GB/T 10357.3; 3. Upholstered furniture formaldehyde limit: GB 18584; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
