Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 700 x 760 x 1140 mm | |
|---|---|---|
| Seat width | 630 mm | |
| Seat depth | 500 mm | |
| Seat height (adjusted maximum) | 597 mm | |
| Backrest height | 740 mm | |
| Five-star base diameter | 700 mm | |
| Caster diameter | 60 mm | |
| Retractable footrest extension length | 420 mm | |
| Armrest height above seat | 220 mm | |
| Seat pad thickness | 120 mm | |
| Finished Seat Cushion Thickness | 90 mm | |
| Backrest Padding Thickness | 70 mm | |
| Lumbar Support Zone Height | 240 mm | |
| Clear Width Between Armrests | 540 mm |
Net weight / load capacity / users / durability
| Recommended user weight capacity | 182 kg | |
|---|---|---|
| Net weight (assembled) | 50 kg | |
| Recline angle (locked maximum) | 155 degrees | |
| Gas lift height adjustment travel | 120 mm | |
| Base static load rating | 1000 kg | |
| Caster rolling durability | 1609 km | |
| Warranty period | 3 years | |
| Seam stitch pitch | 8 stitches per inch | |
| Seat Foam Density / Rebound Reference | 45 kg/m³ / 65% | |
| Back Foam Density Reference | 38 kg/m³ |
Core acceptance fields · Panels / hardware / frame / upholstery
| Seat and back upholstery | Top-grain olive leather, 1.2mm thickness, abrasion-resistant finish | |
|---|---|---|
| Cushion core material | High-density cold-cure foam, 45kg/m³ density, 60% rebound rate | |
| Internal support frame | 2mm thick welded steel tube frame, rust-resistant powder coating | |
| Armrest structure | Padded leather wrap with polished chrome top trim, rigid steel inner bracket | |
| Five-star base | 1.5mm thick chrome-plated steel, polished mirror finish | |
| Caster wheels | Dual-wheel PU soft casters, black finish with chrome accent rings | |
| Recline mechanism | 3mm thick steel tilt chassis, tension adjustment dial | |
| Retractable footrest | Padded leather top, chrome-plated steel support rails | |
| Gas lift cylinder | Class 4 steel gas lift, 50mm outer tube diameter, chrome finish | |
| Seat Internal Support Board Thickness | 14 mm bent plywood or equivalent support board | |
| Backrest Internal Frame Thickness | 14 mm bent plywood/composite reinforced frame | |
| Tilt Mechanism Plate Thickness | 2.5 mm cold-rolled steel |
Adjustment / rotation / tilt / mobility / storage features
| 360-degree swivel rotation | Full free rotation enabled by central gas lift and base assembly | |
|---|---|---|
| Seat height adjustment | Pneumatic height control via side lever, 120mm total travel | |
| Multi-position recline lock | Tilt lock at 3 positions between 90 and 155 degrees, tension adjustable | |
| Retractable footrest operation | Slides out 420mm from under seat, tucks flush when not in use | |
| Smooth caster mobility | Soft PU casters roll on hard floors and carpet without scratching | |
| Segmented lumbar support | Three padded back zones provide natural lumbar and upper back support | |
| Fixed padded armrests | Stationary armrests offer stable forearm support during work and recline | |
| Waterfall seat edge design | Curved front seat edge reduces leg pressure during long seating sessions | |
| Recline Angle / Lock Reference | 125° with 3suggested lock positions | |
| Tilt Tension User-weight Range | Reference adjustment coverage 120 kg | |
| Rotation / Mobility Configuration | 360° swivel with 5-caster multidirectional movement |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Carton Dimensions | 850× 420× 720 mm | |
| Reference Packaged Gross Weight | 23 kg/set | |
| Reference Carton Volume | 0.26 m³/set | |
| Indicative 20GP Loading | 135 sets at 85% space utilization | |
| Indicative 40HQ Loading | 320 sets at 85% space utilization |
Recommended spaces / users / usage modes
| Private executive office | Premium seating for C-suite and management private office spaces | |
|---|---|---|
| Home office study | Reclining function supports both work and midday rest for home use | |
| Manager meeting room | Professional appearance fits small executive meeting and discussion rooms | |
| High-end reception area | Upscale olive leather finish creates premium impression for visitor seating | |
| Long-duration desk work | Ergonomic padding and lumbar support suit 8+ hour daily seating use | |
| Midday rest scenarios | 155-degree recline and extended footrest support short naps at work | |
| Recommended Matching Desk Size | 2.4 m executive desk | |
| Reference Daily Use Duration | 8 hours/day; confirm by ergonomic testing |
EU Market Access Requirements* EN Standards
| EN 1335-1:2020 | Applies to office chair dimensional, safety and strength requirements for office work seating | |
|---|---|---|
| EN 1335-2:2018 | Applies to office chair mechanical safety performance test methods |
US and Canada office-furniture standards
| ANSI/BIFMA X5.1-2017 | Applies to general-purpose office chair structural durability and load performance testing | |
|---|---|---|
| ANSI/BIFMA X5.11-2015 | Applies to big-and-tall office chair load and durability requirements for heavier users |
Standards applicable to China-market projects
| GB/T 3326-2016 | Applies to office chair dimension, strength and durability testing for furniture desks and chairs | |
|---|---|---|
| GB/T 28007-2011 | Applies to upholstered office chair safety and performance requirements for commercial use |
This product must meet the following technical requirements: 1. GB/T 3326-2016: Applies to office chair dimension, strength and durability testing for furniture desks and chairs; 2. GB/T 28007-2011: Applies to upholstered office chair safety and performance requirements for commercial use; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
