PRODUCT MODULE 01 / 06

Physical Dimensions

Automatic mm / inch conversion · Core engineering specifications

Data source: Structured from factory data; final measured values prevail.

Overall dimensions (W × D × H)	580 × 600 × 900 mm
Finished Seat Cushion Thickness	90 mm
Backrest Padding Thickness	70 mm
Lumbar Support Zone Height	240 mm
Clear Width Between Armrests	540 mm

PRODUCT MODULE 02 / 06

Weight, Load & Performance

Net weight / load capacity / users / durability

Data source: Product performance data; verify exact test conditions before procurement.

Recommended user weight capacity	120 kg
Net weight per chair	11 kg
Seating capacity	1 person
Static seat verification load	150 kg
Backrest static verification load	70 kg
Cantilever flex fatigue reference	100000 loading cycles
Caster-free floor stability	4 contact points
Color options for procurement	1 standard black upholstery color
Seat Foam Density / Rebound Reference	45 kg/m³ / 65%
Back Foam Density Reference	38 kg/m³

PRODUCT MODULE 03 / 06

Materials & Structure

Core acceptance fields · Panels / hardware / frame / upholstery

Data source: Subject to the factory material list and inspection report.

Seat upholstery	Black padded upholstered surface with smooth grain and sewn front edge
Backrest upholstery	Black padded rectangular back panel with slight side contour
Arm pads	Black padded arm caps following the top curve of each arm support
Cantilever frame	Polished chrome-plated tubular steel continuous sled frame
Frame tube specification	25 mm diameter round tube with 1.5 mm wall thickness
Floor glides	Black replaceable polymer end caps bonded over the tube ends

PRODUCT MODULE 04 / 06

Functions & Adjustment

Adjustment / rotation / tilt / mobility / storage features

Data source: Functional configuration; the supplier specification prevails.

Cantilever rocking response	Fixed sled base provides controlled flex under seated movement, with no tilt-lock or recline mechanism
Arm support	Fixed curved armrests provide 200 mm support above the seat and cannot be height or width adjusted
Floor protection	Four polymer glides isolate the chrome tube ends from hard floors and reduce sliding noise
Stacking capability	Non-stacking individual chair configuration

PRODUCT MODULE 05 / 06

Packaging & Logistics

Verified carton / gross weight / assembly / loading data

Data source: Reference for export quotations and container planning.

Reference Package Count	1 set / 2 cartons
Reference Assembly Time	40 minutes per set
Reference Carton Dimensions	850× 420× 720 mm
Reference Packaged Gross Weight	23 kg/set
Reference Carton Volume	0.26 m³/set
Indicative 20GP Loading	135 sets at 85% space utilization

PRODUCT MODULE 06 / 06

Applications & Usage

Recommended spaces / users / usage modes

Data source: Recommended applications based on product form and category.

Meeting and conference rooms	Fixed 450 mm seat height and padded upright back support short-to-medium meetings at standard 750 mm tables
Visitor and reception areas	Black upholstery with polished chrome frame provides a formal appearance and four-point stable seating for guests

STANDARD S1

EU Market Entry Requirements * EN Standards

EU Market Access Requirements* EN Standards

EN 16139	Applies to strength, durability, and safety requirements for non-domestic seating
EN 1022	Applies to seating stability determination for upright visitor and meeting chairs
EN 12524	Applies to upholstery furniture fabric and leather classification terminology when material grade is supplied

STANDARD S2

North America Purchasing & Inspection Reference * ANSI/BIFMA Standards

US and Canada office-furniture standards

ANSI/BIFMA X5.4	Applies to lounge and public-office seating strength, durability, and stability verification

STANDARD S3

Standards Applicable to China-Market Projects * GB Standards

Standards applicable to China-market projects

GB/T 10357.2	Applies to chair mechanical and structural stability test methods for procurement verification
GB/T 10357.3	Applicable standards and test results require confirmation
GB 18584	Applies to indoor furniture limit values for formaldehyde emission in wood-based components

Standardized tender description text

This product must meet the following technical requirements:
1. GB/T 10357.2: Applies to chair mechanical and structural stability test methods for procurement verification;
2. GB/T 10357.3: Applicable standards and test results require confirmation;
3. GB 18584: Applies to indoor furniture limit values for formaldehyde emission in wood-based components;
Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.

GENERATED EXPORTS

Ready-to-use export tools

Export data is generated from the current published product record.

Technical Report PDF

Directly download an English report in metric or imperial units.

PDF · FG-1806C

Complete Parameter Workbook

Download all product information and parameter modules in English.

XLSX · FG-1806C

International Listing Template

English title, specifications, materials, standards and purchasing fields.

XLSX · LISTING

Customs Declaration Data

Prepare customs description, material, usage, dimensions and declaration elements.

CUSTOMS · FG-1806COpen Export Tool

Quick Actions

Post an RFQ

Product Description

The Black Upholstered Visitor Chair with Chrome Cantilever Frame, model FG-1806C, is an unbranded visitor and meeting chair designed for formal seating in conference, reception, and guest environments. Its appearance balances a smooth black upholstered seat and back with a polished chrome continuous sled frame, creating a clean, professional silhouette that suits both traditional and contemporary interiors. The chair presents a rectangular padded back panel with a slight side contour and a defined lumbar support zone, paired with a generously padded seat finished with a sewn front edge. Fixed curved armrests carry matching black padded arm caps that follow the top curve of each support. The clear width between the armrests is 540 mm, while the seat cushion is 90 mm thick and the backrest padding is 70 mm thick. These elements create an upright, supportive profile suited to short-to-medium meetings. Construction centers on a chrome-plated tubular steel cantilever frame made from 25 mm diameter round tube with 1.5 mm wall thickness. The continuous sled base has four floor contact points and is fitted with black replaceable polymer glides bonded over the tube ends. These glides separate the chrome frame from hard floor surfaces and help reduce sliding noise. The fixed frame provides controlled flex during seated movement, without a tilt-lock or recline mechanism. The armrests are fixed and positioned 200 mm above the seat, with no height or width adjustment. The chair is a non-stacking, single-person configuration. Rated for a recommended user weight of 120 kg, the chair has a net weight of 11 kg. Static seat verification is documented at 150 kg, backrest static verification at 70 kg, and the cantilever flex fatigue reference is 100000 loading cycles. Its caster-free four-point base contributes to stable guest seating. The model is appropriate for meeting and conference rooms used with standard 750 mm tables, thanks to its fixed 450 mm seat height and padded upright back. It is also well suited to visitor and reception areas where the black upholstery and polished chrome frame deliver a formal, organized look. For procurement, buyers should note that each set is supplied in two cartons, with a packaged gross weight of 23 kg and a carton volume of 0.26 cubic meter. Reference assembly time is 40 minutes per set, and an indicative 20GP container load is 135 sets at 85 percent space utilization. Replacement glides may be worth carrying for high-traffic installations, while the non-stacking design should be considered where floor storage space is limited.

Black Upholstered Visitor Chair with Chrome Cantilever Frame Specifications
