Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 680 x 720 x 1280 mm | |
|---|---|---|
| Seat width | 520 mm | |
| Seat depth | 500 mm | |
| Seat height range | 460 mm | |
| Backrest height | 780 mm | |
| Headrest dimensions | 480 x 180 mm | |
| Armrest height above seat | 210 mm | |
| 5-star base diameter | 700 mm | |
| Caster diameter | 60 mm | |
| Finished Seat Cushion Thickness | 90 mm | |
| Backrest Padding Thickness | 70 mm | |
| Lumbar Support Zone Height | 240 mm | |
| Clear Width Between Armrests | 540 mm |
Net weight / load capacity / users / durability
| Suggested static load capacity | 150 kg | |
|---|---|---|
| Net weight reference | 22 kg | |
| Foam density (seat cushion) | 45 kg/m³ | |
| Foam thickness (seat cushion) | 100 mm | |
| Tilt mechanism recline angle | 15° | |
| Caster rolling durability reference | 100000 cycles | |
| Stitch pitch | 6 mm | |
| Warranty reference (structure) | 5 years | |
| Seat Foam Density / Rebound Reference | 45 kg/m³ / 65% | |
| Back Foam Density Reference | 38 kg/m³ |
Core acceptance fields · Panels / hardware / frame / upholstery
| Upholstery surface | Black smooth faux leather (PU) face with matte finish | |
|---|---|---|
| Seat and back foam core | Dense polyurethane foam with layered padding structure | |
| Internal seat-back frame | Plywood and steel reinforcing frame | |
| Armrest structure | Polished aluminum square-tube frame with black padded top | |
| Base frame | Polished die-cast aluminum 5-leg spider | |
| Height adjustment cylinder | Chrome-plated steel gas lift with black plastic collar | |
| Tilt mechanism | Black powder-coated steel synchronous tilt plate under seat | |
| Casters | Dual-wheel PU casters with black tread and silver hub ring | |
| Thread and trim | Matching black top-stitched seams on all upholstered panels | |
| Seat Internal Support Board Thickness | 14 mm bent plywood or equivalent support board | |
| Backrest Internal Frame Thickness | 14 mm bent plywood/composite reinforced frame | |
| Gas-lift Engineering Specification | Recommended Class 4; outer tube 50 mm; stroke 100 mm |
Adjustment / rotation / tilt / mobility / storage features
| Seat height adjustment | Pneumatic lift controlled by right-side lever, providing 120 mm vertical travel | |
|---|---|---|
| Synchronous tilt recline | Mechanism tilts seat and back together up to 15° with user weight tension adjustment | |
| Tilt lock | Lockable in upright position via front lever, with tension dial for recline resistance | |
| 360° swivel | Full rotation around central gas-lift axis on precision bearing | |
| Mobility | Five dual-wheel casters enable smooth rolling across floor surfaces | |
| Integrated headrest support | Fixed-position padded headrest extension at top of high back | |
| Fixed armrests | Rigid aluminum-framed armrests at fixed height for forearm support | |
| Gas lift stroke | 120 mm | |
| Recline Angle / Lock Reference | 125° with 3 suggested lock positions | |
| Tilt Tension User-weight Range | Reference adjustment coverage 120 kg | |
| Rotation / Mobility Configuration | 360° swivel with 5-caster multidirectional movement |
Verified carton / gross weight / assembly / loading data
| Number of cartons | 1 | |
|---|---|---|
| Carton dimensions | 850 x 650 x 450 mm | |
| Gross weight | 26 kg | |
| Volume per carton | 0.249 m³ | |
| Assembly time | 30 minutes | |
| 20 ft container loading quantity | 180 units | |
| Reference Package Count | 1 set / 2 cartons | |
| Reference Assembly Time | 40 minutes per set | |
| Reference Carton Dimensions | 850× 420× 720 mm | |
| Reference Packaged Gross Weight | 23 kg/set |
Recommended spaces / users / usage modes
| Private executive office | Suitable for C-suite and senior manager workstations as a primary task and visitor seating chair | |
|---|---|---|
| Conference and boardroom | Appropriate for head-of-table or premium meeting room seating to convey professional executive image | |
| Modern open-plan workstations | Can be used by senior staff in open offices where a premium ergonomic chair is required | |
| Reception and lounge areas | Works as high-end guest seating in lobbies or waiting areas of design-focused firms | |
| Home office premium setup | Suitable for residential home offices seeking commercial-grade build and executive styling | |
| Recommended Matching Desk Size | 2.4 m executive desk | |
| Reference Daily Use Duration | 8 hours/day; confirm by ergonomic testing |
EU Market Access Requirements* EN Standards
US and Canada office-furniture standards
| North America procurement and testing reference | ANSI/BIFMA X5.1 General-Purpose Office Chairs |
|---|
Standards applicable to China-market projects
This product must meet the following technical requirements: 1. Technical standards and test reports must be supplied during tender or purchase confirmation; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
