PRODUCT MODULE 01 / 06

Physical Dimensions

Automatic mm / inch conversion · Core engineering specifications

Data source: Structured from factory data; final measured values prevail.

Overall dimensions (W × D × H)	660 × 650 × 1025 mm
Finished Seat Cushion Thickness	90 mm
Backrest Padding Thickness	70 mm
Lumbar Support Zone Height	240 mm
Clear Width Between Armrests	540 mm

PRODUCT MODULE 02 / 06

Weight, Load & Performance

Net weight / load capacity / users / durability

Data source: Product performance data; verify exact test conditions before procurement.

Suggested user weight capacity	160 kg
Frame static load verification target	450 kg
Seat impact durability target	100000 cycles
Backrest cyclic load target	120000 cycles
Front-to-back floor loading footprint	630 mm
Seat Foam Density / Rebound Reference	45 kg/m³ / 65%
Back Foam Density Reference	38 kg/m³
Upholstery Thickness / Abrasion Reference	1.4 mm / 50000 cycles
Five-star Base Static Load Reference	Acceptance target ≥120 kg; chair reference load 150 kg
Caster Rolling Durability Reference	Acceptance target 30000 cycles

PRODUCT MODULE 03 / 06

Materials & Structure

Core acceptance fields · Panels / hardware / frame / upholstery

Data source: Subject to the factory material list and inspection report.

Seat Internal Support Board Thickness	14 mm bent plywood or equivalent support board
Backrest Internal Frame Thickness	14 mm bent plywood/composite reinforced frame
Gas-lift Engineering Specification	Recommended Class 4; outer tube 50 mm; stroke 100 mm
Tilt Mechanism Plate Thickness	2.5 mm cold-rolled steel
Five-star Base Material Thickness	Metal base wall 3.5 mm; diameter 700 mm
Caster Engineering Specification	5 PU-tread swivel casters, 60 mm diameter

PRODUCT MODULE 04 / 06

Functions & Adjustment

Adjustment / rotation / tilt / mobility / storage features

Data source: Functional configuration; the supplier specification prevails.

Recline Angle / Lock Reference	125° with 3suggested lock positions
Tilt Tension User-weight Range	Reference adjustment coverage 120 kg
Height Adjustment Stroke	100 mm continuous travel
Rotation / Mobility Configuration	360° swivel with 5-caster multidirectional movement

PRODUCT MODULE 05 / 06

Packaging & Logistics

Verified carton / gross weight / assembly / loading data

Data source: Reference for export quotations and container planning.

Reference Package Count	1 set / 2 cartons
Reference Assembly Time	40 minutes per set
Reference Carton Dimensions	850× 420× 720 mm
Reference Packaged Gross Weight	23 kg/set
Reference Carton Volume	0.26 m³/set
Indicative 20GP Loading	135 sets at 85% space utilization

PRODUCT MODULE 06 / 06

Applications & Usage

Recommended spaces / users / usage modes

Data source: Recommended applications based on product form and category.

Recommended Matching Desk Size	2.4 m executive desk
Reference Daily Use Duration	8 hours/day; confirm by ergonomic testing

STANDARD S1

EU Market Entry Requirements * EN Standards

EU Market Access Requirements* EN Standards

No standards data is available for this market.

STANDARD S2

North America Purchasing & Inspection Reference * ANSI/BIFMA Standards

US and Canada office-furniture standards

North America procurement and testing reference	Recommended references: ANSI/BIFMA X5.4

STANDARD S3

Standards Applicable to China-Market Projects * GB Standards

Standards applicable to China-market projects

No standards data is available for this market.

Standardized tender description text

This product must meet the following technical requirements:
1. Technical standards and test reports must be supplied during tender or purchase confirmation;
Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.

GENERATED EXPORTS

Ready-to-use export tools

Export data is generated from the current published product record.

Technical Report PDF

Directly download an English report in metric or imperial units.

PDF · VC-CANT-660650-TT

Complete Parameter Workbook

Download all product information and parameter modules in English.

XLSX · VC-CANT-660650-TT

International Listing Template

English title, specifications, materials, standards and purchasing fields.

XLSX · LISTING

Customs Declaration Data

Prepare customs description, material, usage, dimensions and declaration elements.

CUSTOMS · VC-CANT-660650-TTOpen Export Tool

Quick Actions

Post an RFQ

Product Description

The Two-Tone Upholstered Visitor Chair with Chrome Cantilever Sled Base is an unbranded reception and visitor seating solution, model VC-CANT-660650-TT. Its two-tone padded upholstery gives the chair a polished, contemporary appearance, while a leather-look surface supports a professional look in formal meeting and guest settings. The chair is non-swivel and uses a cantilever sled frame, producing a clean linear silhouette and an open, uncluttered footprint beside desks or around reception tables. Integrated armrests continue the side profile of the seat and provide upper-body support without separate attachments. Black floor glides complete the base and provide a defined contact point with the floor. Construction combines padded leather-look upholstery with a chrome-plated tubular steel cantilever frame. The seat cushion has a finished thickness of 90 mm, and the backrest padding is 70 mm thick. A 240 mm lumbar support zone shapes the lower-back area, while the clear width between armrests is 540 mm. Internal seat support uses a 14 mm bent plywood or equivalent support board, and the backrest uses a 14 mm bent plywood or composite reinforced frame. Reference foam specifications include 45 kg/m³ seat foam with 65 percent rebound and 38 kg/m³ back foam. The overall dimensions are 660 mm wide, 650 mm deep, and 1025 mm high, with a front-to-back floor loading footprint of 630 mm. The suggested user weight capacity is 160 kg. Engineering and durability references include a 450 kg frame static load verification target, 100,000 seat impact durability cycles, and 120,000 backrest cyclic load cycles. These values are planning and verification references rather than field-use guarantees. The fixed cantilever design is suited to visitors who require stable side-arm support and an easy seating position in reception, conference, executive meeting, or guest consultation areas. The recommended matching desk size is a 2.4 m executive desk, and the reference daily use duration is 8 hours per day, subject to confirmation by ergonomic testing. Procurement planning should note that one set ships in two cartons, with a packaged gross weight of 23 kg and total carton volume of 0.26 m³ per set. Reference carton dimensions are 850 by 420 by 720 mm, and reference assembly time is 40 minutes per set. At 85 percent space utilization, the indicative 20GP container loading is 135 sets. Buyers should specify flooring conditions, delivery access, assembly resources, and intended daily use when placing orders.

Two-Tone Upholstered Visitor Chair with Chrome Cantilever Sled Base Specifications
