| Submitted | Field | Original | 修改后参数 | Note / Status |
|---|---|---|---|---|
No corrections yet. Use the flag at the end of a row to report an issue. | ||||
Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 660 x 680 x 1020 mm | |
|---|---|---|
| Seat height | 450 mm | |
| Seat width | 510 mm | |
| Seat depth | 480 mm | |
| Backrest total height | 640 mm | |
| Seat cushion thickness | 80 mm | |
| Armrest height above seat | 200 mm | |
| Sled base footprint width | 580 mm | |
| Sled base depth (front to rear floor contact) | 620 mm | |
| Backrest lumbar zone height | 180 mm above seat | |
| Finished Seat Cushion Thickness | 90mm | |
| Backrest Padding Thickness | 70mm | |
| Lumbar Support Zone Height | 240mm | |
| Clear Width Between Armrests | 540mm |
Net weight / load capacity / users / durability
| Estimated net weight | 17kg | |
|---|---|---|
| Static seat load capacity | 136 kg / 300 lbs | |
| Recommended user weight limit | 120 kg | |
| Cantilever frame static load test reference | ≥15000 cycles without structural deformation | |
| Applicable user count | Single occupant | |
| Estimated net product weight | 17.5 kg | |
| Recommended maximum occupant weight | 120 kg | |
| Cantilever frame durability reference | ≥20000 dynamic flex cycles without permanent deformation | |
| Upholstery seam strength | ≥200 N per seam | |
| Seat Foam Density / Rebound Reference | 45kg/m³ / 65% |
Core acceptance fields · Panels / hardware / frame / upholstery
| Seat and back upholstery | Smooth light gray polyurethane (PU) faux leather | |
|---|---|---|
| Seat cushion core | 45kg/m³ high-density polyurethane foam | |
| Backrest cushion core | 35kg/m³ medium-density polyurethane foam | |
| Cantilever support frame | 22mm diameter chrome-plated steel tube, wall thickness 1.5mm | |
| Armrest structure | Steel inner frame wrapped in matching light gray PU upholstery over foam padding | |
| Floor contact glides | Injection molded non-marking nylon glides | |
| Internal back support panel | 12mm thick molded plywood | |
| Upholstery seam stitch pitch | 3 stitches per cm / 8 stitches per inch | |
| Armrest assembly | 12mm diameter curved steel inner support, wrapped in 20mm PU foam and matching light gray PU upholstery | |
| Internal back support substrate | 12mm thick molded beech plywood, shaped to match ergonomic back contour | |
| Internal seat support substrate | 15mm thick multi-layer plywood, bonded to seat foam core | |
| Upholstery construction | Double-stitched seam with bonded nylon thread, 3 stitches per cm (8 stitches per inch) pitch |
Adjustment / rotation / tilt / mobility / storage features
| Seating support | Fixed cantilever sled design, no swivel, height adjustment or tilt, provides gentle flex for dynamic seated comfort | |
|---|---|---|
| Fixed arm support | Integrated curved upholstered armrests fixed permanently at 210mm above seat surface, aligned to standard 750mm desk height to support neutral forearm posture during meetings | |
| Ergonomic back support | Contoured two-section backrest with horizontal seam defining a built-in lumbar curve at 220mm above seat, supporting upright seated posture during 2 hour meeting sessions | |
| Floor protection | Non-marking glides on all base feet allow smooth repositioning on hard floors without scratching | |
| Cantilever flex | Chrome steel frame provides ~10 degrees of controlled backward flex under seated load without mechanical tilting mechanism | |
| Use case flexibility | Fixed design requires no user adjustment, ready for immediate use in meeting or guest seating | |
| Seating support behavior | Fixed cantilever sled base design, no swivel, height adjustment, casters or tilt mechanism; steel frame provides 12 degrees of controlled backward flex under seated load to reduce static sitting pressure without mechanical adjustment | |
| Floor protection and repositioning | Non-marking rubber-padded nylon glides on all four base contact points allow quiet repositioning on wood, tile, and vinyl hard floors without scratching or leaving marks; glides produce minimal noise when chairs are shifted under tables | |
| Anti-tip stability | 610mm front-to-back sled floor contact span prevents tipping during normal rearward leaning, eliminating need for rear anti-tip protrusions that catch on carpet or flooring gaps | |
| No-assembly use preparation | Chairs are shipped nearly fully assembled, only requiring minor glide fitting or bolt tightening before deployment for immediate guest/meeting use | |
| Recline Angle / Lock Reference | 125° with 3 suggested lock positions | |
| Tilt Tension User-weight Range | Reference adjustment coverage 120kg |
Verified carton / gross weight / assembly / loading data
| Number of packages | 1 unit per carton | |
|---|---|---|
| Reference carton dimensions | 700 x 450 x 650 mm | |
| Reference gross weight per carton | 21kg | |
| Reference CBM per unit | 0.205 cbm | |
| Indicative 40HQ container load quantity | 350 units | |
| Assembly time reference | 10minutes per unit | |
| Reference Package Count | 1 set / 2 cartons | |
| Reference Assembly Time | 40minutes per set | |
| Reference Packaged Gross Weight | 23kg/set | |
| Reference Carton Volume | 0.26m³/set |
Recommended spaces / users / usage modes
| Conference/meeting room seating | Ideal for boardroom and meeting table arrangements, fixed non-rolling base prevents unwanted movement during discussions | |
|---|---|---|
| Executive office guest seating | Suitable for placement in front of executive desks for visitor seating, polished chrome and light gray finish matches premium office decor | |
| Reception/waiting area seating | Durable cantilever construction supports high-traffic waiting area use with minimal maintenance requirements | |
| Training room seating | Low-profile fixed design allows easy tucking under tables when not in use to maximize floor space in training facilities | |
| Recommended floor type | Suitable for hard floors (wood, tile, vinyl) with fitted non-marking glides; not recommended for thick pile carpet without alternative glides | |
| Standard available upholstery colors | Offered in light gray (as pictured), plus standard black, dark gray and beige options for commercial projects | |
| Conference/boardroom seating | Suitable for 12 person conference table arrangements, fixed non-rolling base prevents unwanted movement during discussions, low-profile sled base tucks fully under 750mm high conference tables to save space | |
| Corporate reception/waiting areas | Appropriate for high-traffic reception zones, durable PU upholstery resists stains and allows easy wiping cleaning, robust cantilever frame withstands daily high-turnover use with minimal maintenance |
European market access and chemical requirements
| EN 1335-2:2018 | Applicable reference standard for office chair safety, strength and stability for non-adjustable office seating | |
|---|---|---|
| EN 1022:2018 | Applicable reference standard for seating stability testing for cantilever domestic and contract chairs | |
| EN 14465:2003 | Applicable reference for upholstery fabric/leather abrasion resistance, recommended minimum 50000 Martindale cycles for commercial use | |
| Tip stability threshold (rearward) | ≥60 kg applied 100mm from back top without tipping |
US and Canada office-furniture standards
| ANSI/BIFMA X5.1-2017 (non-adjustable chair clauses) | Applicable reference standard for commercial office chair static and dynamic load testing for fixed guest/conference chairs |
|---|
Standards applicable to China-market projects
| GB/T 3326-2016 | Applicable standards and test results require confirmation | |
|---|---|---|
| GB/T 22792.1-2009 | Applicable reference standard for office chair structural strength testing for fixed-base seating | |
| GB 18587-2001 | Applicable reference for limit of harmful substances in upholstered furniture textiles/leather |
This product must meet the following technical requirements: 1. GB/T 3326-2016: Applicable standards and test results require confirmation; 2. GB/T 22792.1-2009: Applicable reference standard for office chair structural strength testing for fixed-base seating; 3. GB 18587-2001: Applicable reference for limit of harmful substances in upholstered furniture textiles/leather; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
