Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 690 x 740 x 1070 mm | |
|---|---|---|
| Seat height from floor | 510 mm | |
| Seat width | 520 mm | |
| Seat depth | 510 mm | |
| Seat pad thickness | 102 mm | |
| Backrest height from seat | 560 mm | |
| Armrest height from floor | 660 mm | |
| Armrest height from seat | 165 mm | |
| Sled base width (front glide span) | 580 mm | |
| Sled base front-to-back depth | 620 mm | |
| Backrest width at shoulder level | 500 mm | |
| Lumbar support contour height from seat | 220 mm | |
| Finished Seat Cushion Thickness | 90 mm | |
| Backrest Padding Thickness | 70 mm | |
| Lumbar Support Zone Height | 240 mm | |
| Clear Width Between Armrests | 540 mm |
Net weight / load capacity / users / durability
| Net product weight | 20 kg | |
|---|---|---|
| Recommended static load capacity | 160 kg | |
| Seat foam density | 45 kg/m³ | |
| Seat foam rebound rate | 45% | |
| Back foam thickness | 80 mm | |
| Frame tube wall thickness | 1.5 mm | |
| Upholstery abrasion resistance | 50000 cycles | |
| Seam stitch pitch | 8 stitches per 30 mm | |
| Seat Foam Density / Rebound Reference | 45 kg/m³ / 65% | |
| Back Foam Density Reference | 38 kg/m³ |
Core acceptance fields · Panels / hardware / frame / upholstery
| Seat upholstery | Smooth grey PU leather cover | |
|---|---|---|
| Backrest upholstery | Matching grey PU leather with contoured lumbar panel | |
| Armrests | Integrated padded armrests upholstered in matching grey material | |
| Cushion core | High-density polyurethane foam padding | |
| Back core | Molded high-density foam with lumbar contour | |
| Internal support frame | Plywood seat and back support board, 12 mm thickness | |
| Base frame | Polished chrome-plated tubular steel cantilever sled base | |
| Floor glides | Injection-molded nylon anti-tip glides at sled base ends | |
| Frame surface finish | Mirror chrome plating over steel tubing | |
| Seat Internal Support Board Thickness | 14 mm bent plywood or equivalent support board | |
| Backrest Internal Frame Thickness | 14 mm bent plywood/composite reinforced frame | |
| Gas-lift Engineering Specification | Recommended Class 4; outer tube 50 mm; stroke 100 mm |
Adjustment / rotation / tilt / mobility / storage features
| Seating adjustment | Fixed non-adjustable seat and back position, no moving mechanisms | |
|---|---|---|
| Swivel function | No 360-degree rotation, fixed stationary orientation | |
| Height adjustment | No gas lift height adjustment, fixed seat height | |
| Recline function | No tilt or recline mechanism, fixed upright back angle | |
| Floor protection | Nylon glides prevent floor scratches and enable smooth repositioning | |
| Arm support | Fixed padded wrap-around armrests provide consistent forearm support | |
| Lumbar support | Contoured built-in lumbar curve aligns with lower back | |
| Stability design | Cantilever sled frame provides gentle flex without tipping under normal use | |
| Recline Angle / Lock Reference | 125° with 3suggested lock positions | |
| Tilt Tension User-weight Range | Reference adjustment coverage 120 kg | |
| Rotation / Mobility Configuration | 360° swivel with 5-caster multidirectional movement |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Carton Dimensions | 850× 420× 720 mm | |
| Reference Packaged Gross Weight | 23 kg/set | |
| Reference Carton Volume | 0.26 m³/set | |
| Indicative 20GP Loading | 135 sets at 85% space utilization | |
| Indicative 40HQ Loading | 320 sets at 85% space utilization |
Recommended spaces / users / usage modes
| Conference room seating | Suitable for fixed placement around meeting tables for attendee use | |
|---|---|---|
| Reception area guest seating | Fits formal front-desk and visitor waiting areas with professional appearance | |
| Executive office guest seating | Positioned across from executive desks for visitor seating | |
| Training room seating | Suitable for multi-purpose training and seminar rooms | |
| Hotel business center seating | Fits hotel meeting and business center public areas | |
| Recommended Matching Desk Size | 2.4 m executive desk | |
| Reference Daily Use Duration | 8 hours/day; confirm by ergonomic testing |
EU Market Access Requirements* EN Standards
| EN 1335-1:2020 | Applicable standard for office chair dimensions and safety requirements | |
|---|---|---|
| EN 1335-2:2018 | Applicable standard for office chair structural strength and stability | |
| EN 1022:2018 | Applicable standard for seating stability testing for domestic and contract use |
US and Canada office-furniture standards
| ANSI/BIFMA X5.1-2017 | Applicable standard for commercial office chair general purpose tests | |
|---|---|---|
| ANSI/BIFMA X5.4-2020 | Applicable standard for lounge and public seating structural performance |
Standards applicable to China-market projects
| GB/T 3324-2017 | Applicable general technical standard for metal furniture | |
|---|---|---|
| GB 18584-2001 | Applicable limit standard for formaldehyde release in wooden furniture components |
This product must meet the following technical requirements: 1. GB/T 3324-2017: Applicable general technical standard for metal furniture; 2. GB 18584-2001: Applicable limit standard for formaldehyde release in wooden furniture components; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
