Grey Upholstered Cantilever Visitor Chair with Fixed Armrests (model VC-CF-640-960-GRY) is listed under Executive Boss Chair. Dimensions: 640 × 620 × 960 mm. Materials: Grey padded leather-look surface over shaped foam; exact leather, PU or PVC grade requires BOM confirmation. Load capacity: 160 kg. Product Features: grey,upholstery,cantilever,sled,base,fixed,armrests,visitor,chair,padded,back. This page consolidates 6 groups of specifications and GB / EN / ANSI/BIFMA standard references, with metric and imperial units. 1 supplier(s) are listed and you can request a quote online.
| Brand | FENGGUAN | Model | VC-CF-640-960-GRY |
| Overall dimensions (W × D × H) | 640 × 620 × 960 mm | Finished Seat Cushion Thickness | 90 mm |
| Backrest Padding Thickness | 70 mm | Lumbar Support Zone Height | 240 mm |
| Clear Width Between Armrests | 540 mm | Net weight | 11 kg |
| Rated static load | 160 kg | Recommended user weight | 120 kg |
| Seating capacity | 1 person | Stacking quantity | 0 chairs |
| Back tilt angle | 10 degrees | Seat foam density | 35 kg/m3 |
| Back foam density | 30 kg/m3 | Foam rebound | 35 percent |
| Warranty | 5 years | Seat upholstery | Grey padded leather-look surface over shaped foam; exact leather, PU or PVC grade requires BOM confirmation |
| Back upholstery | Grey padded leather-look facing with continuous contoured back panel | Cushion core | Molded polyurethane foam with an 80 mm seat layer and 70 mm back layer |
| Load-bearing frame | Black powder-coated bent steel tube forming a one-piece cantilever sled base | Arm supports | Black rigid molded or steel-reinforced supports with flat padded arm caps |
| Floor contact parts | Black polymer glides at four runner ends to protect flooring and reduce slip | Fixed seating position | Cantilever frame provides slight controlled flex without swivel, height adjustment or recline lock |
| Arm support | Fixed armrests provide a 670 mm top height and side support during meetings or waiting use | Floor protection | Four end glides distribute load and allow controlled repositioning on hard floors |
| Maintenance access | Detachable upholstery group is expected to be bolted to the frame under the seat for service replacement | Gross weight per carton | 13 kg |
| Reference Package Count | 1 set / 2 cartons | Reference Assembly Time | 40 minutes per set |
| Reference Carton Dimensions | 850× 420× 720 mm | Reference Packaged Gross Weight | 23 kg/set |
| Reference Carton Volume | 0.26 m³/set | Meeting and conference rooms | Fixed padded seating with armrests suits conference rooms where a consistent 450 mm seat height is required |
| Reception and waiting areas | Grey upholstery and black sled base provide durable visitor seating for reception, lobby and guest zones | — | — |
| Time | Field | Original Value | Corrected Value | Note / Status |
|---|---|---|---|---|
No correction records yet. Found an error? Click the flag at the end of a row to report it. | ||||
Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall dimensions (W × D × H) | 640 × 620 × 960 mm | |
|---|---|---|
| Finished Seat Cushion Thickness | 90 mm | |
| Backrest Padding Thickness | 70 mm | |
| Lumbar Support Zone Height | 240 mm | |
| Clear Width Between Armrests | 540 mm |
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Net weight | 11 kg | |
|---|---|---|
| Rated static load | 160 kg | |
| Recommended user weight | 120 kg | |
| Seating capacity | 1 person | |
| Stacking quantity | 0 chairs | |
| Back tilt angle | 10 degrees | |
| Seat foam density | 35 kg/m3 | |
| Back foam density | 30 kg/m3 | |
| Foam rebound | 35 percent | |
| Warranty | 5 years |
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Seat upholstery | Grey padded leather-look surface over shaped foam; exact leather, PU or PVC grade requires BOM confirmation | |
|---|---|---|
| Back upholstery | Grey padded leather-look facing with continuous contoured back panel | |
| Cushion core | Molded polyurethane foam with an 80 mm seat layer and 70 mm back layer | |
| Load-bearing frame | Black powder-coated bent steel tube forming a one-piece cantilever sled base | |
| Arm supports | Black rigid molded or steel-reinforced supports with flat padded arm caps | |
| Floor contact parts | Black polymer glides at four runner ends to protect flooring and reduce slip |
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Fixed seating position | Cantilever frame provides slight controlled flex without swivel, height adjustment or recline lock | |
|---|---|---|
| Arm support | Fixed armrests provide a 670 mm top height and side support during meetings or waiting use | |
| Floor protection | Four end glides distribute load and allow controlled repositioning on hard floors | |
| Maintenance access | Detachable upholstery group is expected to be bolted to the frame under the seat for service replacement |
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Gross weight per carton | 13 kg | |
|---|---|---|
| Reference Package Count | 1 set / 2 cartons | |
| Reference Assembly Time | 40 minutes per set | |
| Reference Carton Dimensions | 850× 420× 720 mm | |
| Reference Packaged Gross Weight | 23 kg/set | |
| Reference Carton Volume | 0.26 m³/set |
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Meeting and conference rooms | Fixed padded seating with armrests suits conference rooms where a consistent 450 mm seat height is required | |
|---|---|---|
| Reception and waiting areas | Grey upholstery and black sled base provide durable visitor seating for reception, lobby and guest zones |
EU Market Access Requirements* EN Standards
| Strength and durability recommendation | EN 16139:2013+AC:2013 applies to non-domestic seating strength, durability and safety verification. | |
|---|---|---|
| Office chair safety recommendation | EN 1335:2018 provides safety requirements relevant when this visitor chair is used in office environments. | |
| Office chair dimension recommendation | EN 1335:2020 provides dimensional fit criteria for office seating comparison. |
US and Canada office-furniture standards
| Seating durability recommendation | ANSI/BIFMA X2023applies to lounge and public-office seating static, impact and cyclic load acceptance. |
|---|
Standards applicable to China-market projects
| Furniture safety recommendation | GB/T 3324applies to dimensional, structural and workmanship checks for wooden and upholstered furniture components. | |
|---|---|---|
| Upholstered furniture fire recommendation | GB 17927applies when specified for upholstered furniture flame-retardant acceptance in China. |
This product must meet the following technical requirements: 1. Furniture safety recommendation: GB/T 3324applies to dimensional, structural and workmanship checks for wooden and upholstered furniture components.; 2. Upholstered furniture fire recommendation: GB 17927applies when specified for upholstered furniture flame-retardant acceptance in China.; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
