PRODUCT MODULE 01 / 06

Physical Dimensions

Automatic mm / inch conversion · Core engineering specifications

Data source: Structured from factory data; final measured values prevail.

Overall dimensions (W × D × H)	680 × 700 × 1010 mm
Finished Seat Cushion Thickness	90 mm
Backrest Padding Thickness	70 mm
Lumbar Support Zone Height	240 mm
Clear Width Between Armrests	540 mm

PRODUCT MODULE 02 / 06

Weight, Load & Performance

Net weight / load capacity / users / durability

Data source: Product performance data; verify exact test conditions before procurement.

Recommended user weight capacity	135 kg
Net weight	17.5 kg
Seat cushion foam density	45 kg/m3
Back cushion foam density	35 kg/m3
Foam rebound resilience	40%
Fabric or leather abrasion acceptance	50,000 cycles
Gas-lift cyclic durability	100,000 cycles
Caster rolling durability	100,000 cycles
Base static-load verification	1,130 kg
Seat Foam Density / Rebound Reference	45 kg/m³ / 65%

PRODUCT MODULE 03 / 06

Materials & Structure

Core acceptance fields · Panels / hardware / frame / upholstery

Data source: Subject to the factory material list and inspection report.

Seat and back upholstery	Orange upholstered facing over padded cushioning
Rear back shell	Black molded polymer shell with tapered outer profile
Armrest assembly	Black molded support with light-colored rigid arm pad
Five-star base	Polished die-cast aluminum five-star base
Gas lift	Chrome-plated steel telescopic gas lift
Casters	Black twin-wheel swivel casters, five units

PRODUCT MODULE 04 / 06

Functions & Adjustment

Adjustment / rotation / tilt / mobility / storage features

Data source: Functional configuration; the supplier specification prevails.

Swivel function	360-degree swivel around the central gas-lift axis
Seat height adjustment	Pneumatic lever adjusts seat height through a 100 mm engineering travel
Back recline control	Under-seat tilt mechanism with lever and tension control, engineered for a 12-degree recline
Fixed arm support	Non-folding armrests provide forearm support at 90 mm above the seat

PRODUCT MODULE 05 / 06

Packaging & Logistics

Verified carton / gross weight / assembly / loading data

Data source: Reference for export quotations and container planning.

Carton dimensions	820 x 660 x 360 mm
Reference Package Count	1 set / 2 cartons
Reference Assembly Time	40 minutes per set
Reference Carton Dimensions	850× 420× 720 mm
Reference Packaged Gross Weight	23 kg/set
Reference Carton Volume	0.26 m³/set

PRODUCT MODULE 06 / 06

Applications & Usage

Recommended spaces / users / usage modes

Data source: Recommended applications based on product form and category.

Executive and private office use	Suitable for desks, managers' offices, and conference rooms due to its upholstered mid-back support and mobile swivel base.
Workstation and meeting applications	Suitable for daily computer work and discussion seating where quiet mobility and a compact 680 mm footprint are required.

STANDARD S1

EU Market Entry Requirements * EN Standards

EU Market Access Requirements* EN Standards

No standards data is available for this market.

STANDARD S2

North America Purchasing & Inspection Reference * ANSI/BIFMA Standards

US and Canada office-furniture standards

North America procurement and testing reference	Recommended references: ANSI/BIFMA X5.1

STANDARD S3

Standards Applicable to China-Market Projects * GB Standards

Standards applicable to China-market projects

No standards data is available for this market.

Standardized tender description text

This product must meet the following technical requirements:
1. Technical standards and test reports must be supplied during tender or purchase confirmation;
Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.

GENERATED EXPORTS

Ready-to-use export tools

Export data is generated from the current published product record.

Technical Report PDF

Directly download an English report in metric or imperial units.

PDF · EC-MB-PAD-AL5

Complete Parameter Workbook

Download all product information and parameter modules in English.

XLSX · EC-MB-PAD-AL5

International Listing Template

English title, specifications, materials, standards and purchasing fields.

XLSX · LISTING

Customs Declaration Data

Prepare customs description, material, usage, dimensions and declaration elements.

CUSTOMS · EC-MB-PAD-AL5Open Export Tool

Quick Actions

Post an RFQ

Product Description

The Mid-Back Upholstered Swivel Executive Chair, model EC-MB-PAD-AL5, presents a tailored executive seating solution with a distinct orange and black visual character. Its upholstered seat and back create a warm, prominent focal point, while the black molded polymer rear shell provides a structured contrast with a tapered outer profile. The fixed armrests extend from the chair body in matching black supports, finished with light-colored rigid arm pads, and the polished die-cast aluminum five-star base adds a refined metallic foundation. Five black twin-wheel swivel casters complete the mobile base and support movement across floor surfaces. Construction balances cushioning, molded support, and durable metal components. The seat features orange upholstered facing over padded cushioning with a finished cushion thickness of 90 mm and 45 kg/m3 foam density. The backrest includes 70 mm of padding at 35 kg/m3 foam density and a defined lumbar support zone height of 240 mm. The upholstery material carries a fabric or leather abrasion acceptance of 50,000 cycles, and the foam provides 40% rebound resilience. A chrome-plated steel telescopic gas lift connects the seating mechanism to the polished aluminum base, which supports a recommended user weight capacity of 135 kg. The chair has a net weight of 17.5 kg. Functional features are designed for everyday office use. The chair rotates 360 degrees around the central gas-lift axis, and a pneumatic lever adjusts seat height through 100 mm of engineering travel. An under-seat tilt mechanism includes a lever and tension control, engineered for a 12-degree recline. The non-folding armrests provide fixed forearm support positioned 90 mm above the seat, with 540 mm of clear width between them. These features make the chair suitable for executive and private offices, desks, managers' offices, conference rooms, workstations, and meeting settings where daily computer work or discussion seating is required. Its compact 680 mm footprint is useful where space planning calls for quiet mobility without a broad visual scale. Overall dimensions are 680 x 700 x 1010 mm. Procurement planning should account for one set supplied in two cartons, a reference packaged gross weight of 23 kg per set, and reference carton volume of 0.26 m3 per set. Stated carton dimensions include 820 x 660 x 360 mm and reference carton dimensions of 850 x 420 x 720 mm. Reference assembly time is 40 minutes per set, so buyers should plan for receiving space, assembly labor, and compatibility with intended desk heights and floor conditions. The chair is offered as an unbranded product, making it suitable for projects where a defined accent color, mid-back support, swivel mobility, and professional executive styling are priorities.

Mid-Back Upholstered Swivel Executive Chair Specifications
